Maintaining The Air Filters; Figure 31 Top And Bottom Air Filters - Quantum scalar i2000 User Manual

Maintaining the Air
Filters
Figure 31 Top and Bottom Air
Filters
Scalar i2000 User's Guide
5 On the operator panel, press the Robotics Enabled button to enable
the picker.
The access door of each control and expansion module has two air filters:
5 one located at the top, and the other located at the bottom, as shown in
figure 31.
Many factors exist that contribute to the need to regularly service the air
filters. For example, the total number of tape drives and the operating
environment greatly affect the rate at which debris accumulates in the air
filters.
Chapter 5 Maintaining Your Library
Maintenance Actions
top air filter
bottom air filter
333
