Table 11 Explanations of MCB
Ethernet Port LED States
LED Color
Possible States and Explanations
Green
• Solid on — the link is up; data can be sent or received through the Ethernet port
• Solid off — the link is not up; data cannot be sent or received through the Ethernet
port
Amber
• Flashes at irregular intervals — data activity is occurring through the Ethernet port
• Solid off — no data activity is occurring through the Ethernet port
Scalar i2000 User's Guide
Table 11
describes how to interpret the Ethernet port LED activity that
you might see.
MCB Fibre Channel and SCSI Port LEDs
The LEDs for the MCB Fibre Channel and SCSI ports are for future use.
Ignore LED behaviors that might appear.
locations and colors of the LEDs.
Chapter 2 Troubleshooting Your Library
Interpreting LEDs
Figure 7
on page 66 shows the
2
65
