System Status Buttons

Figure 36 System Status
Buttons in Good Status
Table 30 Subsystems and
Their Components
Subsystem
Drives
Connectivity
Control
Robotics
Power
Scalar i2000 User's Guide
System status buttons are located in the Overall System Status area at the
6
bottom of the LMC display (see
Each button represents a subsystem.
subsystems and some of the components that each subsystem represents.
Each field replaceable unit (FRU) in the library belongs to one of the
subsystems.
Components
Drives and media, such as brick firmware, drive bricks, drive sleds, cartridges,
and magazines
Host connectivity components, such as I/O management units, I/O blades, and
the chassis management blade (CMB)
Main processor cards and related hardware and software, such as system
firmware, the management control blade (MCB), the robotics control unit (RCU),
the library motor drive (LMD), and the operator panel
Assemblies and processors involved in the movement and handling of library
media, such as the IEX board, I/E stations, the pivot and reach assemblies, system
barcode labels, doors, filters, the accessor, drive mounts, rails, and carriages
Power supplies and related hardware, such as the power distribution unit (PDU),
power chassis, and fuses
Chapter 6 Running Your Library
Library Management Console (LMC)
figure 36).
Table 30 shows the library
364
