  • Page 1 ® Relion 670 series Bay control REC670 Pre-configured Product Guide...

  • Page 2: Table Of Contents

    11. Logic................15 Disclaimer The information in this document is subject to change without notice and should not be construed as a commitment by ABB. ABB assumes no responsibility for any errors that may appear in this document. © Copyright 2012 ABB.

  • Page 3: Application

    Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Issued: February 2015 Revision: E 1. Application with the multi-display local HMI allows use as multi feeder REC670 is used for the control, protection and monitoring of protection and controller for distribution buses. different types of bays in power networks.

  • Page 4: Available Functions

    Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 2. Available functions Main protection functions = number of basic instances 3-A03 = optional function included in packages A03 (refer to ordering details) IEC 61850 ANSI Function description Bay control Differential protection HZPDIF 1Ph high impedance differential protection 3-A02...

  • Page 5: Current Protection

    Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Back-up protection functions IEC 61850 ANSI Function description Bay control Current protection PHPIOC Instantaneous phase overcurrent protection 1-C31 2-C32 2-C33 OC4PTOC 51_67 Four step phase overcurrent protection 1-C31 2-C32 2-C33 EFPIOC Instantaneous residual overcurrent protection 1-C31 2-C32...

  • Page 6: Secondary System Supervision

    Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Control and monitoring functions IEC 61850 ANSI Function description Bay control Control SESRSYN Synchrocheck, energizing check and synchronizing SMBRREC Autorecloser 1-H04 2-H05 3-H06 APC8 Apparatus control for single bay, max 8 apparatuses (1CB) incl. interlocking APC15 Apparatus control for single bay, max 15 apparatuses (2CBs) incl.

  • Page 7: Monitoring

    Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 IEC 61850 ANSI Function description Bay control Extension logic package FixedSignals Fixed signal function block B16I Boolean 16 to Integer conversion B16IFCVI Boolean 16 to Integer conversion with Logic Node representation IB16 Integer to Boolean 16 conversion IB16FCVB...
  • Page 8 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Designed to communicate IEC 61850 ANSI Function description Bay control Station communication SPA communication protocol LON communication protocol IEC60870-5-103 communication protocol 20/1 20/1 20/1 Operation selection between SPA and IEC60870-5-103 for SLM DNP3.0 for TCP/IP and EIA-485 communication protocol DNP3.0 fault records for TCP/IP and EIA-485 communication protocol Parameter setting function for IEC61850...

  • Page 9: Basic Ied Functions

    Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Basic IED functions IEC 61850 Function description Basic functions included in all products IntErrorSig Self supervision with internal event list TIME Time and synchronization error TimeSynch Time synchronization ActiveGroup Parameter setting groups Test Test mode functionality ChangeLock...
  • Page 10 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 EF4PTOC can be configured to measure the residual current Four step phase overcurrent protection OC4PTOC from the three-phase current inputs or the current from a The four step phase overcurrent protection function separate current input.
  • Page 11 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Normally the own breaker is tripped to correct such a The three-phase current measuring protection has an I situation. If the situation persists the surrounding breakers characteristic with settable time constant and a thermal should be tripped to clear the unsymmetrical load situation.
  • Page 12 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 SAPTOF is used mainly for generation shedding and remedial Two step residual overvoltage protection ROV2PTOV action schemes. It is also used as a frequency stage initiating Residual voltages may occur in the power system during load restoring.
  • Page 13 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 with the neutral point current on a separate input taken from SESRSYN function includes a built-in voltage selection another set of cores on the current transformer. scheme for double bus and 1½ breaker or ring busbar arrangements.
  • Page 14 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 In normal security, the command is processed and the require exchange of information between the parallel resulting position is not supervised. However with enhanced transformers and this is provided for within IEC61850-8-1. security, the command is processed and the resulting Voltage control includes many extra features such as position is supervised.
  • Page 15 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 In the directional scheme, information of the fault current Single command, 16 signals direction must be transmitted to the other line end. With The IEDs can receive commands either from a substation directional comparison, a short operate time of the protection automation system or from the local HMI.
  • Page 16 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 12. Monitoring Trip matrix logic TMAGGIO Trip matrix logic TMAGGIO function is used to route trip Measurements CVMMXN, CMMXU, VNMMXU, VMMXU, signals and other logical output signals to different output CMSQI, VMSQI contacts on the IED.
  • Page 17 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 A disturbance is defined as an activation of an input to the Trip value recorder DRPRDRE AxRADR or BxRBDR function blocks, which are set to trigger Information about the pre-fault and fault values for currents the disturbance recorder.

