Secondary shaft reassembly on the housing

Follow the procedure below to reassemble gears and
sleeves on the very shaft.
On the shaft, housing side, insert the following:
• The bushing for the 2 nd -speed gear on the shaft; make
sure that the head of the bushing faces the cover.
• The roller bearing cage for the 2
bushing.
• The 2 nd -speed gear on the roller bearing cage, making
sure that the front engaging notches face the cover.
• The washer between the 2
gear.
rd
• The 3 -speed gear on the roller bearing cage, making
sure that the front engaging notches face the housing
side.
• The bushing for 3 rd -speed gear on the shaft with head
facing the mobile sleeve.
• The fixed sleeve, making sure that the lowered internal
part is assembled facing the 3
• The inner bearing race, 4
code 14928600, see chapter 5 section B.
• The mobile sleeve to engage the 3
making sure that the lowered part faces the 3
gear.
• The roller bearing cage on the bushing.
th
• The 4 -speed gear on the shaft, making sure that the
front engaging notches face the mobile sleeve.
On the shaft, cover side, insert the following:
st nd
• 1 and 2 gear sleeve on the shaft.
st
• The bushing for 1 -speed gear with head towards the
nd
2 -speed gear.
• The roller bearing cage for 1
bushing.
• The 1 st -speed gear on the roller bearing cage.
• The seal ring within the groove on the shaft.
th
• The 5 -speed gear making sure that the lowered part
is assembled on the seal ring.
G
EARBOX
nd
-speed gear on the
nd -speed and the 3 rd -speed
rd
-speed gear.
th
-speed gear side, with tool
rd and 4 th gear
rd -speed
st -speed gear on the
