Installation and Maintenance Manual
11
Select the Licences tab.
12
Select the Navigate Softphone Licence box.
13
Select Update or Apply when ready. (This setting will not be saved if a Navigate SoftPhone licence
is not available.)
14
Return to Navigate.
15
Click on the Softphone button and restart Navigate.
16
Once open Navigate will display "Navigate (Softphone) - <user name>" in the title bar and the User
Name in the Status Bar.
Navigate as a partner to a User's handset
Navigate can be run as partner to any PCS 58x, 57x, 56x, 55x, 542 or analogue handset being used on the
maximiser system giving the user the additional functionality provided by Navigate.
Before starting:
In order for Navigate to partner a telephone Navigate must connect to the port that the analogue
handset is plugged into or to the relevant IP phone, therefore you will require the following information:
1
The IP address of the Phone Module or Call Server where the analogue port is located.
This can be viewed within Manager. Select Modules and then select the relevant module, the IP
address is displayed, or via Manager Assist>System Utilities>IP Addresses.
or
The IP address of the PCS 56x, 57x, 55x or 542.
This can be viewed on the handset by selecting the Favourites button, then Settings and then
Phone Information, or via Manager Assist>System Utilities>IP Addresses.
or
The IP address of the PCS 58x.
This can be viewed on the handset within the Phone Information screen, which can be accessed
by pressing the Settings icon 5 times, or via Manager Assist>System Utilities>IP Addresses.
or
The IP address of a PCS 410/400.
This can be viewed on the handset by selecting the Information icon from the Home Page toolbar,
or via Manager Assist>System Utilities>IP Addresses.
or
The IP address of a PCS 100.
This can be viewed on the handset by pressing the Down arrow once (or twice if Favourites are
displayed) and the IP address being used by the handset will be displayed. The IP address is also
displayed during power up. Or via Manager Assist>System Utilities>IP Addresses.
2
The reference number of the port:
a Each analogue port on a Phone module or Call Server is given a reference number starting at
5001. Therefore port 1 is referenced as 5001, port 2 as 5002 etc.
b The port reference number for a PCS 58x/57x/56x/55x/542/410/400/100 will always be 5001.
3
The User's Partner Login Code. This can be configured as follows.
System Configuration
Installation and Maintenance Manual v4/0615/10
65
