Library Management Module

Figure 14 Library Management
Module Boards
management control blade
robotics control unit
library motor drive
Scalar i2000 User's Guide
The library management module (LMM) controls and manages library
hardware and software components. It enables both SAN-connected
hosts and users who access the library using the operator panel to
configure the library, obtain system status information, and perform
various library functions. The LMM contains the management control
blade (MCB), the robotics control unit (RCU), and the library motor
driver (LMD), as shown in
Library Management Module
figure 14.
Chapter 3 Description
86