  • Page 18: Human Machine Interface

    Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 signal to other systems or equipment in the substation. It can Function for energy calculation and demand handling also be used inside the same IED, to attach a RANGE aspect ETPMMTR to an analog value and to permit measurement supervision on Outputs from the Measurements (CVMMXN) function can be that value.

  • Page 19: Station Communication

    SPA communication protocol signals only, up to 192 binary signals can be exchanged A single glass or plastic port is provided for the ABB SPA between two IEDs. For example, this functionality can be protocol. This allows extensions of simple substation...

  • Page 20: Hardware Description

    Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 18. Hardware description plastic, plastic/glass or glass/glass. One port is used for serial communication (SPA, IEC 60870-5-103 and DNP3 port or Hardware modules dedicated IEC 60870-5-103 port depending on ordered SLM Power supply module PSM module) and one port is dedicated for LON communication.
  • Page 21 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 xx05000003.vsd IEC05000003 V1 EN Figure 2. 1/2 x 19” case with rear cover xx05000004.vsd IEC05000004 V1 EN Figure 3. Side-by-side mounting Case size 6U, 1/2 x 19” 265.9 223.7 201.1 242.1 252.9 205.7 6U, 3/4 x 19”...

  • Page 22: Connection Diagrams

    Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 19. Connection diagrams Table 1. Designations for 1/2 x 19” casing with 1 TRM slot Module Rear Positions BIM, BOM, SOM, IOM or X31 and X32 etc. to X51 and X52 X301:A, B, C, D LDCM, IRIG-B or RS485 X302...
  • Page 23 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 3. Designations for 3/4 x 19” casing with 2 TRM slot Module Rear Positions BIM, BOM, SOM, IOM or X31 and X32 etc. to X71 and X301:A, B, C, D LDCM, IRIG-B or RS485 X302 LDCM or RS485...
  • Page 24 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 5. Designations for 1/1 x 19” casing with 2 TRM slots Module Rear Positions BIM, BOM, SOM, X31 and X32 etc. to X131 IOM or MIM and X132 X301:A, B, C, D LDCM, IRIG-B or X302 RS485...
  • Page 25 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 1MRK002801-AC-10-670-1.2-PG V1 EN Figure 4. Transformer input module (TRM) ￭ Indicates high polarity CT/VT-input designation according to figure AI01 AI02 AI03 AI04 AI05 AI06 AI07 AI08 AI09 AI10 AI11 AI12 12I, 1A 12I, 5A 9I+3U, 1A 110-220V...
  • Page 26 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 1MRK002801-AC-15-670-1.2-PG V1 EN Figure 6. mA input module (MIM) 1MRK002801-AC-11-670-1.2-PG V1 EN Figure 5. Binary input module (BIM). Input contacts named XA corresponds to rear position X31, X41, and so on, and input contacts named XB to rear position X32, X42, and so on.
  • Page 27 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 1MRK002801-AC-7-670-1.2-PG V1 EN Figure 8. Power supply module (PSM) 1MRK002801-AC-12-670-1.2-PG V1 EN Figure 9. Binary output module (BOM). Output contacts named XA corresponds to rear position X31, X41, and so on, and output contacts named XB to rear position X32, X42, and so on.
  • Page 28 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 1MRK002801-AC-13-670-1.2-PG V1 EN Figure 10. Static output module (SOM) 1MRK002801-AC-14-670-1.2-PG V1 EN Figure 11. Binary in/out module (IOM). Input contacts named XA corresponds to rear position X31, X41, and so on, and output contacts named XB to rear position X32, X42, and so on.

