Page 1 TimeCreator 1000 DOCSIS Timing Interface Server User’s Guide Revision C – February 2010 Part Number 097-93100-01...
Page 2 2300 Orchard Parkway San Jose, CA 95131-1017 U.S.A. http://www.symmetricom.com Copyright © 2010 Symmetricom, Inc. All rights reserved. Printed in U.S.A. All product names, service marks, trademarks, and registered trademarks used in this document are the property of their respective owners.
Page 3: Table Of Contents
Chapter 1 Overview of the TimeCreator 1000 Overview ............24 Shelf .
Page 4 Overview ............38 TimeCreator 1000 Part Numbers ........38 System Configurations .
Page 5 Provisioning Establishing a Connection to the TimeCreator 1000.....72 Communicating Through the Serial Port......72 Communicating Through the Ethernet Port .
Page 6 Displaying System Status ........108 TimeCreator 1000 User’s Guide...
Page 7 Replacing the IMC .........122 Repairing the TimeCreator 1000........122 Obtaining Technical Assistance .
Page 8 Alarm Default Values ........290 TimeCreator 1000 User’s Guide...
Page 9: Timecreator 1000 User's Guide
............295 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide...
Page 10 Table of Contents TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 11 DTI Server Hierarchy and M-CMTS Elements..... . .24 TimeCreator 1000 Front View ........25 TimeCreator 1000 Rear View .
Page 12 List of Figures TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 13 Recovery Modes Based on TOD Source......96 TimeCreator 1000 Alarm Codes ....... .107 Preventive Maintenance .
Page 14 TimeCreator Events Traps - Additional Details .....162 TimeCreator 1000 Alarm Codes ....... .180 Time Zone Offsets .
Page 15: How To Use This Guide
Conventions Used in This Guide  Warnings, Cautions, Recommendations, and Notes  Related Documents and Information  Where to Find Answers to Product and Document Questions  What’s New In This Guide  097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide...
Page 16: Purpose Of This Guide
How to Use This Guide Purpose of This Guide Purpose of This Guide The TimeCreator 1000 User’s Guide describes the procedures for unpacking, installing, using, maintaining, and troubleshooting the Symmetricom TimeCreator 1000 DOCSIS Timing Interface Server (TimeCreator 1000). It also includes appendixes that describe alarms and events, the languages that you use to communicate with the TimeCreator 1000, default values, and other information.
Page 17: Structure Of This Guide
Provides procedures for installing a GPS antenna and connecting Two-Way GPS Antenna it to the TimeCreator 1000. Appendix D, Specifications and Lists the specifications for the TimeCreator 1000. Factory Defaults Appendix E, Software Licenses Contains licensing information for third party software.
Page 18: Conventions Used In This Guide
You must enter status commands for case-sensitive operating systems exactly as shown. qualified personnel A word or term being emphasized. Symmetricom does not A word or term given special emphasis. recommend... TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 19: Warnings, Cautions, Recommendations, And Notes
Note: All notes use this symbol. Notes contain installation, operation, or maintenance procedures, practices, conditions, or statements, that alert you to important information, which may make your task easier or increase your understanding. 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide...
Page 20: Related Documents And Information
How to Use This Guide Related Documents and Information Related Documents and Information See your Symmetricom representative or sales office for a complete list of available documentation. Note: Symmetricom offers training courses designed to enhance your knowledge of the TimeCreator 1000. Contact your local representative or sales office for a complete list of courses and outlines.
Page 21 Set SNMP accessv2 Rwcommunity  Show SNMP accessv3  Set SNMP accessv3  Show Whitelist  Set Whitelist  Deleted CLI commands in Appendix B: History  Clear log  097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide...
Page 22 How to Use This Guide What’s New In This Guide TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 23: Chapter 1 Overview Of The Timecreator
Chapter 1 Overview of the TimeCreator 1000 This chapter provides introductory information for the TimeCreator 1000. In This Chapter Overview  Performance Monitoring  Physical Description  Functional Description  Communication Ports  Outputs  Reference Inputs and TOD Sources ...
Page 24: Dti Server Hierarchy And M-Cmts Elements
(Edge QAMs, Upstream Receivers, M-CMTS Core, etc.) use DTI to synchronize the DOCSIS Timestamp and Symbol Clock used in the DOCSIS communications between modems and the headend/hub. The TimeCreator 1000 functions as either a root server or subtending server. The root server is at the top of a server hierarchy and is the source of traceable time and frequency for all subtending DTI servers and clients in a building.
Page 25: Timecreator 1000 Front View
Chapter 1 Overview of the TimeCreator 1000 Overview A TimeCreator 1000 in a root server configuration can use either its internal clock as the master frequency for the headend/hub meeting DOCSIS specifications, or it can be configured to use GPS. GPS is required for Business Services over DOCSIS (BSoD), which allows you to deliver T1, E1, and NxDSO emulation services.
Page 26: Shelf
Input Signals The TimeCreator 1000 can use either GPS or DTI signals as external input references to acquire the system’s frequency, DTI timestamp, and TOD alignment. NTP and the user-specified time from the IMC’s real-time clock (RTC) can also provide system TOD with much less accuracy.
Page 27: Timecreator 1000 Input Signal Source
Chapter 1 Overview of the TimeCreator 1000 Overview Table 1-1. TimeCreator 1000 Input Signal Source Input Source Description GPS antenna used to acquire the system’s frequency, DTI timestamp, and TOD. External DTI signals used as external input references to acquire the system’s frequency, DTI timestamp, and TOD.
Page 28: Output Signals
Through the Ethernet Port, on page 72). Once the IP address is set and a connection is made, you can access the TimeCreator 1000 on an intranet. The Ethernet port supports two simultaneous connections to port 23. TimeCreator 1000 User’s Guide...
Page 29: Clock Design
TOD are tracking the reference frequency (GPS or DTI) and TOD within the DTI specified requirements. Bridging – If all input references are lost, the TimeCreator 1000 goes into  bridging mode. In this mode, the outputs continue to provide accurate timing for a limited period.
Page 30: Performance Monitoring
MTIE values for 35-second and user-configurable windows. You can set an alarm threshold for each of these windows; if the MTIE value exceeds this threshold and the alarm is enabled, the TimeCreator 1000 generates an alarm. Physical Description The TimeCreator 1000 consists of a 19-inch (48 cm) rack mount shelf, plug-in modules, AC power supply cables and optional GPS cables, and hardware.
Page 31: Timecreator 1000 Modules And Dti Links
Chapter 1 Overview of the TimeCreator 1000 Functional Description The front of the TimeCreator 1000 has two IOC module slots and one IMC module slot. The rear has two power supply slots, twelve DTI link connectors and two BITS connectors (see Figure 1-4).
Page 32: Timecreator 1000 Block Diagram
Chapter 1 Overview of the TimeCreator 1000 Functional Description Figure 1-5. TimeCreator 1000 Block Diagram Figure 1-6. IMC Module Block Diagram TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 33: Ioc Module Block Diagram
Chapter 1 Overview of the TimeCreator 1000 Functional Description Figure 1-7. IOC Module Block Diagram IOC Module The IOC module has LED status indicators and test outputs for the system. The LEDs indicate: Power Status  Active Status  Output Status ...
Page 34: Power Module
Chapter 1 Overview of the TimeCreator 1000 Communication Ports Power Module The TimeCreator 1000 allows either –48 V DC power connection, or 120/220 V AC power connection depending on the type of module used. The LED indicates power status. Rear Panel Connectors The TimeCreator 1000 rear panel connections are RJ-45 connectors.
Page 35: Management Ethernet Port
Output when a DTI Client is connected eliminating the need to manually compensate for cable lengths. The maximum cable length is 656 Ft. (200 m). The TimeCreator 1000 provides a 10.24 MHz master clock signal and a 10 kHz frame clock on the front panel.
Page 36: Alarms
Mode, on page 95 for details. Alarms The TimeCreator 1000 uses alarms to notify you when certain conditions are deteriorating below user-specified levels. These alarms are indicated by module status LEDs and by SNMP traps. You can provision the alarm to either be enabled or disabled and the current alarm state can be obtained via the communication ports.
Page 37: Chapter 2 Engineering And Ordering Procedures
Chapter 2 Engineering and Ordering Procedures This chapter describes the items available for the TimeCreator 1000, and lists the part number for each item. In This Chapter Overview  TimeCreator 1000 Part Numbers  User-Supplied Tools and Materials  097-93100-01 Revision C – February, 2010...
Page 38: Common Configurations
Table 2-6 990-93105-01 TimeCreator 1000 - NA AC Power (1 SH, 1 IMC, 2 IOC, 2 AC) 990-93105-02 TimeCreator 1000 - NA AC Power, 8port IOC (1 SH, 1 IMC, 2 IOC-8 port, 2 AC) Table 2-7 - see Table 2-8...
Page 39: Ac Power Cord Options
990-93108-01 TimeCreator 1000 - DC power (1 SH, 1 IMC, 2 IOC, 2 DC, GPS) - see 990-93109-01 TimeCreator 1000 - NA AC Power (1 SH, 1 IMC, 2 IOC, 2 AC, GPS, NTP) Table 2-11 - see Table 990-93110-01...
Page 40: Gps Parts And Accessories
Chapter 2 Engineering and Ordering Procedures TimeCreator 1000 Part Numbers Table 2-3. Component Part Numbers Item Part Number IOC Module Slot Blank Panel 090-93122-01 Power Module Slot Blank Panel 090-93142-01 TimeCreator 8 port to 12 port 990-93121-99 IOC Upgrade kit...
Page 41: Timecreator 1000 No Redundancy - Na Ac Power - P/N 990-93101-01
TimeCreator 1000 AC power card (AC) 090-93151-01 NA AC power connector cable 160-00004-02 CD Manuals 998-93101-01 Table 2-7. TimeCreator 1000 - NA AC Power & Rdnt Clk, 8port - P/N 990-93105-02 Item Part Number Quantity TimeCreator 1000 Shelf (SH) 090-93100-01...
Page 42: Timecreator 1000 - Na Ac Power - P/N 990-93107-01
