Provisioning PTP

By default, the TP5000 is provisioned as a PTP grandmaster enabled for PTP
unicast dynamic negotiation, except for versions that are purchased as dedicated
NTP servers. The TP5000 also supports up to 10 unicast static clients per port. The
"set ptp" command is used to provision PTP parameters common to Default
(multicast), Hybrid (multicast-hybrid), Telecom-2008 (unicast), and ITU-G.8265.1
configurations. See
"set ptp" commands.
and Table B-30
ptp profile, management addressing mode and two-step clock mode.
Packet Service Modes
Each Ethernet port on the TP5000 IOC module can be configured as either a PTP
grandmaster or as an NTP server, with PTP grandmaster as the default. The
exception is for versions that are purchased as dedicated NTP servers. See
4-9.
Note: The set packet-service command also allows the user to
configure the TP5000 as a PTP probe or NTP probe. A separate
option license is required to enable the TP5000 to support either type
of probe functionality.
Figure 4-9.

Set Packet-Service Command Hierarchy

Use the following procedure to configure Port 1 of IOC1 as a PTP grandmaster:
1. Login at the Admin.
2. Type
set packet-service ioc1-1 ptp-gm
098-00028-000 Revision F – May, 2012
Figure 4-10, Figure 4-11
SeeTable 4-10 for descriptions of the Common parameters
for defaults and ranges. including those commands for setting the
and Figure 4-12 for the hierarchy of the
and press Enter.
TimeProvider 5000 User's Guide 291
Chapter 4 Provisioning
Provisioning PTP