  • Page 29: Technical Data

    Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 20. Technical data General Definitions Reference value The specified value of an influencing factor to which are referred the characteristics of the equipment Nominal range The range of values of an influencing quantity (factor) within which, under specified conditions, the equipment meets the specified requirements Operative range The range of values of a given energizing quantity for which the equipment, under specified conditions, is able to perform its...
  • Page 30 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 7. TRM - Energizing quantities, rated values and limits for measuring transformer modules Quantity Rated value Nominal range Current = 1 or 5 A (0-1.8) × I at I = 1 A (0-1.6) ×...
  • Page 31 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Binary inputs and outputs Table 11. BIM - Binary input module Quantity Rated value Nominal range Binary inputs DC voltage, RL 24/30 V RL ± 20% 48/60 V RL ± 20% 110/125 V RL ±...
  • Page 32 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 13. IOM - Binary input/output module Quantity Rated value Nominal range Binary inputs DC voltage, RL 24/30 V RL ± 20% 48/60 V RL ± 20% 110/125 V RL ± 20% 220/250 V RL ±...
  • Page 33 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 15. IOM with MOV and IOM 220/250 V, 110mA - contact data (reference standard: IEC 61810-2) Function or quantity Trip and Signal relays Fast signal relays (parallel reed relay) Binary outputs IOM: 10 IOM: 2 Max system voltage...
  • Page 34 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 17. SOM - Static Output module data (reference standard: IEC 61810-2): Electromechanical relay outputs Function of quantity Trip and signal relays Max system voltage 250V AC/DC Number of outputs Test voltage across open contact, 1 min 1000V rms Current carrying capacity: Continuous...
  • Page 35 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 20. Auxiliary DC supply voltage influence on functionality during operation Dependence on Reference value Within nominal Influence range Ripple, in DC auxiliary voltage max. 2% 15% of EL 0.01% /% Operative range Full wave rectified Auxiliary voltage dependence, operate...
  • Page 36 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Type tests according to standards Table 22. Electromagnetic compatibility Test Type test values Reference standards 1 MHz burst disturbance 2.5 kV IEC 60255-22-1 100 kHz slow damped oscillatory wave immunity test 2.5 kV IEC 61000-4-18, Class III Ring wave immunity test, 100 kHz...
  • Page 37 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 24. Environmental tests Test Type test value Reference standard Cold test Test Ad for 16 h at -25°C IEC 60068-2-1 Storage test Test Ad for 16 h at -40°C IEC 60068-2-1 Dry heat test Test Bd for 16 h at +70°C IEC 60068-2-2...
  • Page 38 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Differential protection Table 27. 1Ph High impedance differential protection HZPDIF Function Range or value Accuracy Operate voltage (20-400) V ± 1.0% of I I=U/R Reset ratio >95% Maximum continuous power U>Trip /SeriesResistor ≤200 W Operate time 10 ms typically at 0 to 10 x U...
  • Page 39 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Current protection Table 28. Instantaneous phase overcurrent protection PHPIOC Function Range or value Accuracy Operate current (1-2500)% of lBase ± 1.0% of I at I £ I ± 1.0% of I at I > I Reset ratio >...
  • Page 40 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 30. Instantaneous residual overcurrent protection EFPIOC Function Range or value Accuracy Operate current (1-2500)% of lBase ± 1.0% of I at I £ I ± 1.0% of I at I > I Reset ratio >...
  • Page 41 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 32. Four step negative sequence overcurrent protection NS4PTOC Function Range or value Accuracy Operate value, negative (1-2500)% of lBase ± 1.0% of I at I £ I sequence current, step 1-4 ±...
  • Page 42 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 33. Sensitive directional residual overcurrent and power protection SDEPSDE Function Range or value Accuracy Operate level for 3I ·cosj (0.25-200.00)% of lBase ± 1.0% of I at I £ I directional residual ±...
  • Page 43 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 33. Sensitive directional residual overcurrent and power protection SDEPSDE, continued Function Range or value Accuracy Reset time, non-directional 60 ms typically at 2 to 0 x I residual over current Operate time, start function 150 ms typically at 0 to 2 x I Reset time, start function...
