Table 2-12. TP E30 - 1PPS+TOD Port Pin-Outs - RJ45 Connector (Continued)
Pin
5
6
7
8
Table 2-13. TP E30 - Default Parameters for TOD Information Transmission
Pin
Baud Rate
Parity Check
Start Bit
Stop Bit
Idle Frame
Data Bits
See Appendix B, Specifications and Factory Defaults
about the TOD signal.

Connecting the GPS/GNSS Antenna

Caution: The GPS and GNSS cables should only be connected while
the unit is properly Earth grounded.
The antenna connections for the TP 5000 are made at the IMC module connector
labeled GPS or GNSS. Allow at least one hour for the unit to track and lock to
GPS/GNSS.
098-00028-000 Revision F – May, 2012
Signal
GND
422_1_P
422_2_N
422_2_P
Default
9600
None
1 (low level)
1 (high level)
High level
8
Connecting the GPS/GNSS Antenna
Comment
RS422 GND
1PPS
TOD time information
TOD time information
Comment
for additional information
TimeProvider 5000 User's Guide
Chapter 2 Installing
83
