Figure 12 Front and Back View
of the Control Module
magazines
and
cartridge
slots
accessor

Expansion Modules

Scalar i2000 User's Guide
front view
picker
Expansion modules enable the library to expand by adding space for tape
drives, I/E stations, and cartridges. Each expansion module adds 300 to
456 LTO or 250 to 380 DLT cartridge slots, depending on the number of
tape drives installed and whether an I/E station is installed (see
on page 85). The library's maximum configuration includes up to seven
back view
I/E
station
drive
clusters
Chapter 3 Description
Expansion Modules
I/O
management
unit
library
management
module
power
supplies
figure 13
84