  • Page 44 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 36. Breaker failure protection CCRBRF Function Range or value Accuracy Operate phase current (5-200)% of lBase ± 1.0% of I at I £ I ± 1.0% of I at I > I Reset ratio, phase current >...
  • Page 45 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 40. Broken conductor check BRCPTOC Function Range or value Accuracy Minimum phase current for operation (5–100)% of IBase ± 0.1% of I Unbalance current operation (0–100)% of maximum current ± 0.1% of I Timer (0.00-6000.00) s ±...
  • Page 46 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Voltage protection Table 41. Two step undervoltage protection UV2PTUV Function Range or value Accuracy UBase Operate voltage, low and high step (1–100)% of ± 0.5% of U UBase Absolute hysteresis (0–100)% of ±...
  • Page 47 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 43. Two step residual overvoltage protection ROV2PTOV Function Range or value Accuracy Operate voltage, step 1 and step 2 (1-200)% of UBase ± 0.5% of U at U < U ±...
  • Page 48 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Frequency protection Table 46. Underfrequency protection SAPTUF Function Range or value Accuracy Operate value, start function (35.00-75.00) Hz ± 2.0 mHz Operate time, start function 100 ms typically Reset time, start function 100 ms typically Operate time, definite time function (0.000-60.000)s...
  • Page 49 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Multipurpose protection Table 49. General current and voltage protection CVGAPC Function Range or value Accuracy Measuring current input phase1, phase2, phase3, PosSeq, NegSeq, 3*ZeroSeq, MaxPh, MinPh, UnbalancePh, phase1-phase2, phase2- phase3, phase3-phase1, MaxPh-Ph, MinPh-Ph, UnbalancePh-Ph Base current (1 - 99999) A...
  • Page 50 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 49. General current and voltage protection CVGAPC , continued Function Range or value Accuracy Relay characteristic angle (-180 to +180) degrees ± 2.0 degrees Relay operate angle (1 to 90) degrees ±...
  • Page 51 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Secondary system supervision Table 50. Current circuit supervision CCSRDIF Function Range or value Accuracy Operate current (5-200)% of I ± 10.0% of I at I £ I ± 10.0% of I at I > I Block current (5-500)% of I ±...
  • Page 52 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Control Table 52. Synchronizing, synchrocheck and energizing check SESRSYN Function Range or value Accuracy Phase shift, j (-180 to 180) degrees line Voltage ratio, U 0.500 - 2.000 line UBaseBus and Voltage high limit for synchronizing and synchrocheck (50.0-120.0)% of ±...
  • Page 53 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 53. Autorecloser SMBRREC Function Range or value Accuracy Number of autoreclosing shots 1 - 5 Autoreclosing open time: shot 1 - t1 1Ph (0.000-60.000) s ± 0.5% ± 10 ms shot 1 - t1 2Ph shot 1 - t1 3PhHS shot 1 - t1 3PhDld...
  • Page 54 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 54. Voltage control TR1ATCC, TR8ATCC, TCMYLTC and TLCYLTC Function Range or value Accuracy Transformer reactance (0.1–200.0)Ω, primary Time delay for lower command when fast step down mode is activated (1.0–100.0) s Voltage control set voltage (85.0–120.0)% of UB ±0.25% of U...
  • Page 55 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Scheme communication Table 55. Scheme communication logic for distance or overcurrent protection ZCPSCH Function Range or value Accuracy Scheme type Intertrip Permissive Underreach Permissive Overreach Blocking Co-ordination time for blocking (0.000-60.000) s ±...
  • Page 56 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 58. Current reversal and weak-end infeed logic for residual overcurrent protection ECRWPSCH Function Range or value Accuracy Operating mode of WEI logic Echo Echo & Trip Operate voltage 3U for WEI trip (5-70)% of UBase ±...
  • Page 57 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Logic Table 59. Tripping logic SMPPTRC Function Range or value Accuracy Trip action 3-ph, 1/3-ph, 1/2/3-ph Minimum trip pulse length (0.000-60.000) s ± 0.5% ± 10 ms Timers (0.000-60.000) s ± 0.5% ± 10 ms Table 60.
  • Page 58 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 61. Extension logic package Logic block Quantity with cycle time Range or value Accuracy fast medium normal LogicAND LogicXOR LogicSRMemory LogicTimer (0.000–90000.000) s ± 0.5% ± 10 ms LogicPulseTimer (0.000–90000.000) s ±...
  • Page 59 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Monitoring Table 62. Measurements CVMMXN Function Range or value Accuracy Frequency (0.95-1.05) × f ± 2.0 mHz Voltage (0.1-1.5) ×U ± 0.5% of U at U£U ± 0.5% of U at U > U Connected current (0.2-4.0) ×...
