Scalar i2000 User's Guide
If you did not accept the default location when you
Note
installed the client, navigate to the location you
chose.
The Connect to AMC Server dialog box appears.
2 Type the name or IP address of the library to which you want to
connect, and then click OK.
If the host computer contacts the library
Note
successfully, but the library fails to perform
callback, a message appears that indicates that the
library failed to register the client. Click OK. The
Connect to AMC Server dialog box appears again
with an additional button (Config). Clicking
Config displays the Connection Configuration
dialog box from which you can indicate a proxy
server IP address so that the host computer can
work across a firewall that is configured for
network address translation (NAT).
If you again fail to connect after indicating a proxy
server IP address, verify your firewall settings.
One possible cause is that the library is not able to
send data to the host computer because the
callback port for the host computer is not within
the range of callback ports indicated on the LMC
tab of the Security Configuration dialog box
(Setup→ Security from the library's touch screen).
For more information about setting up callback
port ranges, see
LMC Clients
Chapter 6 Running Your Library
Configuring Access for Remote
on page 189.
Logging On and Off
343
