PART 1 Overview System Overview on page 3 Chassis Components and Descriptions on page 13 Cooling System and Airflow on page 19 Power Supplies on page 23 Viewing System Information on page 25 Copyright © 2016, Juniper Networks, Inc.
Page 25: System Overview
Rear Panel of an EX2200 Switch on page 8 EX2200 Switches First View EX2200 switches are available in models with 12 , 24, or 48 built-in network ports. The compact, fanless model, EX2200-C switches have 12 network ports. Copyright © 2016, Juniper Networks, Inc.
Page 26: Uplink Ports
Each EX2200 switch except the EX2200-C switch model has an RJ-45 console port that accepts a cable with RJ-45 connector. The EX2200-C switch has two console ports: an RJ-45 port and a Mini-USB Type-B port. The RJ-45 console port accepts a cable with an RJ-45 connector and the Mini-USB Type-B console port accepts a Mini-B plug (5-pin) connector to connect to the console management device.
Page 27: Cable Guard
119. Security Slots Each EX2200-C switch model has security slots on the left and right panels of the chassis. Use the security slots to lock and secure the chassis in the installation site with a standard cable lock . See “Mounting an EX2200 Switch on a Desk or Other Level Surface”...
Page 28: Front Panel Of An Ex2200 Switch
EX2200 and EX2200-C Switches Hardware Guide Front Panel of an EX2200 Switch The front panel of an EX2200 switch except the EX2200-C switch models consists of the following components: Network ports—depending on the switch model, either of: 24 or 48 10/100/1000BASE-T Gigabit Ethernet ports, with Power over Ethernet...
Page 29: Figure 3: Front Panel Of An Ex2200-C Switch With 12 Gigabit Ethernet Ports
Chapter 1: System Overview The front panel of an EX2200-C switch consists of the following components: Network ports—depending on the switch model, either of: 12 10/100/1000BASE-T Ethernet ports, (PoE+) in EX2200-C-12P 12 10/100/1000BASE-T Ethernet ports, (non-PoE) in EX2200-C-12T 2 built-in dual-purpose uplink ports, each of which includes one 10/100/1000 RJ-45...
Page 30: Rear Panel Of An Ex2200 Switch
EX2200 and EX2200-C Switches Hardware Guide Rear Panel of an EX2200 Switch The rear panel of the EX2200 switch except the EX2200-C switch models consists of the following components: Management Ethernet port USB port Console port Protective earthing terminal Redundant power system (RPS) port...
Page 31: Ex2200 Switch Models
Site Preparation Checklist for EX2200 Switches on page 47 EX2200 Switch Models The EX2200 switch is available with 12, 24, or 48 built-in network ports with full Power over Ethernet (PoE) capability (all 12, 24, or 48 built-in network ports support PoE) or no PoE capability.
Page 32: Ex2200 Switch Hardware And Cli Terminology Mapping
EX2200 and EX2200-C Switches Hardware Guide EX2200 Switch Hardware and CLI Terminology Mapping This topic describes the hardware terms used in EX2200 switch documentation and the corresponding terms used in the Junos OS command line interface (CLI). See Table 4 on page...
Page 33 Chapter 1: System Overview Table 4: CLI Equivalents of Terms Used in Documentation for EX2200 Switches (continued) Hardware Item (as Description (as Value (as displayed Item in Additional displayed in the CLI) displayed in the CLI) in the CLI) Documentation...
Page 35: Chassis Components And Descriptions
Management Port LEDs in EX2200 Switches on page 15 Network Port and Uplink Port LEDs in EX2200 Switches on page 16 Chassis Physical Specifications for EX2200 Switches The EX2200 switch chassis is a rigid sheet-metal structure that houses the hardware components. Table 5 on page 13 summarizes the physical specifications of the EX2200 switch chassis.
Page 36: Chassis Status Leds In Ex2200 Switches
EX2200 and EX2200-C Switches Hardware Guide Chassis Status LEDs in EX2200 Switches The front panel of an EX2200 switch has two chassis status LEDs labeled SYS and ALM on the far right side of the panel. See Figure 7 on page 14...
Page 37: Management Port Leds In Ex2200 Switches
Understanding Alarm Types and Severity Levels on EX Series Switches on page 197 Management Port LEDs in EX2200 Switches The management port on an EX2200 switch has two LEDs that indicate link/activity and port status. The EX2200 switches except the EX2200-C switch models have the management port on the rear panel and the EX2200-C switch has the management port on the front panel.
Page 38: Network Port And Uplink Port Leds In Ex2200 Switches
Documentation Network Port and Uplink Port LEDs in EX2200 Switches Each network port and uplink port on the front panel of an EX2200 switch has two LEDs that indicate link/activity and port status. Each dual-purpose uplink port in an EX2200-C switch has two pairs of LEDs that indicate the link/activity status, one pair for each of the two ports that constitute the dual-purpose uplink port.
Page 39: Figure 13: Port Status Mode Leds Of The Dual-Purpose Uplink Ports Of An
Figure 13: Port Status Mode LEDs of the Dual-Purpose Uplink Ports of an EX2200-C Switch Table 9 on page 17 describes the Link/Activity LED. Table 9: Link/Activity LED on the Network Ports and Uplink Ports in EX2200 Switches Color State and Description Link/Activity Green Blinking—The port and the link are active, and there is link activity.
Page 40 A device that draws power from the port is connected to the port, but the device is not drawing any power from the port. Off—PoE is not available on the port. NOTE: PoE Status LED is available on the following EX2200 switch models: EX2200-C-12P EX2200-24P EX2200-48P PoE is not available on uplink ports;...
Page 41: Cooling System And Airflow
In the PoE models of these switches, there is an additional fan in the power supply. In the EX2200-C switch the cooling is done by the vents on top and sides of the chassis in non-PoE models and by heatsinks in PoE+ models. Do not block the vents on the chassis.
Page 42: Airflow Direction In Poe Models Of Ex2200 Switches, Except For The Ex2200-C Models
Figure 14: Airflow Through Non-PoE Models of EX2200 Switches Except the EX2200-C Switch Model Airflow Direction in PoE Models of EX2200 switches, Except for the EX2200-C Models Figure 15 on page 21 shows the airflow in PoE models of EX2200 switches, except EX2200-C models.
Page 43: Figure 15: Airflow Through Poe Models Of Ex2200 Switches Except The Ex2200-C Switch Models
Chapter 3: Cooling System and Airflow Figure 15: Airflow Through PoE Models of EX2200 Switches Except the EX2200-C Switch Models Under normal operating conditions, the fans operate at a moderate speed to reduce noise. Temperature sensors in the chassis monitor the temperature within the chassis.
Page 45: Power Supplies
Power Supply in EX2200 Switches The power supply in EX2200 switches is built in along the rear panel of the chassis, with an AC power cord inlet or DC power terminals on the rear panel to connect power to the switch.
Page 46 EX2200 and EX2200-C Switches Hardware Guide Connecting AC Power to an EX2200 Switch on page 149 Connecting DC Power to an EX2200 Switch on page 151 Connecting Earth Ground to an EX Series Switch on page 143 Copyright © 2016, Juniper Networks, Inc.
Page 47: Viewing System Information
NOTE: This topic applies only to the J-Web Application package. When you log in to the J-Web user interface, the dashboard for the Juniper Networks EX Series Ethernet Switches appears. Use the dashboard to view system information. The Update Available window appears if there is a latest update of the J-Web Application package available on the Juniper Networks server.
Page 48: Graphical Chassis Viewer
EX2200 and EX2200-C Switches Hardware Guide File System Usage on page 32 Chassis Viewer on page 32 Graphical Chassis Viewer The Dashboard panel displays a graphical view of the switch chassis. In a Virtual Chassis, it displays a graphical view of each member switch.
Page 49: System Information Panel
NOTE: In a Virtual Chassis setup for an EX6210, EX8208, or EX8216 switch, the Device model field displays details of the master Routing Engine. To view details of a member, select it. Copyright © 2016, Juniper Networks, Inc.
Page 50 EX4550 switches that are not configured as Virtual Chassis, the value displayed in the Inventory details field is always 1 FPC. FPC is a legacy term for a slot in a large Juniper Networks chassis, which simply refers to the standalone switch.
Page 51: Health Status Panel
EX2200-C switch. Temp. Temp. field is dynamically available for an EX2200 Virtual Chassis switch based on the model of the member clicked. NOTE: In EX4300 Virtual Chassis, the temperature of the master Routing Engine is displayed by default.
Page 52 NOTE: field is unavailable for standalone EX2200-C and EX2300-C switches. Fan status field is dynamically available for an EX2200 Virtual Chassis switch based on the Fan status model of the member clicked. EX4500 and EX4550 Switches Memory util.
Page 53: Capacity Utilization Panel
Indicates the maximum number of VLANs supported. Alarms Panel The Alarms panel displays information about the last five alarms raised in the system. For example, if there are 5 major alarms, then details of all 5 major alarms are displayed. Copyright © 2016, Juniper Networks, Inc.
Page 54: File System Usage
Table 17 on page 32—Describes the chassis viewer for EX2200 switches. Table 18 on page 33—Describes the chassis viewer for EX2200-C and EX2300-C switches. Table 19 on page 34—Describes the chassis viewer for EX2300 switches.