Chapter 2 Engineering and Ordering Procedures TimeCreator 1000 Part Numbers Table 2-7. TimeCreator 1000 - NA AC Power & Rdnt Clk, 8port - P/N 990-93105-02 Item Part Number Quantity NA AC power connector cable 160-00004-02 CD Manuals 998-93101-01 Table 2-8. TimeCreator 1000 - DC Power - P/N 990-93106-01...
Page 43: Timecreator 1000 - Dc Power - P/N 990-93108-01
093-00001-01 TimeProvider/TimeCreator GPS hardware kit 093-58545-01 IF antenna mounting kit 093-72010-71 CD Manuals 998-93101-01 Table 2-11. TimeCreator 1000 - NA AC Power - P/N 990-93109-01 Item Part Number Quantity TimeCreator 1000 Shelf (SH) 090-93100-01 TimeCreator 1000 IOC card (IOC) 090-93121-01...
Page 44: Timecreator 1000 - Dc Power - P/N 990-93110-01
Chapter 2 Engineering and Ordering Procedures TimeCreator 1000 Part Numbers Table 2-12. TimeCreator 1000 - DC power - P/N 990-93110-01 Item Part Number Quantity TimeCreator 1000 Shelf (SH) 090-93100-01 TimeCreator 1000 IOC card (IOC) 090-93121-01 TimeCreator 1000 IMC card (IMC)
Page 45: User-Supplied Tools And Materials
User-Supplied Tools and Materials User-Supplied Tools and Materials You need to supply the following tools and materials for installing and testing the TimeCreator 1000. Phillips-head screwdriver to install the TimeCreator 1000 shelf in a rack  ESD wrist strap for installing modules ...
Page 46 Chapter 2 Engineering and Ordering Procedures User-Supplied Tools and Materials TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 47: Chapter 3 Installing The Timecreator
Chapter 3 Installing the TimeCreator 1000 This chapter describes the procedures for installing the TimeCreator 1000. In This Chapter Getting Started  Unpacking the Unit  Rack Mounting the Shelf  Working With Modules  Making Signal Connections  Making Ground and Power Connections ...
Page 48: Getting Started
The TimeCreator 1000 is designed to mount in a 19-inch (48 cm) rack, occupies 1.75 in (4.5 cm, 1 RU) of vertical rack space, and has a depth of 20 in (50.8 cm).
Page 49: Installation Tools And Equipment
TimeCreator 1000. Electromagnetic interference can adversely affect the operation of nearby equipment. Installation Tools and Equipment You will need the following tools and equipment to install the TimeCreator 1000: Standard tool kit  Cable ties, waxed string or acceptable cable clamps ...
Page 50: Rack Mounting The Shelf
The installation procedure described in this section provides general guidelines for installing the TimeCreator 1000. Always follow applicable local electrical codes. Use the following steps to mount the TimeCreator 1000 in a 19- or 23-inch (48 or rack. 58.42 cm) Note: The TimeCreator 1000 comes equipped with 19-inch rack mounting brackets.
Page 51: Installing The Timecreator 1000
Chapter 3 Installing the TimeCreator 1000 Working With Modules Figure 3-1. Installing the TimeCreator 1000 Working With Modules This section describes how to install, remove, and handle the modules associated with the TimeCreator 1000. Handling Modules When handling any of the modules, observe the following precautions: 1.
Page 52: Inserting Modules
Chapter 3 Installing the TimeCreator 1000 Working With Modules Inserting Modules This procedure is common for all modules. Caution: You must disconnect power prior to removing the power module, but all other modules can be removed and inserted while system power is supplied without damaging modules; however, system performance may be affected.
Page 53: Imc Module
Note: The T1/E1 BITS links do not function in this release. Making Communications Connections The IMC allows user control of the TimeCreator 1000. The EIA-232 serial port, Ethernet Management port, and NTP server port are located on the IMC as shown Figure 3-2.
Page 54: Serial Port Connector Pins
Chapter 3 Installing the TimeCreator 1000 Making Signal Connections The connector pinouts are listed in Table 3-1. Table 3-1. Management and NTP Server Ethernet Connector Pin Assignments Signal Name TX+ (Transmit positive) TX- (Transmit negative) RX- (Receive negative) RX+ (Receive positive)
Page 55: Gps Connections
Chapter 3 Installing the TimeCreator 1000 Making Signal Connections GPS Connections The TimeCreator 1000 GPS input TNC connector is located on the IMC. To connect a GPS signal, you must install a GPS antenna. For detailed installation instructions, Appendix C, Installing the Two-Way GPS Antenna.
Page 56: Rear Panel Dti Links
Chapter 3 Installing the TimeCreator 1000 Making Signal Connections To connect a TimeCreator 1000 root server to a subtending server, install a shielded twisted pair RJ-45 cable, CAT5E or better, from the root server's rear panel DTI connector to the subtending server's client input port (port A or port B, when optioned as 'client').
Page 57: Making Ground And Power Connections
Making Ground and Power Connections Making Ground and Power Connections The TimeCreator 1000 has the option of using either 120/220 V AC, or –48 V DC power. For non-redundant operation, install either one AC module or one DC module. For redundant operation, install either two AC modules, two DC modules,...
Page 58: Timecreator 1000 Dc Power Module
Chapter 3 Installing the TimeCreator 1000 Making Ground and Power Connections Figure 3-5. TimeCreator 1000 DC Power Module AC Power 1. Ensure the power source is turned off. 2. Connect the power cord to the power connector on the 120V-220V AC Power Module.
Page 59: Installation Completeness Checklist
Verify that all input and output cables are properly installed Applying Power to the TimeCreator 1000 The TimeCreator 1000 is not equipped with a Power switch. DC power is controlled by a power distribution panel. AC power is applied when a standard 120 or 220 V AC power cord connected to the 100-240 AC Power module is plugged into the appropriate power outlet.
Page 60 Chapter 3 Installing the TimeCreator 1000 Applying Power to the TimeCreator 1000 Table 3-5. Module LED Descriptions (Continued) Color Description IMC Module Power Module power fault Green Module power is functioning properly System is not provisioned to use GPS reference...
Page 61 Chapter 3 Installing the TimeCreator 1000 Applying Power to the TimeCreator 1000 Table 3-5. Module LED Descriptions (Continued) Color Description DTI Links A/11 - B/12 DTI Disabled, or Enabled and qualified as reference input Client State Amber Enabled and not qualified as reference input...
Page 62 Chapter 3 Installing the TimeCreator 1000 Applying Power to the TimeCreator 1000 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 63: Chapter 4 General Guidelines For Using The Symmetricom Timecreator
Chapter 4 General Guidelines for using the Symmetricom TimeCreator 1000 This chapter provides basic information to which users can refer to ensure proper system operation. In This Chapter Clock Operations   NTP Client Mode  DHCP  CLI commands ...
Page 64: Tod Source Modes
Chapter 4 General Guidelines for using the Symmetricom TimeCreator 1000 Clock Operations Clock Operations For TOD sources of RTC, User, and NTP, the unit initially sets the time from the selected source. The unit then operates in freerun after that, keeping time according to its local oscillator frequency.
Page 65: Dhcp
Chapter 4 General Guidelines for using the Symmetricom TimeCreator 1000 DHCP Since the unit only sets the time once, the time could be off by more than 100 ms if this procedure is not followed. DHCP This unit's DHCP client will not continually attempt to acquire an IP address if the Ethernet cable is not connected at power up, or when DHCP mode is enabled.
Page 66: Saving The Present Configuration To Non-Volatile Memory
Chapter 4 General Guidelines for using the Symmetricom TimeCreator 1000 CLI commands Saving The Present Configuration To Non-volatile Memory Enter the following command to backup the current configuration: Set configuration backup Enter the following command to backup the current IOC configuration in the IMC...
Page 67: Enabling Outputs
Chapter 4 General Guidelines for using the Symmetricom TimeCreator 1000 CLI commands Show status (general status of unit) Show gps (GPS information) Show inventory Backing up Provisioning Data, on page 110 for additional details. Enabling Outputs Enter the following command to set the interface state.
Page 68: Configuring For Ntp Mode
Chapter 4 General Guidelines for using the Symmetricom TimeCreator 1000 CLI commands Set tod-source gps Set interface state gps enable (Wait until GPS is available) Sync tod-source now Configuring For NTP Mode Enter the following commands to set up NTP mode:...
Page 69: Setting Manual Cable Advance
Chapter 4 General Guidelines for using the Symmetricom TimeCreator 1000 CLI commands Sync tod-source now If the unit is not ready when the “ ” command is issued, actual sync tod-source now execution of this command is postponed until the unit is ready. Use the “...
Page 70: Switching Active And Standby Cards
Chapter 4 General Guidelines for using the Symmetricom TimeCreator 1000 CLI commands Switching Active And Standby Cards Example for IOC 1 presently active, and switching to IOC 2): Set ioc-state IOC2 active TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 71: Chapter 5 Provisioning
Chapter 5 Provisioning This chapter describes the procedures for provisioning the TimeCreator 1000. Use the procedures in this chapter after you have installed and powered up the TimeCreator 1000 (see Chapter 3, Installing the TimeCreator 1000). In This Chapter Establishing a Connection to the TimeCreator 1000 ...
Page 72: Establishing A Connection To The Timecreator 1000
Establishing a Connection to the TimeCreator 1000 Establishing a Connection to the TimeCreator 1000 To set up and manage the TimeCreator 1000 with a terminal or a computer with terminal emulation, you must establish either a serial connection or an Ethernet connection.
Page 73 Making Communications Connections, on page 53 for details). 2. Telnet from your PC to the IP address assigned to the TimeCreator 1000 (see Configuring the Ethernet Port, on page 73). 3. Type your user name and press Enter. If you are not assigned as a user in the...
Page 74: Managing The User Access List
PC through the EIA-232 serial port. See Making Communications Connections, on page 53. 2. If the TimeCreator 1000 is connected to a LAN, Telnet from your PC to the assigned IP address, and start a Telnet session and press Enter. TimeCreator 1000 User’s Guide...
Page 75: Adding A User
Chapter 5 Provisioning Managing the User Access List If the TimeCreator 1000 is connected to a PC directly through the serial port, start a session and press Enter. 3. Type your user name and press Enter. The system prompts for a password.
