Installing the SSL Gateway on a Linux PC
Initial consideration
SSL Gateway must be in installed on PC running OpenSUSE 12.3
Minimum hardware requirement - 1 Gbps processor, 2 GB memory
SSL Gateway software is 32 bit so will run on 32 or 64 bit Linux (64 bit is recommended if a choice is
available)
Can reside on the same PC as S8000 and/or Vision (except Vision Call Centre)
Linux configuration:
The IP address of the SSL Gateway is the IP address of the Linux PC. This IP address must be
associated with eth0.
DHCP, IP routing, DNS, NFS Server and NTP services are all configured within Linux
The Linux PC must have a User called "splicecom". It is recommended that Auto Login is turned
off for this User account.
You will need to know the root password to enter and execute Terminal commands during
installation and configuration.
Ensure that the Firewall available on the Linux PC is turned off
Enable Remote Administration (VNC)
Enable the sshd service
Ensure that Linux PC does not hibernate or shut down
During the installation the Linux PC must be connected to the Internet or have access to the Linux
installation CD
Installing the software
1 Copy the SSL Gateway software onto the Linux PC
2 Via Terminal go to the directory where the software is stored
3 Enter the following command to extract the software
tar –xf SSL-Gateway-Linux.tar.gz
4 This will create a new directory called SSL-Gateway
5 Change to this directory, eg cd SSL-Gateway
6 Enter sudo ./install.SUSE
(use this command if you are using the Linux installation CD)
or
Enter sudo ./install.SUSE - net
(use this command if the installation files are to be retrieved via the Internet, preferred method)
7 Once the Installation complete message is displayed and the prompt has returned the following
commands will configure the Linux PC to communicate with the Call Server
8 Enter sudo vi /etc/xinetd.d/upcs
9 Once the xinetd file is displayed, press i to go into Insert Mode
10 Change the server_args line to read
–s –securepartner –gk ip address of call server
11 Ensure the Port line is set to 5000
12 Press ESC to exit Insert Mode
13 Enter :wq to save any changes
14 You will be returned to Terminal prompt
15 Enter the following command to restart xinetd and apply the changes
sudo /sbin/service xinetd restart
