Quantum scalar i2000 User Manual page 225

Element Description
Port Index The port number.
Location The location of the port (for example, MCB).
Port Mode The mode of the port (Target or Initiator).
Status The status of the SCSI Channel (Operational or Lost Sync).
Host ID The SCSI ID.
Termination Terminated or Not Terminated.
Alternate ID The alternate SCSI ID.
Bus Reset Indicates whether the bus is configured to reset when library power is turned on
(Yes or No).
Scalar i2000 User's Guide
The following table describes the elements on the SCSI Channel Status
dialog box.
3 From the IO Blade Status dialog box, you can perform the following
tasks:
• Change the sorting of SCSI connections in the status list (for
example, by type or location) by clicking the column heading by
which you want the connections sorted. Repeatedly clicking a
column heading toggles between ascending and descending
order.
• Mail, save, or print status information by using the Send button
(see Mailing, Saving, and Printing Status Information
page 230).
Chapter 5 Maintaining Your Library
Monitoring the Library
on
212