Page 76: Deleting A User
1. Login at the Admin level (see Login, on page 74). 2. Type and press Enter. The system displays the current show logged-in-user list of users who are logged in. TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 77: Changing A User's Password And Access Level
5. Type the user’s password again and press Enter. 6. Type <access-level>and press Enter. set user modify <user> access-level (The access level is 1, 2, or 3, where 3 is admin level.) 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide...
Page 78: Managing The Ip Address Whitelist
Telnet/SSH. The whitelist must be committed before any changes to the whitelist will be implemented. Note: If the whitelist function is being use for a TimeCreator 1000 with 127.0.0.1) the TOD-source of NTP, the local host address (...
Page 79: Delete An Ip Address From The Whitelist
Provisioning Login Authentication The authentication scheme used in the TimeCreator 1000 allows you to provision either a RADIUS or TACACS+ server IP address and authentication key(s) for server access. If RADIUS or TACACS+ is enabled, the system allows local login if the server doesn't authenticate the user and the user is configured locally.
Page 80: Configuring The Radius Server
For other RADIUS servers, see the appropriate user documentation for information on how to configure the server. The "Class" attribute from the RADIUS server is used by the TimeCreator 1000 to indicate the security level for each authorized user, as described in the Table 5-2 below:.
Page 81 TimeCreator's stale user account (if it exists) for your remote RADIUS user. Then log in to TimeCreator again so the TimeCreator 1000 will recreate the user account for your remote RADIUS user with the new user security level corresponding to new "Class"...
Page 82: Configuring The Tacacs+ Server
Configuring the TACACS+ Server For the Cisco TAC_PLUS TACACS+ server, configuration requires placing the TimeCreator 1000 user information in the file tac.cfg. For other TACACS+ servers, see the appropriate user documentation for information on how to configure the server. The "priv-lvl " attribute from the TACACS+ server is used by the TimeCreator 1000 to indicate the security level for each authorized user, as described in the Table below:.
Page 83 # End file When using the TimeCreator's “show user” command, Note: users logged in remotely via TACACS+ will be displayed as <username> (remote), rather than just <username> for local users. 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide...
Page 84: Provisioning Services
TACACS+ user with the new user security level corresponding to the "priv-lvl" attribute you specified in the file “tac.cfg”. Provisioning Services Using the Set Service command, you can control the TimeCreator 1000 services (see Service, on page 250). This command allows you to enable or disable the...
Page 85: Dhcp Mode
Setting the System Date, Time and Time Offset The TimeCreator 1000 Time of Day can be set either by an external source, or manually with the Set Clock command. You can set the time and date only in the user tod-source mode.
Page 86: Setting The Dti Server Type
The TimeCreator 1000 can also be provisioned to operate as a subtending server receiving its reference from a root DTI server. The TimeCreator 1000 stays in warm-up until the time is obtained. If RTC mode is selected, then the time is already available. Other modes need to obtain the time from an external source.
Page 87: Root Dti Server In Free-Run Mode
The Set Clock Date Time command is used to set the system time. Example To provision the TimeCreator 1000 as a root server in free-run mode with the TOD set by the user to the current time, perform the following steps: 1.
Page 88: Root Dti Server In Gps Mode
Chapter 5 Provisioning Setting the DTI Server Type Example To provision the TimeCreator 1000 as a root server with an NTP server supplying the TOD, perform the following steps: 1. Login at the Admin or Power-User level (see Login, on page 74).
Page 89: Provisioning The Input Reference
Chapter 5 Provisioning Provisioning the Input Reference Example To provision the TimeCreator 1000 as a subtending server, perform the following steps: 1. Login at the Admin or Power-User level (see Login, on page 74). 2. Type and press Enter. set tod-source dti 3.
Page 90: Setting The Dti Parameters
Provisioning the Input Reference Example To provision the TimeCreator 1000 to set a GPS reference for manual mode and specify the position as a latitude of N37.22.45.123, longitude of W121.55.36.123, height of 17.5 meters, with a mask of 25 degrees, perform the following steps: 1.
Page 91: Setting The Ntp Parameters
Enter. set interface state port 12 enable Setting the NTP Parameters When the TimeCreator 1000 is provisioned for free-run mode, the unit can reference its time from an external NTP server connected to the MGMT or NTP port. Example...
Page 92: Provisioning The Dti Links
Provisioning the DTI Links Provisioning the DTI Links The TimeCreator 1000 rear panel has ten permanent DTI client links that provide DTI timing signals to client elements in an M-CMTS architecture. With the 8-port IOC module option, however, only Ports 1 through 6 are active. There are also two DTI client/server ports that can be provisioned as either DTI reference links (for subtending servers), or as additional DTI links to client elements.
Page 93: Dti Link Led Indicators
2. Enabled and qualified as reference input Amber Enabled and not qualified as reference input DTI Input Connectivity 1. Disabled Status 2. Not connected to DTI server Green Connected to DTI server 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide...
Page 94: Enabling Dti Test Mode
If the priorities are different, the ports act in the revertive mode. Example To provision the TimeCreator 1000 ports A and B for revertive mode, perform the following steps: 1. Login at the Admin or Power-User level (see Login, on page 74).
Page 95: Provisioning Root Server Recovery Mode
2. Root Server returning to server mode and slowly steering the subtending servers' time and phase back in phase with the root With the TimeCreator 1000, when the root server has lost power or is taken off line for servicing, the subtending servers' clocks will enter the holdover state and slowly drift over time.
Page 96: Recovery Modes Based On Tod Source
Enable root server auto recovery feature Root Recovery No action required for root server Root Recovery No action required for root server Real-Time Root Recovery No action required for root Clock server TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 97: State Diagram For Root Server Recovery - User Mode
Chapter 5 Provisioning Provisioning Root Server Recovery Mode Figure 5-1. State Diagram for Root Server Recovery - USER mode 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide...
Page 98: Simple Deployment With Root Server Recovery
Chapter 5 Provisioning Provisioning Root Server Recovery Mode Figure 5-2. Simple Deployment with Root Server Recovery Figure 5-3. Large Scale Deployment with Root Server Recovery TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 99: State Diagram For Root Recovery - Gps, Ntp, And Rtc Modes
Chapter 5 Provisioning Provisioning Root Server Recovery Mode Figure 5-4. State Diagram for Root Recovery - GPS, NTP, and RTC modes 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide...
Page 100: Requirements For Root Server Recovery
See the sections Displaying Status of Root Server Recovery, on page 101 and Enabling Rapid Recovery Mode, on page 102 for details. Using rapid recovery mode will cause network Warning: interruption 100 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 101: Enabling Root Server Recovery
Note: This command is only applicable for a TimeCreator 1000 that is OD Source mode of USER being used as a root server in T...
Page 102: Aborting Root Server Recovery
3. Type and press Enter. set root-recovery rapidrecovery all enable Aborting Root Server Recovery Use the command “set root-recovery autorecoverymode abort ” to abort the root server recovery process. 102 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 103: Provisioning Snmp
Provisioning SNMP Enabling SNMP allows you to use an SNMP interface to remotely manage the TimeCreator 1000 over an Ethernet connection. This also allows the user to: provision SNMPv2 to be enabled or disabled on the specified Ethernet port ...
Page 104: Provisioning An Ntp Server
Provisioning an NTP Server To provision the NTP server, you must enable it on the NTP server port. When NTP is enabled, the TimeCreator 1000 can serve its system time to external NTP clients. Example To enable NTP on the NTP server port, perform the following steps: 1.
Page 105: Provisioning Cable Advance
This section describes the commands used to provision and manage alarms in the TimeCreator 1000. The user can provision the alarms to be enabled or disabled and set thresholds to turn the alarms on and off. For a list of all alarms, see...
Page 106: Provisioning The Set And Clear Alarm Thresholds
Provisioning the Alarm-States The “set alarm-state <alarm code> {enable|disable}” command is used to enable or disable specific alarms. Table 5-7 provides a list of TimeCreator alarm types and their descriptions. Example 106 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 107: Timecreator 1000 Alarm Codes
1. Login at the Admin or Power-User level (see Login, on page 74). 2. Type and press Enter. set alarm-state exthold enable Table 5-7. TimeCreator 1000 Alarm Codes Alarm Code Description IOCFAIL IOC card failure IMCFAIL...
Page 108: Retrieving Current Alarm Settings
Chapter 5 Provisioning Provisioning Alarms Table 5-7. TimeCreator 1000 Alarm Codes Alarm Code Description IOC DCM unlocked DCMUNLOCK PLLUNLOCK IOC PLL unlocked Retrieving Current Alarm Settings The “show alarm threshold” command displays the set and clear alarm thresholds of all ports.
Page 109: Routine Operation Commands
To display the system status, enter the following: Type and press Enter. show status Routine Operation Commands This section describes the commands you use to perform the following routine operations with the TimeCreator 1000: Displaying alarms  Displaying events  Restarting the server IMC card ...
Page 110: Restarting Timecreator 1000'S Imc Card
Saving and Restoring Provisioning Data Symmetricom recommends that you keep an electronic version and/or a written version of the provisioning changes you make to the TimeCreator 1000. Note: IMC configuration changes are not saved automatically, so it is necessary to use the command “set configuration backup IMC” to explicitly save the changes.
