Application information

Video Session application

Figure 90: Video Session application – SDI FORMAT tab display
Video Session application
banner
110
Use this application to view various performance parameters of the SDI video
signal or the decoded IP stream. Touch any of the four tab titles to view the
associated information: SDI Format, VPID 352, Bit Level, or CRC Status.
The following figure shows the available options after pressing and holding
anywhere on the Video Session application tile.
Figure 91: Video Session application banner
The following options adjust the Video Session application tile:
The maximize icon ( ) expands the Video Session application tile to the full
screen. The minimize icon ( ) collapse the tile back to its original size.
The expand icon ( ) expands or collapses the tile vertically. If the tile
expands it will cover the tile above or below, depending on whether you are
expanding the top or bottom quarter tile. Use the collapse icon ( ) to bring
the tile back to its original size.