  • Page 60 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 66. Current sequence component measurement CMSQI Function Range or value Accuracy Current positive sequence, I1 (0.1–4.0) × I ± 0.2% of I at I ≤ 0.5 × I Three phase settings ±...
  • Page 61 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 70. Disturbance report DRPRDRE Function Range or value Accuracy Pre-fault time (0.05–9.90) s Post-fault time (0.1–10.0) s Limit time (0.5–10.0) s Maximum number of recordings 100, first in - first out Time tagging resolution 1 ms See table...
  • Page 62 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 74. Event recorder Function Value Buffer capacity Maximum number of events in disturbance report Maximum number of disturbance reports Resolution 1 ms Accuracy Depending on time synchronizing Table 75. Trip value recorder Function Value Buffer capacity...
  • Page 63 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Metering Table 77. Pulse counter PCGGIO Function Setting range Accuracy Input frequency See Binary Input Module (BIM) Cycle time for report of counter (1–3600) s value Table 78. Energy metering ETPMMTR Function Range or value Accuracy...
  • Page 64 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Station communication Table 79. IEC 61850-8-1 communication protocol Function Value Protocol IEC 61850-8-1 Communication speed for the IEDs 100BASE-FX Protocol IEC 608–5–103 Communication speed for the IEDs 9600 or 19200 Bd Protocol DNP3.0 Communication speed for the IEDs...
  • Page 65 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 84. SLM – SPA/IEC 60870-5-103/DNP3 port Quantity Range or value Optical connector Glass fibre: type ST Plastic fibre: type HFBR snap-in Fibre, optical budget Glass fibre: 11 dB (3000ft/1000 m typically *) Plastic fibre: 7 dB (80ft/25 m typically *) Fibre diameter Glass fibre: 62.5/125 mm...
  • Page 66 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Remote communication Table 87. Line data communication module Characteristic Range or value Type of LDCM Short range (SR) Medium range (MR) Long range (LR) Type of fibre Graded-index Singlemode 9/125 µm Singlemode 9/125 µm multimode 62.5/125 µm or...
  • Page 67 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Hardware Table 88. Case Material Steel sheet Front plate Steel sheet profile with cut-out for HMI Surface treatment Aluzink preplated steel Finish Light grey (RAL 7035) Table 89. Water and dust protection level according to IEC 60529 Front IP40 (IP54 with sealing strip) Sides, top and bottom...
  • Page 68 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Basic IED functions Table 93. Self supervision with internal event list Data Value Recording manner Continuous, event controlled List size 40 events, first in-first out Table 94. Time synchronization, time tagging Function Value Time tagging resolution, events and sampled measurement values...
  • Page 69 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 97. IRIG-B Quantity Rated value Number of channels IRIG-B Number of channels PPS Electrical connector: Electrical connector IRIG-B Pulse-width modulated 5 Vpp Amplitude modulated – low level 1-3 Vpp – high level 3 x low level, max 9 Vpp Supported formats IRIG-B 00x, IRIG-B 12x...
  • Page 70 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Inverse characteristic Table 98. ANSI Inverse time characteristics Function Range or value Accuracy Operating characteristic: k = (0.05-999) in steps of 0.01 æ ö ç ÷ × ç ÷ è ø EQUATION1249-SMALL V1 EN Reset characteristic: ×...
  • Page 71 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 99. IEC Inverse time characteristics Function Range or value Accuracy Operating characteristic: k = (0.05-999) in steps of 0.01 æ ö ç ÷ × ç ÷ è ø EQUATION1251-SMALL V1 EN I = I measured Time delay to reset, IEC inverse time...
  • Page 72 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 101. Inverse time characteristics for overvoltage protection Function Range or value Accuracy Type A curve: k = (0.05-1.10) in steps of 0.01 5% +40 ms æ ö > ç ÷ è...
  • Page 73 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 102. Inverse time characteristics for undervoltage protection Function Range or value Accuracy Type A curve: k = (0.05-1.10) in steps of 0.01 5% +40 ms æ ö < - ç ÷...
  • Page 74 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Table 103. Inverse time characteristics for residual overvoltage protection Function Range or value Accuracy Type A curve: k = (0.05-1.10) in steps of 5% +40 ms 0.01 æ ö > ç ÷...

