Installation and Maintenance Manual
Global BLF
Enable/Disable. When enabled this feature provides a system wide Busy Lamp Field view across all
networked Call Servers for all User's on the system. Requires multicast Router support to transport Global
BLF info between sites. Where required, this option must be enabled on all Call Servers – not just the
Primary Call Server.
Global Call Log
Enable/Disable. When enabled in a multi-Call Server network this feature provides a unified Call Logging
output from all Servers to be presented on the Primary Call Server. Where required, this option must be
enabled on all Call Servers – not just the Primary Call Server.
Extended Capacity Licence
5108 Call Server only. Increases the number of Users supported on a 5108 to 12 once the 5108Plus
licence has been installed.
IP Routes page
This page can be used to create IP routes for destinations where the packets need to route back on to
the LAN.
Intramodule Trunks page
Name
64 Domain characters. Name of this trunk.
Compression Type
None Calls to be made without using compression
G729A8K Use G.729a based compression supported via a Voice Compression Module or Card
Relay Relay the media packets, allowing RTP packets to go through a NAT/firewall by using the
Call Server as a single address for all RTP
Capacity
Number of connections to be allowed via this Call Server.
Reserved Incoming Capacity
The number of channels to be reserved for incoming calls. Outgoing calls will not be made if the
remaining capacity is exceeded.
IP Address (override)
Default - blank = public IP address. The IP address that the module should use as a source address when
communicating with the modules listed below. Can be an internal or public IP address.
Members
Member
The module to whom compressed calls will be made.
Order
Determines the position of an entry within the Members list.
346
Field Descriptions
Installation and Maintenance Manual v4/0615/10
