Removing An Application's Trap Registration - Quantum scalar i2000 User Manual

Removing an
Application's Trap
Registration
Scalar i2000 User's Guide
5 In the UDP Port text box, type the number of the User Datagram
Protocol (UDP) port that you want to associate with the IP address.
6 Click Create.
The application's IP address and UDP port number appear in the table to
indicate that the application is registered to receive SNMP traps from the
library.
4
1 Log on as an administrator.
2 Make sure that you are viewing the physical library. From the View
menu, click the name of the physical library.
3 Click Setup→ Trap Registration.
The Trap Registration dialog box appears.
4 Click the IP address of the application for which you want to remove
trap registration to highlight it.
5 Click Delete.
Chapter 4 Configuring Your Library
Registering SNMP Traps
185