Page 55: Table 18: Chassis Viewer For Ex2200-C And Ex2300-C Switches
NOTE: The mini-USB console port is available on EX2300-C switch and is unavailable on EX2200-C switch. We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Rear View Copyright © 2016, Juniper Networks, Inc.
Page 56: Table 19: Chassis Viewer For Ex2300 Switches
Indicates the mini-USB port for the switch. This is used to connect the switch to a management console such as a laptop or a PC. (You might do this for initial switch configuration.) NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Rear View USB port Indicates the USB port for the switch.
Page 57: Table 20: Chassis Viewer For Ex3200, Ex3300, And Ex4200 Switches
USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Fan tray Mouse over the fan tray icon to display name, status, and description information.
Page 58: Table 21: Chassis Viewer For Ex3400 And Ex4300 Switches
Gray—VCP is down and nonoperational. USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Management ( ) port The management port is used to connect the switch to a management device for out-of-band management.
Page 59 USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Fan tray Mouse over the fan tray icons to display name, status, and description information.
Page 60: Table 22: Chassis Viewer For Ex4500 Switches
Use this port for initial switch configuration. USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Rear View of the EX4500 Switch Fan tray Mouse over the fan tray icon to display status of the fans and airflow direction information.
Page 61: Table 23: Chassis Viewer For Ex4550 Switches
(uplink or Virtual Chassis). USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Rear View of the EX4550 Switch Fan tray Mouse over the fan tray icon to display the status of the fans and airflow direction information.
Page 62: Table 24: Chassis Viewer For Ex6210 Switches
You can view status for the following ports on the SRE module: USB port—Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Management ( ) port—The management port is used to connect the switch to a management...
Page 63 You can view status for the following ports on the SRE module: USB port—Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Auxiliary port—This port is unavailable.
Page 64: Table 26: Chassis Viewer For Ex8216 Switches
You can view status for the following ports on the RE module: USB port—Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Auxiliary port—This port is unavailable.
Page 65 Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. PIC1 slot You can install a Virtual Chassis module in the PIC1 slot. Mouse over the Virtual Chassis ports to display the port status details.
Page 66 EX2200 and EX2200-C Switches Hardware Guide Related J-Web User Interface for EX Series Switches Overview Documentation EX2200 Switches Hardware Overview on page 3 EX2300 Switches Hardware Overview EX3200 Switches Hardware Overview EX3300 Switches Hardware Overview EX4200 Switches Hardware Overview EX4300 Switches Hardware Overview...
Page 67: Part 2 Site Planning, Preparation, And Specifications
PART 2 Site Planning, Preparation, and Specifications Preparation Overview on page 47 Power Specifications and Requirements on page 63 Transceiver and Cable Specifications on page 69 Pinout Specifications on page 105 Copyright © 2016, Juniper Networks, Inc.
Page 69: Preparation Overview
Site Electrical Wiring Guidelines on page 54 Chassis Physical Specifications for EX2200 Switches on page 55 Requirements for Mounting an EX2200 Switch on a Desktop or Wall on page 55 Rack Requirements for EX2200 Switches on page 56 Cabinet Requirements for EX2200 Switches on page 57...
Page 70 Plan the cable routing and management. Related General Safety Guidelines and Warnings on page 211 Documentation General Site Guidelines on page 53 Installing and Connecting an EX2200 Switch on page 117 Mounting an EX2200 Switch on page 118 Copyright © 2016, Juniper Networks, Inc.
Page 71: Environmental Requirements And Specifications For Ex Series Switches
32° F (0° C) earthquake EX2300-C 13,000 feet 10% through 85% through 113° F (45° C) requirements as per switches) (3962.4 meters) at (noncondensing) GR-63, Issue 4. 104° F (40° C) as per GR-63 Copyright © 2016, Juniper Networks, Inc.
Page 72 EX2200 and EX2200-C Switches Hardware Guide Table 29: EX Series Switch Environmental Tolerances (continued) Environment Tolerance Switch or device Altitude Relative Humidity Temperature Seismic EX3200 No performance Normal operation ensured in Normal operation ensured in the Complies with Zone 4...
Page 73 10,000 feet 5% through 90% (0° C) through 104° F (40° C) requirements as per (3048 meters) (noncondensing) GR-63. Nonoperating storage temperature in shipping container: –40° F (–40° C) to 158° F (70° C) Copyright © 2016, Juniper Networks, Inc.
Page 74 Articles 110–16, 110–17, and 110–18 of the National Electrical Code, ANSI/NFPA 70. Related Clearance Requirements for Airflow and Hardware Maintenance for EX2200 Switches Documentation on page 58 Clearance Requirements for Airflow and Hardware Maintenance for EX2300 Switches...
Page 75: General Site Guidelines
Environmental Requirements and Specifications for QFX3600 and QFX3600-I Devices Environmental Requirements and Specifications for a QFX5100 Device QFX5200 Environmental Requirements and Specifications QFX10002 Environmental Requirements and Specifications QFX10000 Environmental Requirements and Specifications Environmental Requirements and Specifications for an NFX250 Device Copyright © 2016, Juniper Networks, Inc.
Page 76: Site Electrical Wiring Guidelines
EX2200 and EX2200-C Switches Hardware Guide Site Electrical Wiring Guidelines This topic applies to hardware devices in the EX Series product family, which includes EX Series switches, the EX Series Redundant Power System (RPS), and the XRE200 External Routing Engine.
Page 77: Chassis Physical Specifications For Ex2200 Switches
Insert the screws into wall studs wherever possible to provide added support for the chassis. Use the wall-mount kit from Juniper Networks to mount the switch on a wall. The wall-mount kit is not part of the standard package and must be ordered separately.
Page 78: Rack Requirements For Ex2200 Switches
EX2200 and EX2200-C Switches Hardware Guide Wall-Mounting Warnings for EX2200 Switches on page 229 Mounting an EX2200 Switch on a Desk or Other Level Surface on page 119 Mounting an EX2200 Switch on a Wall on page 128 Rack Requirements for EX2200 Switches You can mount the EX2200 switches on two-post racks or four-post racks.
Page 79: Cabinet Requirements For Ex2200 Switches
Mounting an EX2200 Switch on Two Posts of a Rack or Cabinet on page 122 Mounting an EX2200 Switch on Four Posts of a Rack or Cabinet on page 124 Mounting an EX2200 Switch in a Recessed Position in a Rack or Cabinet on page 128 Cabinet Requirements for EX2200 Switches You can mount the switch in a cabinet that contains a 19-in.
Page 80: Clearance Requirements For Airflow And Hardware Maintenance For Ex2200 Switches
Mounting an EX2200 Switch on Four Posts of a Rack or Cabinet on page 124 Mounting an EX2200 Switch in a Recessed Position in a Rack or Cabinet on page 128 Clearance Requirements for Airflow and Hardware Maintenance for EX2200 Switches When planning the site for installing an EX2200 switch, you must allow sufficient clearance around the installed switch.
Page 81: Figure 16: Clearance Requirements For Airflow And Hardware Maintenance For Ex2200 Switches Except Ex2200-C Switch Models
For the cooling system to function properly, the airflow around the chassis must be unrestricted. Figure 18 on page 60 shows the airflow in PoE models of EX2200 switches, except for EX2200-C models. Figure 19 on page 60 shows the airflow non-PoE models of EX2200 switches, except for EX2200-C models.
Page 82: Figure 18: Airflow Through Poe Models Of Ex2200 Switches Except Ex2200-C
Fans Chassis rear If you are mounting an EX2200 switch in a rack or cabinet with other equipment, or if you are placing it on the desktop or floor near other equipment, ensure that the exhaust from other equipment does not blow into the intake vents of the chassis.
Page 83 Rack Requirements for EX2200 Switches on page 56 Documentation Cabinet Requirements for EX2200 Switches on page 57 General Site Guidelines on page 53 Rack-Mounting and Cabinet-Mounting Warnings on page 224 Cooling System and Airflow in an EX2200 Switch on page 19 Copyright © 2016, Juniper Networks, Inc.
Page 85: Power Specifications And Requirements
Calculating the EX Series Switch Fiber-Optic Cable Power Margin on page 66 Power Specifications for EX2200 Switches This topic describes the power supply electrical specifications for EX2200 switches. Table 34 on page 63 provides the AC power supply electrical specifications for EX2200 switches.
Page 86: Ac Power Cord Specifications For Ex2200 Switches
EX2200 and EX2200-C Switches Hardware Guide Table 35: DC Power Supply Electrical Specifications for EX2200 Switches (continued) Item Specification Output holdup time 1 ms minimum NOTE: EX2200 switches with DC power supply do not provide PoE. NOTE: For DC power supplies, we recommend that you provide at least 3.5 A at 48 VDC and use a facility circuit breaker rated for 10 A minimum.
Page 87: Figure 20: Ac Plug Types
Table 36 on page Figure 20: AC Plug Types Related Power Supply in EX2200 Switches on page 23 Documentation General Safety Guidelines and Warnings on page 211 General Electrical Safety Guidelines and Warnings on page 243 Copyright © 2016, Juniper Networks, Inc.
