Stop Display application

Figure 69: Stop Display application
Stop Display application
banner
PRISM Media Analysis Platform User Manual
The Stop Display provides a tool to monitor video signals with a variety of
transfer functions in a consistent manner. It also helps the DP, Cinematographer
and Light engineer communicate to create a scene.
NOTE. Stop Display is enabled with Option MP-PROD and is effected by the
Gamma and Color Gamut settings. For additional information regarding these
settings, refer to the How to configure signal inputs section (See page 40.)
The following figure shows the available options after pressing and holding
anywhere on the Stop Display application tile.
Figure 70: Stop Display application banner
The following options adjust the Stop Display application:
The maximize icon ( ) expands the Stop Display application tile to the full
screen. The minimize icon ( ) collapse the tile back to its original size.
Application information
91