Page 111: Restoring Provisioning Data
Change Current Configuration to Factory Default To change the current configuration to the factory default, use the command “set configuration factory”. Example Type and press Enter. set configuration factory 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 111...
Page 112 “set recvconfig IOC user@host:file” to specify the server address and file name. Example1 To retrieve the IOC configuration file “/home/user/ioc.bak” from the remote server at IP address 192.168.3.86 - 112 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 113 IOC user@192.168.3.86:/home/user/ioc.bak press Enter. Example 2 To restore the IOC configuration file that was retrieved rom the remote server - Type and press Enter. set configuration restoreuser IOC 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 113...
Page 114: Timecreator 1000 User's Guide 097-93100-01 Revision C – February
Chapter 5 Provisioning Saving and Restoring Provisioning Data 114 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 115: Chapter 6 Maintenance And Troubleshooting
Diagnosing the IOC  Diagnosing the IMC  Repairing the TimeCreator 1000  Obtaining Technical Assistance  Upgrading the Firmware  Returning the TimeCreator 1000  User’s Guide Updates  097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 115...
Page 116: Preventive Maintenance
Maintenance personnel should wear ESD wrist straps when installing or working on all TimeCreator 1000 equipment and modules. Plug the user-supplied wrist strap into the TimeCreator 1000. Place IMC and IOC modules into static-free bags when not in use. 116 TimeCreator 1000 User’s Guide...
Page 117: Diagnosing The Ioc
Removing the Only IOC To remove the only IOC in a shelf, use the following procedure. Output signals will be interrupted; they will resume once the IOC has achieved normal operating state. 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 117...
Page 118 Type and press Enter. set ioc-state IOC1 disable 3. Attach a wrist grounding strap and connect it to the TimeCreator 1000 chassis. 4. Loosen the captive retaining screws and pull out on them to unseat the IOC from the shelf.
Page 119 Caution: Output signals are turned off when you place the second IOC out of service. 3. Attach a wrist grounding strap and connect it to the TimeCreator 1000 chassis. 4. Loosen the captive retaining screws and pull out on them to unseat the standby IOC from the shelf.
Page 120: Replacing The Ioc
IOC memory in the IMC using the Set Configuration Backup IOC command. 1. Attach a wrist grounding strap and connect it to the TimeCreator 1000 chassis. 2. Install the IOC into the shelf and tighten the captive retaining screws.
Page 121: Diagnosing The Imc
System is provisioned to use GPS reference, GPS reference is qualified as reference Ethernet No Ethernet link established state Green Ethernet link established Ethernet No Ethernet activity activity Amber Blinks with Ethernet activity 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 121...
Page 122: Replacing The Imc
Type and press Enter. set configuration backup imc ioc1 2. Attach a wrist grounding strap and connect it to the TimeCreator 1000 chassis. 3. Remove the IMC by loosening the captive screws and pulling the IMC from the shelf. Warning: To avoid possible electrostatic damage to the IMC, place it in a static-free bag or on a static-free surface.
Page 123: Obtaining Technical Assistance
Upgrading Single IOCs To upgrade the software in a single IOC, use the procedure in this section. Outputs from the TimeCreator 1000 are interrupted for up to 30 minutes until the upgraded IOC enters the Locked mode. 1. Login at the Admin level (see Login, on page 74).
Page 124 IOC is rebooted first. The IMC waits until that IOC is out of warmup, and then it is set active. At that point, the previously active IOC is rebooted. Note: Symmetricom recommends that redundant IOCs use the same firmware revision.
Page 125: Upgrading The Imc
5. The new software is loaded into the IOC, the IOC is rebooted, and it then enters Warm-up mode for up to 30 minutes. If you are upgrading the active IOC, the TimeCreator 1000 performs the following: the active IOC enters standby mode ...
Page 126: Returning The Timecreator 1000
Note: The system will FTP the file from the specified FTP server (IP address) and then upgrade the module. 5. The TimeCreator 1000 validates the received file, and if the file is valid it updates the flash memory and reboots the IMC.
Page 127: User's Guide Updates
3. Provide the return shipping information (customer field contact, address, telephone number, and so forth.) 4. Ship the product to Symmetricom, transportation prepaid and insured, with the Return Material Authorization (RMA) number and item numbers or part numbers clearly marked on the outside of the container to the address given with the RMA.
Page 128 Chapter 6 Maintenance and Troubleshooting User’s Guide Updates 128 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 129: Appendix A Alarms, Events And Snmp Traps
Appendix A Alarms, Events and SNMP Traps The TimeCreator 1000 provides a log of events and alarms that are stored in non-volatile memory on the IMC module. This appendix provides details on the TimeCreator 1000 alarms, including corrective actions. This appendix also provides details and descriptions about events and SNMP traps.
Page 130: Alarm Messages
Alarm Messages Alarm Messages The TimeCreator 1000 provides set and clear alarm messages to notify you when certain conditions are exceeding the user-specified levels (when alarms are set) and when certain conditions return to within the user-specified levels (when alarms are cleared).
Page 131: System Notification Messages - Alarms
IOC module is not resolved, not functioning replace module properly IOC <#> Indicates that No action required recovered from the specified operational IOC module is failure now functioning properly 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 131...
Page 132 NE providing input unstable the specified on that port port is unstable Input Port <#> Indicates that No action required performance is performance for stable the specified port is stable 132 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 133 BITS Port <#> Indicates that No action required reference is the reference qualified as signal at the system reference specified BITS input port can be used as system reference 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 133...
Page 134 IOC not resolved, modules is lost replace module Xsync between Indicates that No action required IOCs recovered the Xsync between IOC modules has been restored 134 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 135 <value> exceeded the port user-set threshold Port <#> is within Indicates that No action required the MTIE-t the MTIE-t error threshold, rate is within the <value> user-set threshold 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 135...
Page 136 B output module, if issue is voltage failure not resolved, replace module Power Module Power module A No action required <#> output failure or B output cleared voltage OK 136 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 137 IOC <#> PLL Phase clock Hardware failure, unlocked module has contact become Symmetricom tech unlocked support IOC <#> PLL Phase clock No action required locked module has become locked 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 137...
Page 138: Event Messages
Warm-up Mode into Warm-up mode CLKFREE nonalarm IOC <#> has Indicates that IOC No action transitioned into module has entered required Free-run Mode into Free-run mode 138 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 139 Normal Mode entered into Normal mode CLTBRG nonalarm Port <#> has Indicates that No action transitioned into specified port has required Bridging Mode entered into Bridging mode 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 139...
Page 140 Frequency Mode into Frequency mode IOC <#> has Indicates that IOC No action transitioned out of module has exited required Frequency Mode Frequency mode 140 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 141 INSVRWARM nonalarm Input Port <#> Indicates that No action server has specified input port required transitioned into has entered into Warm-up Mode Warm-up Mode 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 141...
Page 142 No action TOD valid TOD for the required specified input port is valid BT3ENGINE nonalarm BestTime engine Indicates the No action mode <#> gear BestTime engine's required <#> progress 142 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 143 Output Port <#> Indicates that the No action exited <#> output port (1-12) required recovery has exited bridging/normal holdover/extended holdover/exception al holdover recovery 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 143...
Page 144 UTCAVA nonalarm UTC time from Indicates that the No action GPS is available UTC time for GPS required is available 144 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 145 Port <#> P-P Jitter Indicates that the No action threshold set P-P Jitter threshold required above 0, alarm for the port has enabled been set to nonzero and the alarm is enabled 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 145...
Page 146 No action been set by user set by the user required RSREN nonalarm Entered auto root Indicates that the No action recovery system has entered required auto root recovery 146 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 147 Indicates that the No action recovery system has exited required auto root recovery RSRAB nonalarm Aborted auto root Indicates that the No action recovery user has aborted required auto root recovery 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 147...
Page 148: Snmp Traps
Appendix A Alarms, Events and SNMP Traps SNMP Traps SNMP Traps The MIB for TimeCreator 1000 v1.2 has MIB var bindings for all Symmetricom specific SNMP traps, as shown in Table A-4 below: Table A-4. MIB Var Bindings for Symmetricom- specific Traps...
Page 149: Snmp Mib - Event Table Entries
Appendix A Alarms, Events and SNMP Traps SNMP Traps Figure A-1. SNMP MIB - Event Table Entries Figure A-2. SNMP MIB - Trap Object Parameters and Event Log Entries 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 149...
Page 150: Snmp Alarm Traps