Page 88: Calculating The Ex Series Switch Fiber-Optic Cable Power Budget
EX2200 and EX2200-C Switches Hardware Guide Prevention of Electrostatic Discharge Damage on page 245 Calculating the EX Series Switch Fiber-Optic Cable Power Budget Calculate the link's power budget when planning fiber-optic cable layout and distances to ensure that fiber-optic connections have sufficient power for correct operation. The power budget is the maximum amount of power the link can transmit.
Page 89: Table 37: Estimated Values For Factors Causing Link Loss
For information about the actual amount of signal loss caused by equipment and other factors, see your vendor documentation for that equipment. Calculate the (P ) by subtracting (LL) from (P – LL = P Copyright © 2016, Juniper Networks, Inc.
Page 90 EX2200 and EX2200-C Switches Hardware Guide (13 dBm) – (0.5 dBm [HOL]) – ((5) * (0.5 dBm)) – ((2) * (0.5 dBm)) – ((2 km) * (1.0 dBm/km)) – (1 dB [CRM]) = P 13 dBm – 0.5 dBm – 2.5 dBm – 1 dBm – 2 dBm – 1 dBm = P...
Page 91: Transceiver And Cable Specifications
Dispersion on page 103 Pluggable Transceivers Supported on EX2200 Switches Uplink ports and dual-purpose uplink ports on the front panel in EX2200 switches support SFP transceivers. This topic describes the optical interfaces supported for those transceivers. It also lists the copper interface supported for the SFP transceivers. For the...
Page 92 EX2200 and EX2200-C Switches Hardware Guide NOTE: EX2200-C switches ensure normal operation in the temperature range 30° F (0° C) through 104° F (40° C) at altitudes up to 5,000 ft (1,524 m). In the following conditions, use extended temperature range SFP transceivers when fiber uplinks are used: In the temperature range 104°...
Page 93: Table 38: Optical Interface Support And Copper Interface Support For Gigabit Ethernet Sfp Transceivers In Ex2200 Switches Except Ex2200-C
Chapter 8: Transceiver and Cable Specifications Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches Ethernet Standard Specification Value 1000BASE-T Model number EX-SFP-1GE-T Rate 10/100/1000 Mbps Connector type RJ-45 Transmitter wavelength –...
Page 94 EX2200 and EX2200-C Switches Hardware Guide Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-SX Model number EX-SFP-1GE-SX Rate 1000 Mbps Connector type...
Page 95 Chapter 8: Transceiver and Cable Specifications Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-1GE-LX Rate 1000 Mbps Connector type...
Page 96 EX2200 and EX2200-C Switches Hardware Guide Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-BX-U Model number EX-SFP-GE10KT13R14 Rate 1000 Mbps Connector type...
Page 97 Chapter 8: Transceiver and Cable Specifications Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-BX-D Model number EX-SFP-GE10KT14R13 Rate 1000 Mbps Connector type...
Page 98 EX2200 and EX2200-C Switches Hardware Guide Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-BX-U Model number EX-SFP-GE10KT13R15 Rate 1000 Mbps Connector type...
Page 99 Chapter 8: Transceiver and Cable Specifications Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-BX-D Model number EX-SFP-GE10KT15R13 Rate 1000 Mbps Connector type...
Page 100 EX2200 and EX2200-C Switches Hardware Guide Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-BX-U Model number EX-SFP-GE40KT13R15 Rate 1000 Mbps Connector type...
Page 101 Chapter 8: Transceiver and Cable Specifications Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-BX-D Model number EX-SFP-GE40KT15R13 Rate 1000 Mbps Connector type...
Page 102 EX2200 and EX2200-C Switches Hardware Guide Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-1GE-LX40K Rate 1000 Mbps Connector type...
Page 103 Chapter 8: Transceiver and Cable Specifications Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-LH (or Model number EX-SFP-1GE-LH 1000BASE-ZX) Rate 1000 Mbps...
Page 104 EX2200 and EX2200-C Switches Hardware Guide Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-GE80KCW1470 Rate 1000 Mbps Connector type...
Page 105 Chapter 8: Transceiver and Cable Specifications Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-GE80KCW1490 Rate 1000 Mbps Connector type...
Page 106 EX2200 and EX2200-C Switches Hardware Guide Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-GE80KCW1510 Rate 1000 Mbps Connector type...
Page 107 Chapter 8: Transceiver and Cable Specifications Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-GE80KCW1530 Rate 1000 Mbps Connector type...
Page 108 EX2200 and EX2200-C Switches Hardware Guide Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-GE80KCW1550 Rate 1000 Mbps Connector type...
Page 109 Chapter 8: Transceiver and Cable Specifications Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-GE80KCW1570 Rate 1000 Mbps Connector type...
Page 110 EX2200 and EX2200-C Switches Hardware Guide Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-GE80KCW1590 Rate 1000 Mbps Connector type...
Page 111 Chapter 8: Transceiver and Cable Specifications Table 38: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-GE80KCW1610 Rate 1000 Mbps Connector type...
Page 112: Table 39: Optical Interface Support For Fast Ethernet Sfp Transceivers In Ex2200 Switches Except Ex2200-C Switches
EX2200 and EX2200-C Switches Hardware Guide Table 39: Optical Interface Support for Fast Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches Ethernet Standard Specification Value 100BASE-FX Model number EX-SFP-1FE-FX Rate 100 Mbps Connector type Fiber count Dual Transmitter wavelength...
Page 113 Chapter 8: Transceiver and Cable Specifications Table 39: Optical Interface Support for Fast Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 100BASE-LX Model number EX-SFP-1FE-LX Rate 100 Mbps Connector type Fiber count Dual Transmitter wavelength...
Page 114 EX2200 and EX2200-C Switches Hardware Guide Table 39: Optical Interface Support for Fast Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 100BASE-BX-U Model number EX-SFP-FE20KT13R15 Rate 100 Mbps Connector type Fiber count Single Transmitter wavelength...
Page 115 Chapter 8: Transceiver and Cable Specifications Table 39: Optical Interface Support for Fast Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 100BASE-BX-D Model number EX-SFP-FE20KT15R13 Rate 100 Mbps Connector type Fiber count Single Transmitter wavelength...
Page 116 EX2200 and EX2200-C Switches Hardware Guide Table 39: Optical Interface Support for Fast Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 100BASE-LX40K Model number EX-SFP-1FE-LX40K Rate 100 Mbps Connector type Fiber count Dual Transmitter wavelength...
Page 117 Chapter 8: Transceiver and Cable Specifications Table 39: Optical Interface Support for Fast Ethernet SFP Transceivers in EX2200 Switches Except EX2200-C Switches (continued) Ethernet Standard Specification Value 100BASE-LH (or Model number EX-SFP-1FE-LH 100BASE-ZX) Rate 100 Mbps Connector type Fiber count...
Page 118: Table 40: Optical Interface Support And Copper Interface Support For Sfp Transceivers In Ex2200-C Switches
EX2200 and EX2200-C Switches Hardware Guide Table 40: Optical Interface Support and Copper Interface Support for SFP Transceivers in EX2200-C Switches Ethernet Standard Specification Value 1000BASE-SX Model number EX-SFP-1GE-SX Rate 1000 Mbps Connector type Fiber count Dual Transmitter wavelength 850 nm Minimum launch power –9.5 dBm...
Page 119 Fiber type Core/Cladding size – Modal bandwidth – Transmitter wavelength 850 nm Distance 550 m (1804 ft) Software required Junos OS for EX Series switches, Release 11.3 or later Support for Virtual Chassis configuration Copyright © 2016, Juniper Networks, Inc.
Page 120 EX2200 and EX2200-C Switches Hardware Guide Table 40: Optical Interface Support and Copper Interface Support for SFP Transceivers in EX2200-C Switches (continued) Ethernet Standard Specification Value Extended Temp SFP Model number EX-SFP-1FE-FX-EX 100BASE-FX Rate 1000 Mbps Connector type Fiber count –...
Page 121 Fiber type Core/Cladding size 62.5/125 µm Fiber grade FDDI/OM1 Modal bandwidth 500 MHz/km Distance 2 km (1.2 miles) Software required Junos OS for EX Series switches, Release 11.3 or later Support for Virtual Chassis configuration Copyright © 2016, Juniper Networks, Inc.
Page 122 EX2200 and EX2200-C Switches Hardware Guide Table 40: Optical Interface Support and Copper Interface Support for SFP Transceivers in EX2200-C Switches (continued) Ethernet Standard Specification Value 1000BASE-LX Model number EX-SFP-1GE-LX Rate 1000 Mbps Connector type Fiber count Dual Transmitter wavelength...
Page 123: Pluggable Transceivers Supported On Ex Series Switches
Junos OS for EX Series switches, Release 11.3 or later Support for Virtual Chassis configuration Related EX2200 Switches Hardware Overview on page 3 Documentation Installing a Transceiver in a Switch on page 177 Removing a Transceiver from a Switch on page 179...
Page 124 Use only optical transceivers and optical connectors purchased from Juniper Networks for your EX Series switches. For the list and specifications of transceivers supported on EX2200 switches, see “Pluggable Transceivers Supported on EX2200 Switches” on page For the list and specifications of transceivers supported on EX2300 switches, see Pluggable Transceivers Supported on EX2300 Switches.
