Control Module

Scalar i2000 User's Guide
100 cartridges and can be increased to as many as 3,492 LTO or 2,915 DLT
cartridges inside one library.
All library configurations include the control module, which contains the
following components at a minimum (see
• Library management module (LMM)
• I/E station
• Tape drives
• Cartridge storage
• Operator panel
• Power system
The I/O management unit is optional for the control module. For more
information about the I/O management unit, see
on page 87.
Chapter 3 Description
Control Module
figure 12 on page 84):
I/O Management Units
83
