Signals - ABB REC650 ANSI Technical Manual

Section 10
Control
10.3.2.4
250

Signals

Table 176: SCSWI Input signals
Name Type
BLOCK BOOLEAN
PSTO INTEGER
L_SEL BOOLEAN
L_OPEN BOOLEAN
L_CLOSE BOOLEAN
AU_OPEN BOOLEAN
AU_CLOSE BOOLEAN
BL_CMD BOOLEAN
RES_EXT BOOLEAN
SY_INPRO BOOLEAN
SYNC_OK BOOLEAN
EN_OPEN BOOLEAN
EN_CLOSE BOOLEAN
XPOS GROUP
SIGNAL
Table 177: SCSWI Output signals
Name Type
EXE_OP BOOLEAN
EXE_CL BOOLEAN
SELECTED BOOLEAN
START_SY BOOLEAN
POSITION INTEGER
OPENPOS BOOLEAN
CLOSEPOS BOOLEAN
CMD_BLK BOOLEAN
L_CAUSE INTEGER
POS_INTR BOOLEAN
XOUT BOOLEAN
Default Description
0 Block of function
2 Operator place selection
0 Select signal from local panel
0 Open signal from local panel
0 Close signal from local panel
0 Used for local automation function
0 Used for local automation function
0 Steady signal for block of the command
0 Reservation is made externally
0 Synchronizing function in progress
0 Closing is permitted by the synchronism-check
0 Enables open operation
0 Enables close operation
- Group signal from XCBR/XSWI
Description
Execute Open command
Execute Close command
Select conditions are fulfilled
Starts the synchronizing function
Position indication
Open position indication
Closed position indication
Commands are blocked
Latest value of the error indication during command
Stopped in intermediate position
Execution information to XCBR/XSWI