  • Page 75: Ordering

    - 11 - 12 SOFTWARE Notes and Rules Version number Version no Selection for position #1. Configuration alternatives Notes and Rules Single breaker Double breaker 1 1/2 Breaker for individual CB ACT configuration ABB standard configuration Selection for position #2.
  • Page 76 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Software options Notes and Rules No option All fields in the ordering form do not need to be filled in High impedance differential protections Note: A02 only in A30/B30, A07 only in C30 High impedance differential protections - 2 zones Sensitive directional residual overcurrent and power protection Directional power protection...
  • Page 77 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Casing Notes and Rules 1/2 x 19" case 3/4 x 19" case 1 TRM slot 3/4 x 19" case 2 TRM slots 1/1 x 19" case 1TRM slots 1/1 x 19" case 2 TRM slots Selection for position #5.
  • Page 78 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Binary input/output module, mA and time synchronizating Notes and Rules boards. Note: 1BIM and 1 BOM included. Make BIM with 50 mA inrush current the primary choice. BIM with 50 mA inrush current fulfill additional standards. As a consequence the EMC withstand capability is further increased.
  • Page 79 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Remote end communication, DNP serial comm. and time synchronization modules Notes and Rules Slot position (rear view) Available slots in 1/2 case with 1 TRM █ █ █ █ Note: Max 1 LDCM in 1/2 case Available slots in 3/4 &...
  • Page 80 Multi-breaker/Single or Three Phase trip with external neutral 001024-CA. Please refer to the website: on current circuit (ordering number RK926 315-BV). www.abb.com/substationautomation for detailed information. The normally open "In test mode" contact 29-30 on the RTXP Due to the high flexibility of our product and the wide variety...
  • Page 81 Bay control REC670 1MRK511232-BEN E Pre-configured Product version: 1.2 Configuration and monitoring tools Front connection cable between LCD-HMI and PC Quantity: 1MRK 001 665-CA LED Label special paper A4, 1 pc Quantity: 1MRK 002 038-CA LED Label special paper Letter, 1 pc Quantity: 1MRK 002 038-DA Manuals...
  • Page 82 670 series SPA and signal list 1MRK 500 092-WEN IEC 61850 Data objects list for 670 series 1MRK 500 091-WEN Engineering manual 670 series 1MRK 511 240-UEN Communication set-up for Relion 670 series 1MRK 505 260-UEN More information can be found on www.abb.com/substationautomation.
  • Page 84 Contact us ABB AB Substation Automation Products SE-721 59 Västerås, Sweden Phone +46 (0) 21 32 50 00 +46 (0) 21 14 69 18 www.abb.com/substationautomation...