SNMP MIB - Trap Object Binding Example SNMP Alarm Traps Table A-5 shows some details for TimeCreator SNMP alarm traps, such as trap name, OID, and severity. Table A-5. TimeCreator 1000 Alarm Trap Details Trap Name Trap OID Trap (trapID)
Page 151 Appendix A Alarms, Events and SNMP Traps SNMP Traps Table A-5. TimeCreator 1000 Alarm Trap Details (Continued) Trap Name Trap OID Trap (trapID) Name Severity MTIETEXC Minor trapMTIETExceed 1.3.6.1.4.1.9070.1.2.4.1.100.2.15 MTIE35EXC trapMTIE35Exceed Minor 1.3.6.1.4.1.9070.1.2.4.1.100.2.16 PPJEXC trapPPJitterExceed Minor 1.3.6.1.4.1.9070.1.2.4.1.100.2.17 FEREXC trapFERExceed Minor 1.3.6.1.4.1.9070.1.2.4.1.100.2.18...
Page 152: Timecreator 1000 Alarm Traps - Additional Details
The severity level for an alarm trap can be critical, major, or minor if trapState is set (2) for this alarm trap; otherwise, the severity level will be clear if trapState is clear (1) for this alarm trap. Table A-6. TimeCreator 1000 Alarm Traps - Additional Details trapSev Trap OID Name...
Page 153 Appendix A Alarms, Events and SNMP Traps SNMP Traps Table A-6. TimeCreator 1000 Alarm Traps - Additional Details (Continued) trapSev Trap OID Name Description Bindings Index erity trapIOCInputDisconnected Input/BITS Port trapID: INPDISC Minor <#> cable is (id = 26) trapAID1: 1: input port A...
Page 154 Appendix A Alarms, Events and SNMP Traps SNMP Traps Table A-6. TimeCreator 1000 Alarm Traps - Additional Details (Continued) trapSev Trap OID Name Description Bindings Index erity trapIOCInputDisqualified GPS reference trapID: INPDISQ Minor (id = 29) trapAID1: 0: GPS qualified/disqual...
Page 155 Appendix A Alarms, Events and SNMP Traps SNMP Traps Table A-6. TimeCreator 1000 Alarm Traps - Additional Details (Continued) trapSev Trap OID Name Description Bindings Index erity trapIOCXyncLoss Xsync between trapID: XSYNCLOS Major IOCs lost (id = 60) trapAID1: n/a...
Page 156 Appendix A Alarms, Events and SNMP Traps SNMP Traps Table A-6. TimeCreator 1000 Alarm Traps - Additional Details (Continued) trapSev Trap OID Name Description Bindings Index erity trapMTIE35Exceed Port <#> has trapID: MTIE35EXC Minor exceeded the (id = 314) trapAID1: port #...
Page 157 Appendix A Alarms, Events and SNMP Traps SNMP Traps Table A-6. TimeCreator 1000 Alarm Traps - Additional Details (Continued) trapSev Trap OID Name Description Bindings Index erity trapPowerFanFail Power Module trapID: PWRFANFAIL Major <#> fan failure (id = 319) trapAID1: power module #...
Page 158: Snmp Event Traps
SNMPv2c request using an unknown community name SNMP Event Traps Table A-8 shows some details for TimeCreator SNMP event traps, such as trap name, OID, and severity. Table A-8. TimeCreator 1000 Event Trap Details Trap Name Trap OID Trap (trapID) Name...
Page 159 Appendix A Alarms, Events and SNMP Traps SNMP Traps Table A-8. TimeCreator 1000 Event Trap Details (Continued) Trap Name Trap OID Trap (trapID) Name Severity CLKFREE trapIOCFreerun nonalarm 1.3.6.1.4.1.9070.1.2.4.1.100.1.6 CLKFSTRK trapIOCFasttrack nonalarm 1.3.6.1.4.1.9070.1.2.4.1.100.1.7 CLKNMTRK trapIOCNormaltrack nonalarm 1.3.6.1.4.1.9070.1.2.4.1.100.1.8 CLKBRG trapIOCBridging nonalarm 1.3.6.1.4.1.9070.1.2.4.1.100.1.9...
Page 160 Appendix A Alarms, Events and SNMP Traps SNMP Traps Table A-8. TimeCreator 1000 Event Trap Details (Continued) Trap Name Trap OID Trap (trapID) Name Severity INTODINV trapInputTOD 1.3.6.1.4.1.9070.1.2.4.1.100.1.30 nonalarm BT3ENGINE trapBestTimeEngine nonalarm 1.3.6.1.4.1.9070.1.2.4.1.100.1.31 TPIUTUNE trapTPIUVoltage nonalarm 1.3.6.1.4.1.9070.1.2.4.1.100.1.32 TATUNE trapAntennaVoltage 1.3.6.1.4.1.9070.1.2.4.1.100.1.33...
Page 161 Appendix A Alarms, Events and SNMP Traps SNMP Traps Table A-8. TimeCreator 1000 Event Trap Details (Continued) Trap Name Trap OID Trap (trapID) Name Severity RSREN trapEnterAutoRecovery nonalarm 1.3.6.1.4.1.9070.1.2.4.1.100.2.54 RSREX trapExitAutoRecovery nonalarm 1.3.6.1.4.1.9070.1.2.4.1.100.2.55 RSRAB trapAbortAutoRecovery 1.3.6.1.4.1.9070.1.2.4.1.100.2.56 nonalarm Table A-9 below for additional trap details, such as descriptions and bindings.
Page 162: Timecreator Events Traps - Additional Details
IOC <#> has trapID: CLKWARM nonalarm transitioned in to (id = 8) trapAID1: 1 or 2, Warm-up Mode IOC module id trapAID2: n/a set (2) trapState: trapValue: n/a 162 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 163 IOC <#> has trapID: CLKHOLD nonalarm transitioned in to (id = 13) trapAID1: 1 or 2, Holdover Mode IOC module id trapAID2: n/a set (2) trapState: trapValue: n/a 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 163...
Page 164 (2) trapState: trapValue: n/a trapPortNormaltrack Port <#> has trapID: CLTNMTRK nonalarm transitioned into (id = 21) trapAID1: port # Normal Mode trapAID2: n/a set (2) trapState: trapValue: n/a 164 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 165 (id = 30) trapAID1: 1 or 2, Frequency Mode IOC module id IOC <#> has trapAID2: n/a transitioned out of set (2) trapState: clear (1), Frequency Mode trapValue: n/a 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 165...
Page 166 IOC <#> Module trapID: AUTORST nonalarm auto reboot (id = 37) trapAID1: 1 or 2, IOC module id trapAID2: n/a set (2) trapState: trapValue: n/a 166 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 167 Input Port <#> trapID: INSVRHOLD nonalarm server has (id = 42) trapAID1: port # transitioned into Holdover Mode trapAID2: n/a set (2) trapState: trapValue: n/a 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 167...
Page 168 TATUNE nonalarm tuning voltage (id = 58) trapAID1: n/a outside 10%-90% range trapAID2: n/a set (2) trapState: clear (1), Timing Antenna tuning voltage trapValue: n/a within 10%-90% range 168 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 169 (id = 62) trapAID2: n/a set (2) trapState: trapValue: n/a trapAuthorizationGrant <#> authorization trapID: AUTHGRN nonalarm granted trapAID1: n/a (id = 301) trapAID2: n/a set (2) trapState: trapValue: user name 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 169...
Page 170 (id = 305) trapAID2: n/a set (2) trapState: trapValue: n/a trapDTITODSet DTI TOD has been trapID: SETTOD nonalarm (id = 306) trapAID1: n/a trapAID2: n/a set (2) trapState: trapValue: n/a 170 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 171 0, (id = 322) trapAID1: port # alarm disabled trapAID2: n/a Port <#> MTIE-35 set (2) trapState: clear (1), threshold set above 0, alarm enabled trapValue: n/a 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 171...
Page 172 (1), trapValue: n/a trapSystemTODSetByD System TOD has trapID: SETBYDTI nonalarm been set by root trapAID1: n/a server (id = 328) trapAID2: n/a set (2) trapState: trapValue: n/a 172 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 173 (2) trapState: trapValue: n/a trapAbortAutoRecovery Aborted auto root trapID: RSRAB nonalarm recovery (id = 332) trapAID1: n/a trapAID2: n/a set (2) trapState: trapValue: n/a 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 173...
Page 174 Appendix A Alarms, Events and SNMP Traps SNMP Traps 174 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 175 In This Appendix CLI Overview  CLI Commands  Simple Network Management Protocol  Network Time Protocol  Secure Shell Protocol  Secure File Transfer Protocol  097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 175...
Page 176: Cli Overview
CLI Overview CLI Overview The Command Line Interface (CLI), also called the ASCII command set, can be used to control the TimeCreator 1000 from a terminal connected to the EIA-232 serial port, or the Ethernet port. See Figure B-1 below for an overview of the command set.
Page 177: Command User Levels
Command User Levels The TimeCreator 1000 provides a hierarchy of CLI command user levels that permit an increasing level of access to system parameters. This allows the system administrator to add users who can only view but not change system parameters and users who can view and change system parameters.
Page 178: Cli Commands
User, Power-User and Admin Remarks: The information displayed is expected to be identical to an entry in the Event/Alarm Log File. Related: show status, generate message, show alarm-threshold, set alarm-threshold 178 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 179 DCM unlocked - enable PLL unlocked - enable Remarks: See the list of alarm codes in the Set Alarm-State command. Related: set alarm-state Level : User, Power-User and Admin 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 179...
Page 180 To enable the alarm for IOC in holdover for extended period (alarm code of EXTHOLD) - tc1000>set alarm-state exthold enable Related: show alarm-state Level: Power-User and Admin only Table B-1. TimeCreator 1000 Alarm Codes Alarm Code Description IOCFAIL IOC card failure IMCFAIL...
Page 181 Appendix B Command Descriptions and Communications Interface CLI Commands Table B-1. TimeCreator 1000 Alarm Codes Alarm Code Description PP-jitter threshold exceeded PPJITTER Frame error rate threshold exceeded PWROUTPUT Power module output failure PWRFAN Power module fan failure IOCRMV Both IOC removed...
Page 182 - 5000 MTIE-35 set - 10000 MTIE-35 clear - 7000 ....Remarks: When ports A/11 and B/12 are configured as clients, alarm thresholds are not used. Related: set alarm-threshold 182 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 183 6 set 100000 Example 3: To set the alarm threshold for MTIE-t on Port 7 to a value of 100,000: tc1000>set alarm-threshold mtie-t port 7 set 100000 Example 4: 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 183...
Page 184 Remarks: When ports A/11 and B/12 are configured as clients, alarm thresholds are not used. The alarm is disabled if either threshold, set, or clear is set to zero. Related: show alarm-threshold Level : Power-User and Admin only 184 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 185 UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1 RX packets:176695 errors:0 dropped:0 overruns:0 frame:0 TX packets:0 errors:0 dropped:0 overruns:0 carrier:0 collisions:0 txqueuelen:100 RX bytes:10976936 (10.4 Mb) TX bytes:0 (0.0 b) Interrupt:9 Base address:0xf000 Memory:fbfaf000-fbfb0000 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 185...
Page 186 TX bytes:8584 (8.3 Kb) Example 2: To display all defined aliases: tc1000> alias Response 2: alias ip='show ip status' alias inv='show inventory' Related: None Level : User, Power-User and Admin 186 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 187: Show Authentication
