Indicator Panel

Robotics Enabled indicator
and button
Table 25 Robotics Enabled
Indicator
Indicator State and Explanation
Green Solid on — robotics are enabled and ready to process commands or are actively
processing commands from the library controller. No attention required. Do not open
the access door.
Blinking — a change of robotics state is pending, either from the enabled state to the not
enabled state or from the not enabled state to the enabled state. No attention required.
Do not open the access door.
No color Solid off — either robotics are not ready, the doors might be open, or the library might
be powered off. Attention required. The operator should close the doors and press the
Robotics Enabled button to return robotics to the enabled state.
Scalar i2000 User's Guide
The Robotics Enabled indicator and the Power indicator each include a
6
button. The Status indicator is not a button. These indicators do not
report the status of communications with a host.
Status indicator
The following tables describe the indicators in detail.
Note
The enabled state does not mean that robotics are
communicating with the host. It means that the
robotics are communicating with the library
controller.
Chapter 6 Running Your Library
Operator Panel
Power button
and indicator