Page 125: Network Cable Specifications For Ex2200 Switches
Fiber-Optic Cable to a Switch” on page 160. Related Management Port Connector Pinout Information for an EX2200 Switch on page 108 Documentation Console Port Connector Pinout Information for an EX Series Switch on page 105 EX2200 Switches Hardware Overview on page 3...
Page 126: Attenuation And Dispersion In Fiber-Optic Cable
EX2200 and EX2200-C Switches Hardware Guide Exceeding the maximum transmission distances can result in significant signal loss, which causes unreliable transmission. For information about the maximum transmission distance and supported wavelength range for the types of single-mode and multimode fiber-optic cables that are used on different EX Series switches see “Pluggable Transceivers...
Page 127: Pinout Specifications
Mini-USB Port Specifications for an EX2200 Switch on page 106 USB Port Specifications for an EX Series Switch on page 107 Management Port Connector Pinout Information for an EX2200 Switch on page 108 Network Port Connector Pinout Information for an EX2200 Switch on page 109...
Page 128: Mini-Usb Port Specifications For An Ex2200 Switch
Configuring the Console Port Type (CLI Procedure) Mini-USB Port Specifications for an EX2200 Switch The EX2200-C switch, the compact, fanless model, has two management console ports: an RJ-45 port, and a Mini-USB Type-B port. By default, the RJ-45 port is set as the active console port. It can display all the early boot and low-level message output and you can access the switch through this port in the debugger prompt.
Page 129: Usb Port Specifications For An Ex Series Switch
Documentation Configuring the Console Port Type (CLI Procedure) USB Port Specifications for an EX Series Switch The following Juniper Networks USB flash drives have been tested and are officially supported for the USB port on all EX Series switches: RE-USB-1G-S...
Page 130: Management Port Connector Pinout Information For An Ex2200 Switch
Booting an EX Series Switch Using a Software Package Stored on a USB Flash Drive Management Port Connector Pinout Information for an EX2200 Switch The management port on an EX2200 switch uses an RJ-45 connector to connect to a management device for out-of-band management.
Page 131: Network Port Connector Pinout Information For An Ex2200 Switch
Chapter 9: Pinout Specifications Network Port Connector Pinout Information for an EX2200 Switch A network port on an EX2200 switch uses an RJ-45 connector to connect to a device. The port uses an autosensing RJ-45 connector to support a 10/100/1000Base-T connection.
Page 132: Table 45: Rj-45 To Db-9 Serial Port Adapter Pinout Information
EX2200 and EX2200-C Switches Hardware Guide Table 45: RJ-45 to DB-9 Serial Port Adapter Pinout Information RJ-45 Pin Signal DB-9 Pin Signal Related Connecting a Switch to a Management Console by Using an RJ-45 Connector on Documentation page 157 Connecting and Configuring an EX Series Switch (CLI Procedure) on page 167...
Page 133: Initial Installation And Configuration
Unpacking the Switch on page 113 Installing the Switch on page 117 Connecting the Switch to Power on page 143 Connecting the Switch to the Network on page 155 Performing Initial Configuration on page 163 Copyright © 2016, Juniper Networks, Inc.
Page 135: Unpacking The Switch
Parts Inventory (Packing List) for an EX2200 Switch on page 114 Registering Products—Mandatory for Validating SLAs on page 115 Unpacking an EX2200 Switch The EX2200 switches are shipped in a cardboard carton, secured with foam packing material. The carton also contains an accessory box. CAUTION: EX2200 switches are maximally protected inside the shipping carton.
Page 136: Parts Inventory (Packing List) For An Ex2200 Switch
EX2200 switch—provided EX2200-C switch—separately orderable Rubber feet RJ-45 cable and RJ-45 to DB-9 serial port adapter Cable guard with 3 number-8 Phillips truss-head screws (optional and separately orderable for EX2200-C – switches) Quick Start installation instructions Juniper Networks Product Warranty End User License Agreement Copyright ©...
Page 137: Registering Products-Mandatory For Validating Slas
Register your products at: https://tools.juniper.net/svcreg/SRegSerialNum.jsp Update your installation base at: If you have a Juniper J-Care service contract, register any addition, change, or upgrade of hardware components at . Failure to do so https://www.juniper.net/customers/support/tools/updateinstallbase/ can result in significant delays if you need replacement parts.
Page 139: Installing The Switch
Mounting an EX2200 Switch on Four Posts of a Rack or Cabinet on page 124 Mounting an EX2200 Switch in a Recessed Position in a Rack or Cabinet on page 128 Mounting an EX2200 Switch on a Wall on page 128...
Page 140: Mounting An Ex2200 Switch
EX2200 and EX2200-C Switches Hardware Guide “Mounting an EX2200 Switch On or Under a Desk Using Screws” on page 135 (using the desk/wall mounting screws) “Mounting an EX2200 Switch Using the Magnet Mount” on page 138 (using the separately orderable magnet sheet) Follow instructions in “Connecting Earth Ground to an EX Series Switch”...
Page 141: Mounting An Ex2200 Switch On A Desk Or Other Level Surface
Mounting an EX2200 Switch on a Desk or Other Level Surface You can mount an EX2200 switch on a desk or other level surface by using the four rubber feet that are shipped with the switch. The rubber feet stabilize the chassis.
Page 142: Figure 21: Attaching Rubber Feet To A Switch Chassis
“Chassis Lifting Guidelines for EX2200 Switches” on page 221. NOTE: Do not block the vents on the top of the EX2200-C switches. Doing this can lead to overheating of the switch chassis. Ensure that you have the following parts and tools available:...
Page 143: Figure 22: Attaching A Cable Guard To An Ex2200-C Switch
121. Figure 22: Attaching a Cable Guard to an EX2200-C Switch (Optional; applies only to EX2200-C switches) Attach the standard cable lock to the security slots on the both sides of the switch: Rope the cable to a desk or a rack and set the lock to unlocked position.
Page 144: Mounting An Ex2200 Switch On Two Posts Of A Rack Or Cabinet
Mounting an EX2200 Switch on Two Posts of a Rack or Cabinet You can mount all EX2200 switches on two posts of a two-post or a four-post 19-in. rack or cabinet using the mounting brackets and screws provided with all EX2200 switches except the EX2200-C switches.
Page 145: Figure 24: Attaching The Mounting Bracket Along The Front Of The Switch
Chapter 11: Installing the Switch To mount the switch on two posts of a two-post or a four-post rack: Remove the switch from the shipping carton (see “Unpacking an EX2200 Switch” on page 113). Place the switch on a flat, stable surface.
Page 146: Mounting An Ex2200 Switch On Four Posts Of A Rack Or Cabinet
Connecting and Configuring an EX Series Switch (CLI Procedure) on page 167 Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 170 Mounting an EX2200 Switch in a Recessed Position in a Rack or Cabinet on page 128 Rack-Mounting and Cabinet-Mounting Warnings on page 224...
Page 147 Chapter 11: Installing the Switch NOTE: If you need to mount an EX2200 switch except the EX2200-C switch model in a recessed position on either a two-post rack or a four-post rack, you can use the 2-in.-recess front-mounting brackets provided in the separately orderable four-post rack-mount kit.
Page 148: Figure 26: Attaching The Front-Mounting Bracket To The Side Mounting-Rail
EX2200 and EX2200-C Switches Hardware Guide Figure 26: Attaching the Front-Mounting Bracket to the Side Mounting-Rail 1— Side mounting-rail 2— Front-mounting bracket Place the switch on a flat, stable surface. Align the side mounting-rails along the side panels of the switch chassis. Align the two holes in the rear of the side mounting-rails with the two holes on the rear of the side panel.
Page 149: Figure 28: Mounting The Switch To The Front Posts Of A Rack
Related Mounting an EX2200 Switch on Two Posts of a Rack or Cabinet on page 122 Documentation Connecting Earth Ground to an EX Series Switch on page 143...
Page 150: Mounting An Ex2200 Switch In A Recessed Position In A Rack Or Cabinet
Connecting and Configuring an EX Series Switch (CLI Procedure) on page 167 Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 170 Mounting an EX2200 Switch in a Recessed Position in a Rack or Cabinet on page 128 Rack-Mounting and Cabinet-Mounting Warnings on page 224...
Page 151 Chapter 11: Installing the Switch When mounting an EX2200 switch chassis in a vertical position, orient the front panel of the chassis downward to ensure proper airflow and meet safety requirements in the event of a fire. When wall mounting Power over Ethernet (PoE) models (EX2200-24P...
Page 152: Figure 30: Attaching Wall-Mount Brackets To A Switch Chassis
EX2200 and EX2200-C Switches Hardware Guide Figure 30: Attaching Wall-Mount Brackets to a Switch Chassis Baffle for PoE Models (EX2200-24P and EX2200-48P) Rear panel Front panel If you are mounting two switches together, align the second switch on top of the first and attach it to the mounting brackets using two additional wall-mount bracket screws on each side.
Page 153: Mounting An Ex2200-C Switch On A Wall
Mounting an EX2200-C Switch on a Wall You can mount an EX2200-C switch, the compact, fanless model, on a wall by using the flexible mounting slots on the bottom of the chassis to fix to the screws on the wall.