Appendix B Command Descriptions and Communications Interface CLI Commands Show Authentication Displays how the TimeCreator 1000 authenticates users. If applicable, it displays the RADIUS server and key and TACACS+ server and key. Command Syntax: show authentication Example: To display the authentication status: tc1000>show authentication...
Page 188 To provision the TACACS+ server IP address to 192.168.5.27, with no port specified: tc1000>set authentication tacacs+ address 192.168.5.27 Example 6: To provision the TACACS+ server to authentication key “ABCDEFGH1234567890” for server access: 188 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 189 Remarks: Authentication can be by local, RADIUS, and TACACS+. If no port is defined for RADIUS or TACACS+ IP address, the default Port (1812 for RADIUS, 49 for TACACS+) is used. Related: show authentication Level : Power-User and Admin 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 189...
Page 190 1000 Remarks: The default value is 900 seconds. Based on DOCSIS requirements and the characteristics of the TimeCreator 1000 oscillator, impairments in performance are not expected within this default time period. The range for this parameter is 100 100000 seconds...
Page 191 Command Syntax: set cable-adv {port# | all} {auto | manual<value>} Example 1: To set the cable advance for all ports to auto - tc1000>set cable-adv all auto 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 191...
Page 192 DTI specification, in both automatic and manual modes. To make a large change in the cable advance manually, first disable the port with the Set Interface command. Related: show cable-adv Level : Power-User and Admin only 192 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 193: Show Clock
To set the leapseconds value for the IMC clock -  set clock leapseconds <value> Example 1: To set the IMC clock to a date of 2010-02-12 and time of 11:23:44 - 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 193...
Page 194: Time Zone Offsets
-11:00 -10:00 -9:00 -8:00 -7:00 -6:00 -5:00 -4:00 -3:30 -3:00 -2:00 -1:00 +0:00 +1:00 +2:00 +3:00 +4:00 +4:30 +5:00 +5:30 +6:00 +6:30 +7:00 +8:00 +9:00 +9:30 +10:00 +11:00 +12:00 194 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 195: Set Configuration
To restore the configuration to the factory values -  set configuration factory Example 1: To backup the current configuration in the same card - tc1000>set configuration backup Example 2: 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 195...
Page 196 The IOC configuration is automatically saved in the IOC one minute after a configuration setting is changed. Related: See Set commands Level : Power-User and Admin only 196 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 197 To retrieve the IOC configuration file “/home/user/imc.bak” from the remote server at IP address 192.168.3.86 - set sendconfig IOC user@192.168.3.86:/home/user/imc.bak Example 1b: To restore the IOC configuration file that was retrieved rom the remote server - 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 197...
Page 198 Appendix B Command Descriptions and Communications Interface CLI Commands set configuration restoreuser IOC Remarks: Related: Level : Power-User and Admin only 198 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 199 Remarks: If the Show Clock command and the Show DTI-Clock command time/date values are different and the unit is not in warm-up, then a "jam-sync" is probably required. Related: show clock, set clock Level : User, Power-User and Admin 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 199...
Page 200 Set Service command. h 57600 baud rate is supported only in the IMC rev H Note: version 1.00.13 or below. Related: set resource, show resource Level : User, Power-User and Admin 200 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 201 To provision the firewall to allow or block Telnet traffic -  set firewall telnet {enable|disable} To provision the firewall to allow or block SSH traffic -  set firewall ssh {enable|disable} 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 201...
Page 202 Example 2 To disable the firewall to block RADIUS traffic - tc1000> set firewall radius enable Related: show firewall Level : Power-User and Admin only 202 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 203 Appendix B Command Descriptions and Communications Interface CLI Commands Generate Message Use this command to generate all TimeCreator 1000 traps in one run, or to generate a specific trap. This command essentially acts as a trap simulator. Command Syntax: To generate all trap messages - ...
Page 204 - W121:55:34.702 Height - 13.2 Elevation Mask - 10 Position Hold State - positionHold Number of tracked: 6 ELEV AZIM Related: set gps Level : User, Power-User and Admin 204 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 205 To provision the GPS reference for manual mode and specify the position as a latitude of N37.22.45.123, longitude of W121.55.36.123, height of 17.5 meters, with a mask of 25 degrees, perform the following steps - 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 205...
Page 206 Longitude is in the format E|Wddd:mm:ss.sss, for example: W121:55:36.123 E157:33:47.456 Height is in meters with one digit after the decimal point, for example: 17.5 Mask is in degrees, for example: 15 206 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 207 Appendix B Command Descriptions and Communications Interface CLI Commands Related: show gps Level : Power-User and Admin only 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 207...
Page 208: Show Hostname
Appendix B Command Descriptions and Communications Interface CLI Commands Show Hostname This command displays the host name for the TimeCreator 1000. Command Syntax: show hostname Example: tc1000>show hostname Response: Host name - abc100 Related: set hostname Level : User, Power-User and Admin Set Hostname This command sets the host name for the TimeCreator 1000.
Page 209 Appendix B Command Descriptions and Communications Interface CLI Commands Imcdebug This command is used to initiate an IMC debugger. This is for use by Symmetricom personnel only. Not for customer use. Command Syntax: imcdebug Remarks: Related: iocdebug Level : Admin only 097-93100-01 Revision C –...
Page 210 Appendix B Command Descriptions and Communications Interface CLI Commands Iocdebug This command is used to initiate an IOC debugger. This is for use by Symmetricom personnel only. Not for customer use. Command Syntax: iocdebug Remarks: Related: imcdebug Level : Admin only 210 TimeCreator 1000 User’s Guide...
Page 211: Show Interface
|enable |..|....| |Port4 |enable |..|....| |Port5 |enable |..|....| |Port6 |enable |..|....| |Port7 |disable |..|....| |Port8 |disable |..|....| |Port9 |disable |..|....| |Port10 |disable |..|....| |PortA/11 |enable |..|....| |PortB/12 |enable --------------------------------- 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 211...
Page 212 ToD Mode: verbose Remarks: There are a total of 12 ports. Ports A/11 and B/12 have dual functionality; they can be provisioned as either DTI client or DTI server ports. 212 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 213 To enable the GPS port - tc1000>set interface state gps enable Example 2: To enable Port 5 for test mode - tc1000>set interface test-mode port 5 enable Example 3: 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 213...
Page 214 B/12 must be configured as server ports for the test signal is generated in test mode. If test mode is enabled, the test signal is generated regardless of the port enable/disable state setting. Level : Power-User and Admin only 214 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 215 This command allows you to provision the interval over which performance data is calculated for the specified type of data (P-P Jitter, MTIE-t, FER) and for the specified output ports. Command Syntax: 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 215...
Page 216 10 15 Remarks: The range is 0 to 1000. Setting the interval to 0 disables calculation of performance data. Level : Power-User and Admin only 216 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 217: Show Inventory
Remarks: The user can only modify the Asset number. Related: set inventory Level : User, Power-User and Admin Set Inventory Use this command to provision the IMC module’s user-assigned asset value information. Command Syntax: 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 217...
Page 218 Appendix B Command Descriptions and Communications Interface CLI Commands set inventory asset <string> Example: To set the asset tag for the TimeCreator 1000 to “abcdefghijklmnopqrs” - tc1000>set inventory asset abcdefghijklmnopqrs Remarks: Enter user-assigned asset value string from 1 to 20 characters. Related:...
Page 219 IMC. IOC module Command Syntax: set ioc-state [active|standby|disable][IOC1|IOC2] Example: To set the standby module IOC2 to become the active module - tc1000>set ioc-state active IOC2 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 219...
Page 220 If the module redundant cannot become the active module, the command is ignored. IOC module Related: show ioc-state Level : Power-User and Admin only 220 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 221 UP BROADCAST NOTRAILERS RUNNING MULTICAST MTU:1500 Metric:1 RX packets:2238869 errors:0 dropped:0 overruns:0 frame:0 TX packets:4798 errors:0 dropped:0 overruns:0 carrier:0 collisions:0 txqueuelen:100 RX bytes:139427807 (132.9 Mb) TX bytes:452343 (441.7 Kb) Interrupt:9 Base address:0xc000 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 221...
Page 222 IP-State to disable the interface while configuring the system. The mask is defined as an integer defining the number of 1-bits from the MSB. The rest of the bits are 0. For example a value of 24 corresponds to 255.255.255.0 222 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 223 Ethernet interface will not function. Use set ip-state {port} restart after configuring the IP interface. Related: show ip, set ip-mode, set ip-state Level : Power-User and Admin only 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 223...
Page 224 Remarks: Use Set IP-State to restart the interface after configuring the system. Related: show ip, set ip, set ip-state Level : Power-User and Admin only 224 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 225 Example 2: To restart the ETH1 inteface - tc1000>set ip-state eth1 restart Remarks: Restart disables the interface and then enables it. Related: show ip Level : Power-User and Admin only 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 225...
