Scalar i2000 User's Guide
Note
• The SCSI Channel Status dialog box displays information about the
SCSI connection on the MCB.
• The Fibre Channel Status dialog box displays information about the
FC connections on the MCB and the I/O blades (if any exist).
You must perform the following procedures while viewing the physical
library.
Viewing I/O Blade Status Information
1 Make sure that you are viewing the physical library. From the View
menu, click the name of the physical library.
2 Click Monitor→ Connectivity→ IO Blade.
The IO Blade Status dialog box appears.
The following table describes the elements on the IO Blade Status dialog
box.
Description
The type of I/O blade ("FC IOB" indicates an I/O blade).
If the library does not detect at least one chassis
management blade (CMB) in the library, the IO
Blade command does not appear on the menu.
Chapter 5 Maintaining Your Library
Monitoring the Library
5
210
