Installation and Maintenance Manual

System Configuration

Manager

The configuration of the maximiser system is controlled and stored on the LDAP database within the Call
Server. Manager is the application that is used to view and configure this database.
Changes to the configuration made via Manager or by a User via their handset are stored in the RAM and
copied regularly to the hard disk to be stored permanently. It is important to perform an orderly shut
down of the system before power down to ensure all changes are copied to the hard disk and so that the
hard disk is shut down cleanly - please refer to the Orderly Shut down of the File System section from
page 281 for further details.
Manager is a web based application which can be run from any Web browser (Internet Explorer v5 or
higher, or Apple Safari v3.2 or higher) that can connect to the maximiser system.
On initial installation/boot up of a Call Server full administrative access is available by logging in as
Manager
which has a password of
password for this Administrator once access has been achieved. Please refer to the Setting Up
Administrative Access section from page 14 for further details.
Running Manager
1 Your PC must have an IP connection to the Call Server.
2 Via a web browser, open
ip address of 5100/5108
http://
or
ip address of the Linux PC
http://
3 Enter the Administrator name and password into the log in dialogue box. For the very first log in
after installation full access is available by logging in as follows:
User Name = Manager
Password = managerpassword
Working in Manager
On opening Manager a list of the configurable objects on the database is displayed in orange within the
navigation pane on the left hand side (please refer to the Manageable Objects section in the Technical
Reference manual for a description of each object). A single click on one of the objects will display a list
of the relevant entries in the database. The User's list is displayed by default.
System Configuration
Installation and Maintenance Manual v4/0615/10
managerpassword
. For security, it is advisable to at least change the
/manager eg http://192.168.0.1/manager
/manager or http://localhost/manager
7