Page 226: Show Log
Jan 20 22:17:08 admin alarmMgr: Output Port 12 cable is disconnected Jan 20 23:21:10 admin alarmMgr: Jam sync required Jan 20 23:26:51 admin alarmMgr: Jam sync completed Related: set log Level : User, Power-User and Admin 226 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 227 Remarks: The range is 0 to 100 kilobytes. Provisioning a log file size to zero disables the logging of that type of data. Related: show log Level : Power-User and Admin 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 227...
Page 228 75 seconds - tc1000>set log-interval performance 75 Remarks: Setting the log interval to zero disables logging. The range is 10 - 86,400. Related: show log Level : Power-User and Admin only 228 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 229 This command displays a list of currently logged in users. Command Syntax: show logged-in-users Example: tc1000>show logged-in-users Response: root tts/0 Jan 22 21:52 admin pts/0 Jan 24 23:10 (192.168.7.33) Remarks: Related: Level : User, Power-User and Admin 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 229...
Page 230 Appendix B Command Descriptions and Communications Interface CLI Commands Logout This command terminates the current user connection. Command Syntax: logout Example: tc1000>logout Level : User, Power-User and Admin 230 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 231 Appendix B Command Descriptions and Communications Interface CLI Commands Show Mode This command displays the TimeCreator 1000 mode configuration, either root or subtending. Command Syntax: show mode Example: tc1000>show mode Response: Operation Mode - root Remarks: For subtending mode, this command returns "proxy". This is the term used by the SNMP MIB.
Page 232: Show Ntp
============================================================================== SYMM_TE(0) .GPS. 0.000 0.000 0.015 192.168.83.180 .STEP. 16 u - 1024 0.000 0.000 0.000 *192.168.3.98 192.168.10.44 845 1024 1.292 0.048 0.207 Level : User, Power-User and Admin 232 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 233 This command provisions which NTP servers to use, the minimum and maximum poll intervals, if the server is preferred, and key ID. This information is used when the TimeCreator 1000 is acting as an NTP client. Command Syntax: To add a new NTP server, its key ID, minimum and maximum poll intervals, and if ...
Page 234 NTP server. The key must be defined with the Set NTP-Key command. A maximum of 8 NTP servers can be specified. Level : Power-User and Admin only 234 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 235 Remarks: The NTP service must be disabled and then enabled with the Set Service command for changes to take effect. This configuration is not used in the client-server mode of NTP. Level : Power-User and Admin only 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 235...
Page 236 This command provisions NTP key ID and key string pairs. This will be used when the TimeCreator 1000 is an NTP client and also when it is an NTP server. Key ID and string pairs can be added, modified, or deleted.
Page 237 Level : User, Power-User and Admin set option This command sets the option mode and key information. The key information is printed on the Symmetricom-issued certificate for the unit. Command Syntax: set option <key> Example: To enable the snmp option with an authentication key of “ABCDEF”, tc1000>...
Page 238 Use this command to ping the host at the specified IP address and display ping statistics. Command Syntax: ping <IP-address> Example: To ping the host at the IP address 192.168.6.122: tc1000> ping 192.168.6.122 Level : User, Power-User and Admin 238 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 239 This command restarts one of the modules. Using this command can cause a loss of outputs. Command Syntax: reboot {imc|ioc1|ioc2} Example: To reboot the IOC1 module: tc1000>reboot ioc1 Remarks: Level : Admin only 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 239...
Page 240 IMC user@192.168.3.86:/home/user/imc.bak Example 1b: To restore the IMC configuration file that was retrieved rom the remote server - tc1000>set configuration restoreuser IMC Related: Level : Power-User and Admin only 240 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 241 IOC user@192.168.3.86:/home/user/imc.bak Example 1b: To restore the IOC configuration file that was retrieved rom the remote server - tc1000>set configuration restoreuser IOC Related: Level : Power-User and Admin only 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 241...
Page 242 Level : User, Power-User and Admin Set Remote-syslog This command is used to configure the remote syslog servers (maximum 8) to receive log messages from the TimeCreator 1000. Command Syntax: To add a new remote syslog server:  set remote-syslog add <hostaddr>...
Page 243 Appendix B Command Descriptions and Communications Interface CLI Commands To delete all remote syslog servers: tc1000>set remote-syslog delete all Related: show remote-syslog Level : Power-User and Admin only 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 243...
Page 244 Port 09 rapid recovery mode: disabled Port 10 rapid recovery mode: disabled Port 11 rapid recovery mode: disabled Port 12 rapid recovery mode: disabled Related: Level : User, Power-User and Admin 244 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 245 Port 09 recovery capability status: No Port 10 recovery capability status: No Port 11 recovery capability status: No Port 12 recovery capability status: No Related: Level : User, Power-User and Admin 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 245...
Page 246 This command is used to enable or disable the auto recovery mode (a global setting) for root server recovery, or to abort the root server recovery process. Note: This command is only applicable for a TimeCreator 1000 that is OD Source mode of USER...
Page 247 (1 through 12). Note: This command is only applicable for a TimeCreator 1000 that is being used as a root server.
Page 248 Example: To save the IMC configuration file “ to a remote server at IP /home/user/imc.bak” address 192.168.3.86 - set sendconfig IMC user@192.168.3.86:/home/user/imc.bak Related: Level : Power-User and Admin only 248 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 249 Example: To save the IOC configuration file “ to a remote server at IP /home/user/ioc.bak” address 192.168.3.86 - set sendconfig IOC user@192.168.3.86:/home/user/ioc.bak Related: Level : Power-User and Admin only 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 249...
Page 250: Show Services
Appendix B Command Descriptions and Communications Interface CLI Commands Show Services This command displays all TimeCreator 1000 service states. Command Syntax: show services Example: tc1000>show services Reponse: Service States: eia-232 - enable telnet - enable - enable - enable snmp...
Page 251 Remarks: Services include EIA-232, Telnet, FTP, SSH, NTP, Syslog, and SNMP. Level : Power-User and Admin only Note: The command also includes the capability of controlling the syslog service. Disabling this service is not recommended. 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 251...
Page 252: Show Snmp
(read only user) v3user4 noauth (read only user) Total 4 SNMPv3 user(s) Example 2: >show snmp trap Response 2: SNMP trap sinks: Host: 192.168.3.44 SNMPv2 trap community: rouser 252 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 253: Set Snmp
SNMPv3 users can provisioned as one of three security levels: Private, Author, and Non Author. SNMPv3 users can be provisioned as one of two access levels: read-only and read-write. The following figure shows the hierarchy for the command: set snmp 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 253...
Page 254 Use this command to add an SNMP trap destination at the specified IP address  and port, if desired. set snmp trap add <trap destination IP-address>[:<port#>][<SNMPv3 user>| <SNMPv2 rocommunity-name>|<SNMPv2 rwcommunity-name>|public] 254 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 255 The user will then be prompted for the privacy protocol - Privacy protocol (DES, AES): - and privacy key. Privacy key: Response 1: Disabling snmpd service: Enabling snmpd service: 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 255...
Page 256 To create a read-only SNMPv2 community with the default name of “public”: tc1000> set snmp accessv2 rocommunity Example 7: To create a read-write SNMPv2 community named “v2rwcommunity2”: tc1000> set snmp accessv2 rwcommunity v2rwcommunity2 256 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 257 Appendix B Command Descriptions and Communications Interface CLI Commands Related: show snmp Level : Admin only 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 257...
Page 258: Show Statistics
Level : User, Power-User and Admin Clear Statistics This command clears all statistics. Command Syntax: clear statistics Example: tc1000>clear statistics Related: show statistics Level : Power-User and Admin only 258 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 259: Show Status
Clock operating mode for the IOC  Assigned System Name and asset tag  Command Syntax: show status Example: tc1000>show status Related: show alarms Level : User, Power-User and Admin 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 259...
Page 260 The value entered by Level 1 or Level 2 users will only apply to the session in which the command was entered. Level : Power-User and Admin only 260 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 261 Related: sync tod-source, show tod-source Level : Power-User and Admin only Note: If the system has passed the warm up state, the Sync TOD-Source command is also required. 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 261...
Page 262 Example 2: To jam sync on March 23, 2011 at exactly 12:30 pm: tc1000>sync tod-source 2011-03-23 12:30:00 Related: set tod-source, show tod-source Level : Power-User and Admin only 262 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 263 CLI Commands Unlockcli This command is used to release a CLI lock. The TimeCreator 1000 can support up to 5 Telnet sessions, with commands being executed on a first-in/first-out (FIFO) basis. In the event that a command from a session cannot be fully executed, other CLI users are essentialy locked out.