Page 154 CAUTION: Do not block the vents on the top of the EX2200-C switches. Doing this can lead to overheating of the switch chassis. Before mounting the switch on a wall: Verify that the site meets the requirements described in “Site Preparation Checklist...
Page 155: Figure 33: Measurements For Installing Mounting Screws For The Ex2200-C
Chapter 11: Installing the Switch Figure 33: Measurements for Installing Mounting Screws for the EX2200-C Switch Drill hole A and install a mounting screw. Drill hole B 9.53 in. (24.2 cm) on a level line from hole A and install a mounting screw.
Page 156: Figure 34: Mounting The Ex2200-C Switch On A Wall Using Screws
EX2200 and EX2200-C Switches Hardware Guide Figure 34: Mounting the EX2200-C Switch on a Wall Using Screws (Optional) Attach the optional cable guard to protect cable connections: Use the 3 truss-head screws to attach the cable guard to the bottom of the chassis.
Page 157: Mounting An Ex2200 Switch On Or Under A Desk Using Screws
This topic applies only to the EX2200-C switch, the compact, fanless model. You can mount an EX2200-C switch on or under a desk or other level surface by using the flexible mounting slots on the bottom of the chassis to secure the switch.
Page 158: Figure 37: Measurements For Installing Mounting Screws For Ex2200-C
Drill three holes A, B, and C on or under the desk as shown in Figure 37 on page 136. Figure 37: Measurements for Installing Mounting Screws for EX2200-C Switch Drill hole A and install a mounting screw. Drill hole B 9.52 in. (22.1 cm) on a level line from hole A and install a mounting screw.
Page 159: Figure 38: Mounting The Ex2200-C Switch On Or Under A Desk Using Screws
See Figure 38 on page 137. Figure 38: Mounting the EX2200-C Switch On or Under a Desk Using Screws (Optional) Attach the cable guard to protect cable connections: Use the 3 truss-head screws to attach the cable guard to the bottom of the chassis.
Page 160: Mounting An Ex2200 Switch Using The Magnet Mount
Mounting an EX2200 Switch Using the Magnet Mount This topic applies only to the EX2200-C switch, the compact, fanless model. You can mount an EX2200-C switch on or under a surface made of ferrous material using the separately orderable magnet sheet.
Page 161: For Ex2200 Switches" On Page
NOTE: Do not block the vents on the top of the EX2200-C switches. Doing this can lead to overheating of the switch chassis. Before mounting the switch using magnet mount: Ensure that no rubber feet are installed on the bottom of the switch.
Page 162: Figure 41: Mounting An Ex2200-C Switch Using Magnet Mount
Mount the magnet along with the switch on the ferrous surface where you want to mount the switch orienting the front panel downwards as shown in Figure 41 on page 140. Figure 41: Mounting an EX2200-C Switch Using Magnet Mount Magnetic surface Magnet mount (Optional) Attach the cable guard to protect cable connections: Use the 3 truss-head screws to attach the cable guard to the bottom of the chassis.
Page 163: Figure 42: Attaching A Cable Guard To An Ex2200-C Switch
Chapter 11: Installing the Switch Figure 42: Attaching a Cable Guard to an EX2200-C Switch (Optional) Attach the standard cable lock to the security slots on the both sides of the switch Rope the cable to a desk or a rack and set the lock to unlocked position.
Page 165: Connecting The Switch To Power
Connecting the Switch to Power Connecting Earth Ground to an EX Series Switch on page 143 Connecting AC Power to an EX2200 Switch on page 149 Connecting DC Power to an EX2200 Switch on page 151 Connecting Earth Ground to an EX Series Switch...
Page 166: Table 48: Parts And Tools Required For Connecting An Ex Series Switch To Earth Ground
EX2200 and EX2200-C Switches Hardware Guide for connecting a switch to earth ground. Before you begin connecting a switch to earth ground, ensure you have the parts and tools required for your switch. Table 48: Parts and Tools Required for Connecting an EX Series Switch to Earth Ground...
Page 167: Special Instructions To Follow Before Connecting Earth Ground To A
Two ¼-20 x 0.5 in. Phillips (+) the chassis mm²), minimum LCD2-14A-Q or screws with #¼” number 2 60°C wire, or as equivalent split-washer permitted by the —provided —provided local code Two #¼” flat washers— provided Copyright © 2016, Juniper Networks, Inc.
Page 168: Switch
Special Instructions EX3200 NOTE: Some early variants of EX3200 switches for which the Juniper Networks model number on the label next to the protective earthing terminal is from 750-021xxx through 750-030xxx require 10-24x.25 in. screws. Copyright © 2016, Juniper Networks, Inc.
Page 169: Figure 44: Connecting The Grounding Lug To A Switch Mounted On Four Posts Of
Special Instructions EX4200 NOTE: Some early variants of EX4200 switches for which the Juniper Networks model number on the label next to the protective earthing terminal is from 750-021xxx through 750-030xxx require 10-24x.25 in. screws. NOTE: The protective earthing terminal on an EX4200 switch mounted on four posts of a rack is accessible through the slot on the left rear bracket only if the rack is 27.5 in.
Page 170: Connecting Earth Ground To An Ex Series Switch
Ensure that the cable does not drape where people could trip over it. Related Connecting AC Power to an EX2200 Switch on page 149 Documentation Connecting DC Power to an EX2200 Switch on page 151 Connecting AC Power to an EX2300 Switch...
Page 171: Connecting Ac Power To An Ex2200 Switch
Grounded Equipment Warning on page 229 Connecting AC Power to an EX2200 Switch The power supply in an EX2200 switch is located on the rear panel. Ensure that you have the following parts and tools available: A power cord appropriate for your geographical location A power cord retainer clip Ensure that you have connected the switch chassis to earth ground.
Page 172: Figure 46: Connecting An Ac Power Cord Retainer Clip To The Ac Power Cord Inlet On An Ex2200 Switch
EX2200 and EX2200-C Switches Hardware Guide To connect AC power to the switch: Squeeze the two sides of the power cord retainer clip and insert the L-shaped ends of the wire clip into the holes in the bracket on each side of the AC power cord inlet...
Page 173: Connecting Dc Power To An Ex2200 Switch
Connecting and Configuring an EX Series Switch (CLI Procedure) on page 167 Documentation Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 170 Power Supply in EX2200 Switches on page 23 Connecting DC Power to an EX2200 Switch The power supply is installed along the rear panel.
Page 174: Figure 48: Securing Ring Lugs To The Terminals On The Dc Power Supply
EX2200 and EX2200-C Switches Hardware Guide Ensure that you have the following parts and tools available: DC power source cables (14 AWG) with ring lug (Molex 0190700067 or equivalent) (not provided) attached to them by a licensed electrician Phillips (+) screwdriver, number 2...
Page 175 Related Connecting and Configuring an EX Series Switch (CLI Procedure) on page 167 Documentation Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 170 Power Supply in EX2200 Switches on page 23 Copyright © 2016, Juniper Networks, Inc.
Page 177: Connecting The Switch To The Network
Connecting a Switch to a Network for Out-of-Band Management on page 155 Connecting a Switch to a Management Console by Using an RJ-45 Connector on page 157 Connecting an EX2200 Switch to a Management Console Using Mini-USB Type-B Console Port on page 159...
Page 178: Figure 50: Connecting A Switch To A Network For Out-Of-Band Management
Connecting a Switch to a Management Console by Using an RJ-45 Connector on Documentation page 157 Management Port Connector Pinout Information for an EX2200 Switch on page 108 Pinout Information for the RJ-45 Management Port on an EX2300 Switch Management Port Connector Pinout Information for an EX3200 Switch...
Page 179: Connector
PC directly to the device, use a combination of the RJ-45 to DB-9 female adapter supplied with the device and a USB to DB-9 male adapter. You must provide the USB to DB-9 male adapter. Copyright © 2016, Juniper Networks, Inc.
Page 180: Figure 52: Connecting A Switch To A Management Console Through A Console
Series Switch (J-Web Procedure)” on page 170 or Connecting and Configuring an OCX1100 Switch (CLI Procedure). NOTE: EX2200-24T-4G-DC switches do not support switch connection and configuration through the J-Web interface. Figure 52: Connecting a Switch to a Management Console Through a Console Server...
Page 181: Connecting An Ex2200 Switch To A Management Console Using Mini-Usb Type-B Console Port
If your laptop or PC does not have a DB-9 male connector pin or RJ-45 connector pin, you can connect your laptop or PC directly to an EX2200–C switch using a mini-USB cable that has a Standard-A USB connector on one end and a Mini-USB Type-B (5 pin) connector on the other end.
Page 182: Connecting A Fiber-Optic Cable To A Switch
EX2200 and EX2200-C Switches Hardware Guide Stop bits—1 DCD state—Disregard Ensure that you have the following parts and tools available: 1 mini-USB cable with Standard-A and Mini-USB Type- B (5-pin) connectors (not provided). To connect the switch to the console using Mini-USB Type-B console port: Connect the Standard-A connector of the mini-USB cable to the host machine (PC or Laptop).
