Element Description
In the Host Settings area:
DHCP If Dynamic Host Configuration Protocol (DHCP) is enabled on your network,
select Enable to have DHCP automatically configure the library network
settings. Enable makes the IP Address, Subnet Mask, and Default Gateway
text boxes unavailable. Select Disable to make the IP Address, Subnet Mask,
and Default Gateway text boxes available for you to manually set the library
network settings.
Library Name The network name that you want to assign to the library.
IP Address The IP address of the library. This text box is available only if DHCP is disabled.
Subnet Mask The subnet mask. This text box is available only if DHCP is disabled.
Default The IP address of the default gateway for your portion of the Ethernet network.
Gateway This text box is available only if DHCP is disabled.
In the Port Settings area:
Auto Negotiate Select Enable to have the library automatically negotiate port speeds. Enable
makes the Speed options unavailable. Select Disable to make the Speed options
available for you to manually set the port speed.
Speed The port speed (10 Mbps or 100 Mbps). Speed options are available only if Auto
Negotiate is disabled.
Scalar i2000 User's Guide
The following table describes the elements on the Network Configuration
dialog box.
The Cycle button enables you to cycle the external Ethernet interface
without rebooting the library.
4 Make the appropriate network configuration changes, and then click
OK.
5 A message appears that informs you that network connectivity will
be lost temporarily and asks whether you want to proceed. Click Yes.
Chapter 4 Configuring Your Library
Setting Up the Network Configuration
