Installation and Maintenance Manual
16
You will be returned to the prompt when finished
Installing the SSL Gateway on MAC OS X
1
Install SSL-Gateway.mpkg
2
Edit the launch file /Library/LaunchDaemons/com.splicecom.upcs.plist using the following
command:
sudo vi /Library/LaunchDaemons/com.splicecom.upcs.plist
3
Change IP address on line 17 to the address of the CallServer.
4
Load the launch file with the following command:
sudo launchctl load /Library/LaunchDaemons/com.splicecom.upcs.plist
5
If you need to change the address unload the launchfile first with the command:
sudo launchctl unload /Library/LaunchDaemons/com.splicecom.upcs.plist
6
Make the change to the file then load the launch file again.
7
The application will automatically start if you reboot your Mac.
Please note:
PCS 582G and PCS 582GX phones do not support SSL.
Port Forwarding - If you are planning on assigning an Internet address to the SSL Gateway machine
you must ensure that your router has the relevant port forwarding enabled on it. The port that needs
forwarding will be the port that is configured in the SSL config files - the default is port 5000.
Log Files - The SSL Gateway Application will store logs in the /SpliceCom/logs directory on both Linux
and MAC OS X platforms. The log will only be generated once a connection is made to the SSL
Gateway app.
The SSL Gateway marks Type of Service (ToS) packets as Expedited, allowing time sensitive voice
packets to take priority across WiFi newtorks. This enhancement was developed in conjunction with
Meru when using iPCS in WiFi mode across their wireless networks. However, this feature will also be
of benefit in other wireless environments that recognise and support ToS.
SSL devices support First and Last Name directory searches (please refer to the Configuring a User
section from page 95 and the Creating a Contact section from page 161 for further details).
Configure iPCS app to communicate with the Call Server
Before starting you will require the following to continue:
iPCS licences installed on the maximiser system
IP address of the PC running the iPCS Gateway application
The port number set in the xinetd file, eg 5000
1
Once the iPCS app has been loaded onto the user's iPhone or iPad or Android phone open this
app
2
Go to Settings at the bottom right hand corner of the screen
3
Select Server >
4
Enter the following parameters:
Address = IP address of the PC running the iPCS Gateway application
Port = the port no set in the xinetd file, eg 5000
User = any value, this will change once the app has registered with the Call Server
Password = any value, this will change once the app has registered with the Call Server
82
System Configuration
Installation and Maintenance Manual v4/0615/10