Page 183 Installing a Transceiver in a Switch on page 177 Maintaining Fiber-Optic Cables in Switches on page 185 Pluggable Transceivers Supported on EX Series Switches on page 101 Installing a Transceiver in an OCX1100 Switch Pluggable Transceivers Supported on OCX1100 Switches Copyright © 2016, Juniper Networks, Inc.
Page 185: Performing Initial Configuration
See Reverting to the Default Factory Configuration for the EX Series Switch. The following factory default configuration file is for an EX2200 switch with 24 ports, all of which have PoE capability:...
Page 186 EX2200 and EX2200-C Switches Hardware Guide file messages { any notice; authorization info; file interactive-commands { interactive-commands any; commit { factory-settings { reset-chassis-lcd-menu; reset-virtual-chassis-configuration; interfaces { ge-0/0/0 { unit 0 { family ethernet-switching; ge-0/0/1 { unit 0 { family ethernet-switching;...
Page 187 { unit 0 { family ethernet-switching; ge-0/0/15 { unit 0 { family ethernet-switching; ge-0/0/16 { unit 0 { family ethernet-switching; ge-0/0/17 { unit 0 { family ethernet-switching; ge-0/0/18 { unit 0 { family ethernet-switching; Copyright © 2016, Juniper Networks, Inc.
Page 188 EX2200 and EX2200-C Switches Hardware Guide ge-0/0/19 { unit 0 { family ethernet-switching; ge-0/0/20 { unit 0 { family ethernet-switching; ge-0/0/21 { unit 0 { family ethernet-switching; ge-0/0/22 { unit 0 { family ethernet-switching; ge-0/0/23 { unit 0 { family ethernet-switching;...
Page 189: Connecting And Configuring An Ex Series Switch (Cli Procedure)
There are two ways to connect and configure an EX Series switch: one method is through the console by using the CLI and the other is by using the J-Web interface. NOTE: EX2200-24T-4G-DC switches do not support switch connection and configuration through the J-Web interface. This topic describes the CLI procedure.
Page 190 See Switch Fabric and Routing Engine (SRE) Module in an EX8208 Switch. See Routing Engine (RE) Module in an EX8216 Switch. NOTE: In EX2200-C, EX2300-C, EX2300, EX4300, and EX4550 switches, you can also use the Mini-USB Type-B console port to connect to a laptop or PC.
Page 191 IP address. If the connection cannot be made, the J-Web interface displays instructions for starting a J-Web session. Related Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 170 Documentation Installing and Connecting an EX2200 Switch on page 117 Copyright © 2016, Juniper Networks, Inc.
Page 192: Connecting And Configuring An Ex Series Switch (J-Web Procedure)
There are two ways to connect and configure an EX Series switch: one method is through the console by using the CLI and the other is by using the J-Web interface. NOTE: EX2200-24T-4G-DC switches do not support switch connection and configuration through J-Web procedure. This topic describes the J-Web procedure.
Page 193 10 minutes and reverts to the factory-default configuration, and the PC loses connectivity to the switch. EX2200, EX2200-C, EX2300, EX2300-C, and EX3400 switch—The LEDs on the RJ-45 network ports on the front panel blink when the switch is in the initial setup mode.
Page 194: Figure 55: Lcd Panel In An Ex3200, Ex4200, Ex4500, Ex4550, Or Ex8200
To connect and configure the switch by using the J-Web interface: Transition the switch into initial setup mode: EX2200 and EX2200-C switches—Press the Factory Reset/Mode button located on the far right side of the front panel for 10 seconds. EX2300, EX2300-C, and EX3400 switches—If you have configured anything on the...
Page 195 Chapter 14: Performing Initial Configuration EX2200, EX2200-C, EX2300, EX2300-C, EX3200, EX3400, or EX4200 switch—Connect the cable to port 0 (ge-0/0/0) on the front panel of the switch. EX3300, EX4500, or EX4550 switch—Connect the cable to the port labeled MGMT on the front panel (LCD panel side) of the switch.
Page 196 Related Connecting and Configuring an EX Series Switch (CLI Procedure) on page 167 Documentation Installing and Connecting an EX2200 Switch on page 117 Installing and Connecting an EX2300 Switch Installing and Connecting an EX3200 Switch Installing and Connecting an EX3300 Switch...
Page 197: Installing, Maintaining, And Replacing Components
PART 4 Installing, Maintaining, and Replacing Components Replacing Transceiver on page 177 Maintaining and Replacing Fiber-Optic Cable on page 183 Contacting Customer Support and Returning the Chassis or Components on page 187 Copyright © 2016, Juniper Networks, Inc.
Page 199: Replacing Transceiver
(JTAC) can help you diagnose the source of the problem. Your JTAC engineer might recommend that you check the third-party optic or cable and potentially replace it with an equivalent Juniper Networks optic or cable that is qualified for the device.
Page 200 EX2200 and EX2200-C Switches Hardware Guide Before you begin installing a transceiver in an EX Series switch, ensure that you have taken the necessary precautions for safe handling of lasers (see “Laser and LED Safety Guidelines and Warnings for Switches” on page 231).
Page 201: Removing A Transceiver From A Switch
CFP transceivers. To remove a transceiver from a switch: Place the antistatic bag or antistatic mat on a flat, stable surface. Label the cable connected to the transceiver so that you can reconnect it correctly. Copyright © 2016, Juniper Networks, Inc.
Page 202 EX2200 and EX2200-C Switches Hardware Guide WARNING: Do not look directly into a fiber-optic transceiver or into the ends of fiber-optic cables. Fiber-optic transceivers and fiber-optic cables connected to transceivers emit laser light that can damage your eyes. WARNING: Do not leave a fiber-optic transceiver uncovered except when inserting or removing a cable.
Page 203: Figure 58: Removing An Sfp, Sfp+, Xfp, Or A Qsfp+ Transceiver From A
By using your fingers, grasp the body of the transceiver and pull it straight out of the port. Place the transceiver in the antistatic bag or on the antistatic mat placed on a flat, stable surface. Place the dust cover over the empty port. Copyright © 2016, Juniper Networks, Inc.
Page 204 EX2200 and EX2200-C Switches Hardware Guide Related Installing a Transceiver in a Switch on page 177 Documentation Pluggable Transceivers Supported on EX Series Switches on page 101 Installing a Transceiver in an OCX1100 Switch Pluggable Transceivers Supported on OCX1100 Switches...
Page 205: Maintaining And Replacing Fiber-Optic Cable
If the fiber-optic cable connector is covered with a rubber safety cap, remove the cap. Save the cap. Remove the rubber safety cap from the optical transceiver. Save the cap. Insert the cable connector into the optical transceiver (see Figure 54 on page 161). Copyright © 2016, Juniper Networks, Inc.
Page 206: Disconnecting A Fiber-Optic Cable From A Switch
EX2200 and EX2200-C Switches Hardware Guide Figure 59: Connecting a Fiber-Optic Cable to an Optical Transceiver Installed in a Switch Secure the cables so that they do not support their own weight. Place excess cable out of the way in a neatly coiled loop. Placing fasteners on a loop helps cables maintain their shape.
Page 207: Maintaining Fiber-Optic Cables In Switches
Frequent plugging and unplugging of fiber-optic cables in and out of optical instruments can damage the instruments, which are expensive to repair. Attach a short fiber Copyright © 2016, Juniper Networks, Inc.
Page 208 EX2200 and EX2200-C Switches Hardware Guide extension to the optical equipment. Any wear and tear due to frequent plugging and unplugging is then absorbed by the short fiber extension, which is easier and less expensive to replace than the instruments.
Page 209: Components
Packing an EX2200 Switch or Component for Shipping on page 191 Returning an EX2200 Switch or Component for Repair or Replacement If you need to return an EX2200 switch or hardware component to Juniper Networks for repair or replacement, follow this procedure: Determine the serial number of the component.
Page 210: Locating The Serial Number On An Ex2200 Switch Or Component
PS 550W AC Fan Tray Fan Tray Locating the Chassis Serial Number ID Label on an EX2200 Switch EX2200 switches have serial number ID labels located on the rear panel of the chassis (see Figure 60 on page 189). Copyright © 2016, Juniper Networks, Inc.
Page 211: Contacting Customer Support To Obtain Return Material Authorization For Switches
Returning an EX2200 Switch or Component for Repair or Replacement on page 187 Contacting Customer Support to Obtain Return Material Authorization for Switches If you are returning a switch or hardware component to Juniper Networks for repair or replacement, obtain a Return Material Authorization (RMA) number from Juniper Networks Technical Assistance Center (JTAC).
Page 212 The support representative validates your request and issues an RMA number for return of the component. Related Packing an EX2200 Switch or Component for Shipping on page 191 Documentation Packing an EX3200 Switch or Component for Shipping Packing an EX3300 Switch or Component for Shipping...
Page 213: Packing An Ex2200 Switch Or Component For Shipping
Returning an OCX1100 Switch or Component for Repair or Replacement Packing an EX2200 Switch or Component for Shipping If you are returning an EX2200 switch or component to Juniper Networks for repair or replacement, pack the item as described in this topic.
Page 214: Packing A Switch For Shipping
EX2200 and EX2200-C Switches Hardware Guide Packing a Switch for Shipping To pack a switch for shipping: On the console or other management device connected to the switch, enter the CLI operational mode and issue the following command to shut down the switch software: user@switch>...
