Installation and Maintenance Manual
a In Manager select Unassigned Modules
b The Phone Module will be displayed together with its MAC address
c Select this link
d The Module Status field will display Available
e From the Module Status list box select Member
f Select Update or Apply when ready
g This unit will now be listed under Modules
7
If any analogue handsets were connected before the install, they will ring once to confirm
communication with the system
Connect each analogue handset to a port on the Phone module via a master dongle or RJ45 connection
if supplied. For further details please refer to the Connecting an Analogue Phone section from page 48.
A Phone Module controls:
Ringing of the telephones at the requested cadence
Presentation of the CLI
Recognition of off-hook state
Recognition of dialled DTMF tones
Presentation of DTMF for fax servers
Please note: Anti-static precautions are advised when handling, inserting or removing PCMCIA cards with
respect to the 4300 Phone modules.
Configuring a Phone Module
1
In Manager select Modules
2
The Phone Module will be displayed together with its MAC address
3
Select this link to view and configure this module.
Name, Description and Location – these are text fields and can be used to help identity the Phone
module. The Name must be unique, should consist of alphanumerical characters only, not contain
any punctuation and begin with a letter.
Serial Number – hardware address of the module
IP Address – displays the IP address being used by the Phone module. This will be either provided
via DHCP or can be configured via setnet as described below.
Product Version - will display which version of software is currently running on the Phone Module.
For information on upgrading this software please refer to page 288.
Module Status – should be set to Member as configured during set up.
Call Server - indicates to which Call Server the Phone Module is registered. The Call Server is
responsible for replicating relevant configuration information to the Phone Module. In turn the
Phone Module will store in RAM configuration information relevant to its functionality. The
Phone Module will pass back configuration changes, eg User configuration, to the Call Server.
The Flash LED button will instruct the Phone Module's SpliceCom LED to flash. This feature is useful
when multiple Phone Modules are being used on a system and will identify the physical Phone
Module from its corresponding configuration form.
4
Select Update or Apply when ready.
46
System Configuration
Installation and Maintenance Manual v4/0615/10