Page 264 To upgrade IOC1 with the file “ver2.bin”, which is located at server IP address 192.168.5.64, via FTP, and then to auto-reboot IOC1 afterwards: tc1000>upgrade ioc1 ver2.bin 192.168.5.64 ftp auto-reboot Level : Admin only 264 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 265: Show User
A maximum of 30 users can be specified. set user add Use this command to delete a user from the access list.  set user del <username> 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 265...
Page 266 Remarks: The password is not echoed back to the user’s terminal. Related: show user Level : User and Power-User (change password only) Admin (add, delete, modify, and unlock users, plus create password) 266 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 267 Use this command to set the whitelist to default conditions, where all IP  addresses are allowed access: set whitelist default Example 1: To add the IP address 192.168.5.10 to the whitelist: 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 267...
Page 268: Simple Network Management Protocol
To delete the IP address 192.168.5.10 from the whitelist: tc1000>set whitelist delete 192.168.5.10 tc1000>set whitelist commit Note: Symmetricom recommends that the IP address of the administrator station always be added to the whitelist first. This will prevent an accidental lockout of the administrator via Telnet/SSH.
Page 269: Snmp Features
TimeCreator 1000, its modules, module features, input ports, output ports, etc. and variables that include settings and measurements. The MIB is controlled by the TimeCreator 1000’s SNMP agent. The SNMP agent is a server program that sends TimeCreator 1000 status (stored in the MIB database) to the network manager when the manager transmits GET or GETNEXT messages.
Page 270 Use the following command to add user ABC with the 20 character MD5 authentication key 123456789ABCDEFGHIJK and 16 DES character privacy key 123456789ABCDEFG. Type and press set snmp accessv3 add abc SecureLvl priv AccessLvl rw Enter. 270 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 271: Network Time Protocol
Network Time Protocol Network Time Protocol (NTP) is used to synchronize system clocks to a common time source by transmitting and receiving time of day over a TCP/IP network. 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 271...
Page 272: Server Mode
Appendix B Command Descriptions and Communications Interface Secure Shell Protocol The TimeCreator 1000 implements NTPv4, and supports the NTP v.3 (RFC 1305) version. It can run as a server application and a client application. The NTP server always runs and the client is enabled independently.
Page 273: Appendix C Installing The Two-Way Gps Antenna
Appendix C Installing the Two-Way GPS Antenna This document describes the procedures for installing the Symmetricom Two-Way GPS antenna and the Two-Way Antenna Interface. In This Appendix Tools  Parts  Making GPS Connections  097-93100-01 Revision C – February, 2010...
Page 274: Tools
RG-58 cable, 500 ft. (150 m) 154-00023-01 Crimp tool for RG-58 cable 371-001 TNC connectors for RG-58 cable Note: Kit includes GPS antenna and mounting hardware. Order antenna cables separately 274 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 275: Making Gps Connections
985 feet (300 m). The minimum cable length is 6.6 feet (2 m). The GPS Antenna should always be as close to the TimeCreator 1000 as practical. 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 275...
Page 276 You can order two lengths of cable: one connecting the antenna to the lightning suppressor and one from the suppressor to the TimeCreator 1000. Or you can order one length of cable; you need to cut the cable and terminate it properly, using your own tools.
Page 277: Antenna-To-Device Cabling
C-3. Slide the two V-bolts over the pipe, and through the mounting bracket slots; then place the provided four washers and four nuts over the V-bolts, against the mounting bracket. Leave the V-bolts loose enough to allow for final adjustments. 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 277...
Page 278: Installing The Antenna Bracket On A Pipe
4. Feed an RG58 (060-58545-xx) cable through the bottom of the mast as illustrated. See Table C-1 for specific cable lengths. 5. Connect the cable to the antenna “pigtail” and pull the cable back through the mast. 278 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 279: Attaching The Antenna To The Bracket
15 feet (4.6 m) of the chosen valid earth ground. A minimum 30-foot (9 m) bend radius is required when installing the ground wire. If the mounting plate is to be 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 279...
Page 280: Assembling The Lightning Suppressor
13.If the lightning suppressor is not mounted directly to a valid earth ground, crimp a length of 4.115 mm (6 AWG) ground cable to the two-hole terminal, slide the 280 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 281 15.Install fire-stopping material in all holes opened in the roof and/or walls during this procedure. 16.Check all connections for tightness to prevent arcing and intermittent operation. 17.Coat all exposed connectors with an electrically conductive antioxidant compound (e.g. Kopr-Shield spray). 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 281...
Page 282 Appendix C Installing the Two-Way GPS Antenna Making GPS Connections 282 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 283: Appendix D Specifications And Factory Defaults
Appendix D Specifications and Factory Defaults This appendix provides mechanical and electrical specifications and factory defaults for the TimeCreator 1000. In This Appendix Specifications  Factory Defaults  097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 283...
Page 284: Specifications
Appendix D Specifications and Factory Defaults Specifications Specifications This section provides the specifications for the TimeCreator 1000 components and input and output signals. Mechanical Table D-1. TimeCreator 1000 Mechanical Specifications Parameter Description Mounting 19 in. Rack Rack Mounting Front mounting location, unit protrudes 0.75 in.
Page 285: Power
Appendix D Specifications and Factory Defaults Specifications Power Table D-3. TimeCreator 1000 Power Specifications Parameter Description AC Input Power 100-240 V AC at 50/60 Hz. AC Power Fuse 2 A (2 each) AC Power 40 W DC Input Power –36 V DC to –72 V DC –48 V DC, 2.7 A (maximum)
Page 286: Lan Port
100 ohms Amplitude 2.2Vpp to 2.8Vpp Data Rate 5.12 Mbps Output Signals Table D-7. Output Signal Specifications Parameter Specification Termination Impedance 100 Amplitude 2.2Vpp to 2.8Vpp Data Rate 5.12 Mbps 286 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 287: Roof Antenna
Connector type 50  / 75  Impedance Factory Defaults This section provides the factory defaults for the TimeCreator 1000 GPS and DTI port parameters, IMC and communications parameters, and alarm parameters. Table D-9. GPS and DTI Port Parameters Description...
Page 288: Imc And Communication Parameters
Enable | Disable SYSLOG Service Enable Enable | Disable User #1 Access level 1 | 2 | 3 User #1 UserName admin User #1 Password SymmTC1000 Eth0 IP mode Static Static|DHCP 288 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 289 Valid IPv4 Host Address Address TACACS+ Server key Maximum of 32 ASCII characters Local Alarm Log Buffer Size 0 to 100 kbytes Local Event Log Buffer Size 0 to 100 kbytes 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 289...
Page 290: Alarm Default Values
Port 1 thru 12 – MTIE-t Clear Threshold (pS) 7000 0 = Disable, 5000 to 10000000 Note: For 8-port IOC module option, these parameters apply to Ports 1 thru 6, Port 11, and Port 12 290 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 291 Europe, Middle East & Africa: 49 700 32886435  An administrative fee may be charged to obtain the source code. By using the TimeCreator 1000, the user agrees to the terms of these licenses. In This Appendix Third-Party Software ...
Page 292: Timecreator 1000 User's Guide 097-93100-01 Revision C – February
 iproute-20030805  iptables-1.2.9  iputils-tracepath-20020124  kernel-2.4.20_dev  less-358  libpam-0.72  libpam-cracklib-0.72  libpam-dev-0.72  libpam-modules-0.72  libpam-runtime-0.72  linux-ftpd-0.17  linuxinfo-1.1.7  logrotate-3.5.7  ltrace-0.3.10  292 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 293  openssh-server-4.2p2  openssl-0.9.7b  pam_radius_license-1.3.16  pam_tacplus-1.2.9  pam_tally-0.1  pciutils-2.1.8  rpm-4.1  setserial-2.17  shellutils-2.0.11  sudo-1.6.7p3  sysklogd-1.4.1  sysvinit-2.78  util-linux-2.11h  xinetd-2.3.3  097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 293...
Page 294 Appendix E Software Licenses Third-Party Software 294 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 295: Index
IP address DHCP mode enable cable advance DOCSIS Timing Interface (DTI) cables documentation, related antenna to shelf lightning suppressor cautions defined CLI Commands 178–266 CLI protocol clock frame master 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 295...
Page 296 31, local area network (LAN) reference provisioning connecting to reference signal connector log files root server operation 86, DTI client status setting satellite parameters Time of Day 296 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...
Page 297 CLI command manager 253, product overview, TimeCreator 1000 manager IP address protocol security level state SNMP trap user provisioning trap version alarms user non-revertive mode v2 community revertive mode 097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 297...
Page 298 Time of Day (TOD) warnings defined Time of Day, setting web address timestamp whitelist 78, DTI 26, 27, 31, 35, 86, whitelist commands timing antenna, installing 275–281 298 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010...

Symmetricom TimeCreator 1000 User Manual

Table of Contents

Figures

Chapter 1 Overview of the Timecreator

Chapter 2 Engineering and Ordering Procedures

Chapter 3 Installing the Timecreator

Chapter 4 General Guidelines for Using the Symmetricom Timecreator

Chapter 5 Provisioning

Chapter 6 Maintenance and Troubleshooting

Appendix A Alarms, Events and SNMP Traps

Appendix B Command Descriptions and

Appendix C Installing the Two-Way GPS Antenna

Appendix D Specifications and Factory Defaults

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for Symmetricom TimeCreator 1000

Summary of Contents for Symmetricom TimeCreator 1000
