Interpreting LEDs

Scalar i2000 User's Guide
Saving a Report Template
If you frequently generate the Tickets Report with the same set of report
criteria, save the criteria as a template. Loading the template recalls the
saved report criteria and lets you quickly generate a report based on the
saved criteria.
1 On the menu bar, click Tools→ Reports→ Tickets.
The Report Criteria dialog box appears.
2 Under Specify Report Criteria, click criteria options in the lists to
customize the content and appearance of the Tickets Report.
Table 3 on page 46 summarizes the available report criteria options.
3 Under Templates, click Save.
4 Type a name for the template, and then click OK.
The template appears in the list under Templates.
To load the saved report criteria at a later time, click the template in the
list, and then click View to generate the report.
5 To close the Report Criteria dialog box, click Cancel.
LEDs can help you assess the state of a library component. The primary
library LEDs can be grouped as follows:
• Blade status LEDs
• Drive status LEDs
• Fibre port link LEDs (for Fibre drives and Fibre Channel I/O blades)
• MCB port LEDs
• LBX terminator LEDs
• Power supply status LEDs
Chapter 2 Troubleshooting Your Library

Interpreting LEDs

2
51
