Interpreting MCB Port
LEDs
Figure 6 Locations - Colors of
MCB Ethernet Port LEDs
MCB Ethernet
port LEDs
- top = green
- bottom = amber
Scalar i2000 User's Guide
The MCB has LEDs for the Ethernet, Fibre Channel, and SCSI ports.
2
MCB Ethernet Port LEDs
The LEDs on the MCB Ethernet port indicate status and activity.
shows the locations and colors of the MCB Ethernet port LEDs.
Chapter 2 Troubleshooting Your Library
Interpreting LEDs
2
Figure 6
64