Page 215 Chapter 17: Contacting Customer Support and Returning the Chassis or Components Related Returning an EX2200 Switch or Component for Repair or Replacement on page 187 Documentation Copyright © 2016, Juniper Networks, Inc.
Page 219: Alarms And Syslog Messages
This topic applies only to the J-Web Application package. Alarms alert you to conditions that might prevent normal operation of the switch. Before monitoring alarms on a Juniper Networks EX Series Ethernet switch, become familiar with the terms defined in Table 50 on page 197.
Page 220: Chassis Component Alarm Conditions On Ex2200 Switches
Dashboard for EX Series Switches on page 25 Chassis Component Alarm Conditions on EX2200 Switches This topic describes the chassis component alarm conditions on EX2200 switches. Table 51 on page 199 lists the alarm conditions on EX2200 switches, their severity levels, and the actions you can take to respond to them.
Page 221: Table 51: Chassis Component Alarm Conditions On Ex2200 Switches
Chapter 18: Alarms and Syslog Messages Table 51: Chassis Component Alarm Conditions on EX2200 Switches Chassis Alarm Component Alarm Condition Severity Remedy One fan in the chassis Major Open a support case using the Case is not spinning or is...
Page 222 EX2200 and EX2200-C Switches Hardware Guide Table 51: Chassis Component Alarm Conditions on EX2200 Switches (continued) Chassis Alarm Component Alarm Condition Severity Remedy Temperature Temperature is below Major Check the fan. the low operating (red) Open a support case using the Case temperature.
Page 223 Chapter 18: Alarms and Syslog Messages Table 51: Chassis Component Alarm Conditions on EX2200 Switches (continued) Chassis Alarm Component Alarm Condition Severity Remedy In EX2200 switches Check the fan. except EX2200-C Open a support case using the Case switches: The...
Page 224 EX2200 and EX2200-C Switches Hardware Guide Table 51: Chassis Component Alarm Conditions on EX2200 Switches (continued) Chassis Alarm Component Alarm Condition Severity Remedy Media Device booted from Minor Open a support case using the Case backup root. (yellow) Manager link at http://www.juniper.net/support/...
Page 225 Chapter 18: Alarms and Syslog Messages Table 51: Chassis Component Alarm Conditions on EX2200 Switches (continued) Chassis Alarm Component Alarm Condition Severity Remedy Redundant RPS is disconnected. Major Check the RPS connection. (red) power system (RPS) RPS fan has failed.
Page 226: Checking Active Alarms With The J-Web Interface
Understanding Software has expired. Licenses for EX Series Switches. Related Chassis Status LEDs in EX2200 Switches on page 14 Documentation Understanding Alarm Types and Severity Levels on EX Series Switches on page 197 Checking Active Alarms with the J-Web Interface...
Page 227: Monitoring System Log Messages
Apply a filter or a combination of filters to view messages. You can use filters to display relevant events. Table 53 on page 206 describes the different filters, their functions, and the associated actions. To view events in the CLI, enter the following command: show log Copyright © 2016, Juniper Networks, Inc.
Page 228: Table 53: Filtering System Log Messages
EX2200 and EX2200-C Switches Hardware Guide Table 53: Filtering System Log Messages Field Function Your Action System Log File Specifies the name of a system log file for which To specify events recorded in a particular file, you want to display the recorded events.
Page 229: Table 54: Viewing System Log Messages
Routing Engine than for messages generated on another Routing Engine (on a system with two Routing Engines installed and operational). Messages from the other Routing Engine also include the identifiers that identify the Routing Engine. Copyright © 2016, Juniper Networks, Inc.
Page 230 EX2200 and EX2200-C Switches Hardware Guide Table 54: Viewing System Log Messages (continued) Field Function Additional Information Severity Severity level of a message is indicated by different A severity level indicates how seriously the triggering colors. event affects switch functions. When you configure a location for logging a facility, you also specify a severity —Gray—Indicates no severity level is...
Page 231: Safety And Compliance Information
Radiation and Laser Safety Guidelines and Warnings on page 231 Maintenance and Operational Safety Warnings on page 237 Electrical Safety Guidelines and Warnings on page 243 Agency Approvals and Compliance Statements on page 261 Copyright © 2016, Juniper Networks, Inc.
Page 233: General Safety Guidelines And Warnings
Do not perform any actions that create a potential hazard to people or make the equipment unsafe. Never attempt to lift an object that is too heavy for one person to handle. Never install or manipulate wiring during electrical storms. Copyright © 2016, Juniper Networks, Inc.
Page 234: Definitions Of Safety Warning Levels
EX2200 and EX2200-C Switches Hardware Guide Never install electrical jacks in wet locations unless the jacks are specifically designed for wet environments. Operate the device only when it is properly grounded. Ensure that the separate protective earthing terminal provided on this device is permanently connected to earth.
Page 235 å unngå ulykker. Aviso Este símbolo de aviso indica perigo. Encontra-se numa situação que lhe poderá causar danos físicos. Antes de começar a trabalhar com qualquer equipamento, familiarize-se com os perigos relacionados com circuitos Copyright © 2016, Juniper Networks, Inc.
Page 236: Qualified Personnel Warning
EX2200 and EX2200-C Switches Hardware Guide eléctricos, e com quaisquer práticas comuns que possam prevenir possíveis acidentes. ¡Atención! Este símbolo de aviso significa peligro. Existe riesgo para su integridad física. Antes de manipular cualquier equipo, considerar los riesgos que entraña la corriente eléctrica y familiarizarse con los procedimientos estándar de prevención de accidentes.
Page 237: Warning Statement For Norway And Sweden
The equipment must be connected to an earthed mains socket-outlet. Advarsel Apparatet skal kobles til en jordet stikkontakt. Varning! Apparaten skall anslutas till jordat nätuttag. Related General Safety Guidelines and Warnings on page 211 Documentation Copyright © 2016, Juniper Networks, Inc.
Page 239: Fire Safety Requirements
In addition, you should establish procedures to protect your equipment in the event of a fire emergency. Juniper Networks products should be installed in an environment suitable for electronic equipment. We recommend that fire suppression equipment be available in the event of a fire in the vicinity of the equipment and that all local fire, safety, and electrical codes and ordinances be observed when you install and operate your equipment.
Page 240 To keep warranties effective, do not use a dry chemical fire extinguisher to control a fire at or near a Juniper Networks switch or other network device provided by Juniper. If a dry chemical fire extinguisher is used, the unit is no longer eligible for coverage under a service agreement.
Page 241: Installation Safety Guidelines And Warnings
CHAPTER 21 Installation Safety Guidelines and Warnings Installation Instructions Warning on page 219 Chassis Lifting Guidelines for EX2200 Switches on page 221 Restricted Access Warning on page 222 Ramp Warning on page 223 Rack-Mounting and Cabinet-Mounting Warnings on page 224...
Page 242 Laser and LED Safety Guidelines and Warnings for the QFX Series Grounded Equipment Warning on page 229 Connecting AC Power to an EX2200 Switch on page 149 Connecting AC Power to an EX2300 Switch Connecting AC Power to an EX3200 Switch...
Page 243: Chassis Lifting Guidelines For Ex2200 Switches
Connecting DC Power to a QFX10000 Connecting AC Power to an NFX250 Device Chassis Lifting Guidelines for EX2200 Switches Observe the following guidelines for lifting and moving an EX2200 switch: Before installing the switch, read the guidelines in “Site Preparation Checklist for EX2200 Switches”...
Page 244: Restricted Access Warning
Related General Safety Guidelines and Warnings on page 211 Documentation Installation Instructions Warning on page 219 Mounting an EX2200 Switch on page 118 Restricted Access Warning WARNING: This unit is intended for installation in restricted access areas. A restricted access area is an area to which access can be gained only by service personnel through the use of a special tool, lock and key, or other means of security, and which is controlled by the authority responsible for the location.
Page 245: Ramp Warning
Attention Ne pas utiliser une rampe dont l'inclinaison est supérieure à 10 degrés. Warnung Keine Rampen mit einer Neigung von mehr als 10 Grad verwenden. Avvertenza Non usare una rampa con pendenza superiore a 10 gradi. Copyright © 2016, Juniper Networks, Inc.
Page 246: Rack-Mounting And Cabinet-Mounting Warnings
EX2200 and EX2200-C Switches Hardware Guide Advarsel Bruk aldri en rampe som heller mer enn 10 grader. Aviso Não utilize uma rampa com uma inclinação superior a 10 graus. ¡Atención! No usar una rampa inclinada más de 10 grados Varning! Använd inte ramp med en lutning på mer än 10 grader.
Page 247 Les directives ci-dessous sont destinées à assurer la protection du personnel: Le rack sur lequel est monté le Juniper Networks switch doit être fixé à la structure du bâtiment. Si cette unité constitue la seule unité montée en casier, elle doit être placée dans le bas.
Page 248 Le seguenti direttive vengono fornite per garantire la sicurezza personale: Il Juniper Networks switch deve essere installato in un telaio, il quale deve essere fissato alla struttura dell'edificio. Questa unità deve venire montata sul fondo del supporto, se si tratta dell'unica unità...
