Installation and Maintenance Manual
Module
5108 Call Server
5500 Network Service Gateway
5204 Trunk Module
5230 Trunk Module
5315 Phone Module
5330 Phone Module
Configuring the System Name and Supplier Name
Licences are issued against a company name and the supplier's name therefore the System Name and
Supplier Name provided with the licences must be entered accurately in the System configuration form.
If this information is not entered correctly the licences will not activate.
Please refer to the Configuring System Details section from page 9 for further details.
Enter the Licences on the system
Each licence is provided with the type of licence, the quantity of licences purchased and a licence key.
This information must be correctly entered; otherwise the licences will not be operational.
1 In Manager, select Licences
2 The Licences List will appear.
3 Click on the Add button
4 In the Key field enter the alpha-numeric code provided
5 In the Qty field enter the number of licences purchased
6 In the Licence field enter the type of licence purchased,
eg IPUser, MessageBox
7 Select Apply when ready.
8 The Valid field will display OK if the licence has been
entered correctly.
24
Qty Licence Action
4 POTS Activating Ports 1-4
4 IPUser 4 Users automatically created
2 Trunk Activating BRI1
2 VoicemailPort Enabling 2 simultaneous voicemail
connections
5 MessageBox Supplied and installation required
4 POTS Activating Ports 1-4
4 IPUser 4 Users automatically created
4 Trunk Activating BRI1 and BRI2 ports
2 VoicemailPort Enabling 2 simultaneous voicemail
connections
2 Trunk Activating BRI1
8 Trunk Activating 8 channels on the PRI port
15 POTS Activating all analogue ports
15 IPUsers 15 Users automatically created
30 POTS Activating all analogue ports
30 IPUsers 30 Users automatically created
System Configuration
