Installation and Maintenance Manual
= (equal sign)
Will record all calls received on this number. Please refer to the Call Recording section
from page 256 for further information.
~ (tilde)
Will bypass any compression (required for fax calls)
Please note that these options may cause the outbound CLI to fail therefore double entries will be
required.
Outgoing CLI for external calls
A DDI Plan entry is also used when external calls are made by a User. If the extension number making
the call is found in the Translate To field of a DDI Plan entry the number in the Number Match field will be
used as the outgoing CLI. (Please note if the User's Dial Plan contains an entry specifying the outgoing
CLI this will take precedence (please refer to page 134 for further details).) If no matches are found then
the Trunk's Presentation Number will be used.
The order in which the configuration of the system will determine the outgoing CLI to be presented for a
specific User when making an external call is as follows:
1
Dial Plan entry – Translate CLI To field
2
DDI Call Plan entry
3
Trunk – Presentation Number field
User dials from extension "x"
Digits dialled are matched by a
Dial Plan entry
Extension number "y" found in
Translate CLI To field of the Dial
Plan entry
Yes
Extension number "y" matched
in DDI Plan entry
Yes
DDI number in Number Match
field of DDI Plan entry sent as
CLI
Configuring system functionality
Installation and Maintenance Manual v4/0615/10
No
No
Extension number "x"
matched in DDI Plan entry
DDI number in Number Match
field of DDI Plan entry sent as
CLI
No
Yes
Trunk Presentation
Number sent as CLI
197