Page 249 Para garantizar su seguridad, proceda según las siguientes instrucciones: El Juniper Networks switch debe instalarse en un bastidor fijado a la estructura del edificio. Colocar el equipo en la parte inferior del bastidor, cuando sea la única unidad en el mismo.
Page 250 EX2200 and EX2200-C Switches Hardware Guide Installation Instructions Warning on page 219 Grounded Equipment Warning on page 229 Mounting an EX2200 Switch on page 118 Mounting an EX2300 Switch Mounting an EX3200 Switch Mounting an EX3300 Switch Mounting an EX3400 Switch...
Page 251: Wall-Mounting Warnings For Ex2200 Switches
Chapter 21: Installation Safety Guidelines and Warnings Wall-Mounting Warnings for EX2200 Switches WARNING: When mounting an EX2200 switch chassis in a vertical position, orient the front panel of the chassis downward to ensure proper airflow and meet safety requirements in the event of a fire.
Page 252 EX2200 and EX2200-C Switches Hardware Guide Aviso Este equipamento deverá estar ligado à terra. Certifique-se que o host se encontra ligado à terra durante a sua utilização normal. ¡Atención! Este equipo debe conectarse a tierra. Asegurarse de que el equipo principal esté...
Page 253: Radiation And Laser Safety Guidelines And Warnings
Unterminated optical connectors can emit invisible laser radiation. The lens in the human eye focuses all the laser power on the retina, so focusing the eye directly on a laser source—even a low-power laser—could permanently damage the eye. Copyright © 2016, Juniper Networks, Inc.
Page 254: Class 1 Laser Product Warning
EX2200 and EX2200-C Switches Hardware Guide Class 1 Laser Product Warning WARNING: Class 1 laser product. Waarschuwing Klasse-1 laser produkt. Varoitus Luokan 1 lasertuote. Attention Produit laser de classe I. Warnung Laserprodukt der Klasse 1. WARNING: Avvertenza Prodotto laser di Classe 1.
Page 255: Laser Beam Warning
ópticos. WARNING: ¡Atención! No mirar fijamente el haz ni observarlo directamente con instrumentos ópticos. WARNING: Varning! Rikta inte blicken in mot strålen och titta inte direkt på den genom optiska instrument. Copyright © 2016, Juniper Networks, Inc.
Page 256: Radiation From Open Port Apertures Warning
EX2200 and EX2200-C Switches Hardware Guide Related General Safety Guidelines and Warnings on page 211 Documentation Radiation from Open Port Apertures Warning on page 234 Installation Instructions Warning on page 219 Grounded Equipment Warning on page 229 Pluggable Transceivers Supported on EX Series Switches on page 101...
Page 257 Laser and LED Safety Guidelines and Warnings for Switches on page 231 Installation Instructions Warning on page 219 Grounded Equipment Warning on page 229 Laser and LED Safety Guidelines and Warnings for the QFX Series Copyright © 2016, Juniper Networks, Inc.
Page 259: Maintenance And Operational Safety Warnings
Waarschuwing Er is ontploffingsgevaar als de batterij verkeerd vervangen wordt. Vervang de batterij slechts met hetzelfde of een equivalent type dat door de fabrikant aanbevolen is. Gebruikte batterijen dienen overeenkomstig fabrieksvoorschriften weggeworpen te worden. Copyright © 2016, Juniper Networks, Inc.
Page 260: Jewelry Removal Warning
EX2200 and EX2200-C Switches Hardware Guide Varoitus Räjähdyksen vaara, jos akku on vaihdettu väärään akkuun. Käytä vaihtamiseen ainoastaan saman- tai vastaavantyyppistä akkua, joka on valmistajan suosittelema. Hävitä käytetyt akut valmistajan ohjeiden mukaan. Attention Danger d'explosion si la pile n'est pas remplacée correctement.
Page 261 Varning! Tag av alla smycken (inklusive ringar, halsband och armbandsur) innan du arbetar på utrustning som är kopplad till kraftledningar. Metallobjekt hettas upp när de kopplas ihop med ström och jord och kan förorsaka allvarliga brännskador; metallobjekt kan också sammansvetsas med kontakterna. Copyright © 2016, Juniper Networks, Inc.
Page 262: Lightning Activity Warning
104° F (40° C) for EX6200 switches, EX8208 switches, EX8216 switches, QFX Series devices, OCX1100 switches, and XRE200 External Routing Engines and 113° F (45° C) for EX2200, EX3300, EX3200, EX4200, EX4300, EX4500, and EX4550 switches. To prevent airflow restriction, allow at least 6 in.
Page 263: Product Disposal Warning
40° C. Ettei ilmanvaihto estyisi, tuuletusaukkojen ympärille on jätettävä ainakin 15,2 cm tilaa. Attention Pour éviter toute surchauffe des routeurs de la gamme Juniper Networks switch, ne l'utilisez pas dans une zone où la température ambiante est supérieure à 40° C. Pour permettre un flot d'air constant, dégagez un espace d'au moins 15,2 cm autour des ouvertures de ventilations.
Page 264 EX2200 and EX2200-C Switches Hardware Guide Waarschuwing Dit produkt dient volgens alle landelijke wetten en voorschriften te worden afgedankt. Varoitus Tämän tuotteen lopullisesta hävittämisestä tulee huolehtia kaikkia valtakunnallisia lakeja ja säännöksiä noudattaen. Attention La mise au rebut définitive de ce produit doit être effectuée conformément à...
Page 265: Electrical Safety Guidelines And Warnings
The intrabuilding ports on the device are suitable for connection to intrabuilding or unexposed wiring or cabling only. The addition of primary protectors is not sufficient protection for connecting these interfaces metallically to OSP wiring. Copyright © 2016, Juniper Networks, Inc.
Page 266: Action To Take After An Electrical Accident
EX2200 and EX2200-C Switches Hardware Guide CAUTION: Before removing or installing components of a device, attach an electrostatic discharge (ESD) grounding strap to an ESD point and place the other end of the strap around your bare wrist. Failure to use an ESD grounding strap could result in damage to the switch.
Page 267: Prevention Of Electrostatic Discharge Damage
When handling any component that is subject to ESD damage and that is removed from the device, make sure the equipment end of your ESD grounding strap is attached to the ESD point on the chassis. Copyright © 2016, Juniper Networks, Inc.
Page 268: Figure 61: Placing A Component Into An Antistatic Bag
General Safety Guidelines and Warnings on page 211. Documentation EX2200 Switches Hardware Overview on page 3 for the ESD point location. See Rear Panel of an EX3200 Switch for the ESD point location. See Rear Panel of an EX3300 Switch for the ESD point location.
Page 269: Ac Power Electrical Safety Guidelines
AC-powered devices are shipped with a three-wire electrical cord with a grounding-type plug that fits only a grounding-type power outlet. Do not circumvent this safety feature. Equipment grounding must comply with local and national electrical codes. Copyright © 2016, Juniper Networks, Inc.
Page 270 General Electrical Safety Guidelines and Warnings on page 243 Multiple Power Supplies Disconnection Warning on page 259 Connecting AC Power to an EX2200 Switch on page 149 Connecting AC Power to an EX3200 Switch Connecting AC Power to an EX3300 Switch...
Page 271: Ac Power Disconnection Warning
Warnung Bevor Sie an einem Chassis oder in der Nähe von Netzgeräten arbeiten, ziehen Sie bei Wechselstromeinheiten das Netzkabel ab bzw. Avvertenza Prima di lavorare su un telaio o intorno ad alimentatori, scollegare il cavo di alimentazione sulle unità CA. Copyright © 2016, Juniper Networks, Inc.
Page 272: Dc Power Electrical Safety Guidelines
EX2200 and EX2200-C Switches Hardware Guide Advarsel Før det utføres arbeid på kabinettet eller det arbeides i nærheten av strømforsyningsenheter, skal strømledningen trekkes ut på vekselstrømsenheter. Aviso Antes de trabalhar num chassis, ou antes de trabalhar perto de unidades de fornecimento de energia, desligue o cabo de alimentação nas unidades de corrente alternada.
Page 273 To supply sufficient power, terminate the DC input wiring on a facility DC source that is capable of supplying: Minimum of 7.5 A at –48 VDC for EX2200, EX3300, and EX3400 switches Minimum of 8 A at –48 VDC for EX3200 and EX4200 switches Minimum of 20 A at –48 VDC for EX4300, EX4500, EX4550, and...
Page 274 DC Power Wiring Sequence Warning on page 255 DC Power Wiring Terminations Warning on page 257 Connecting DC Power to an EX2200 Switch on page 151 Connecting DC Power to an EX3200 Switch Connecting DC Power to an EX3400 Switch...
Page 275: Dc Power Disconnection Warning
Advarsel Før noen av disse prosedyrene utføres, kontroller at strømmen er frakoblet likestrømkretsen. Sørg for at all strøm er slått AV. Dette gjøres ved å lokalisere strømbryteren på brytertavlen som betjener likestrømkretsen, slå strømbryteren AV og teipe bryterhåndtaket på strømbryteren i AV-stilling. Copyright © 2016, Juniper Networks, Inc.
Page 276: Dc Power Grounding Requirements And Warning
EX2200 and EX2200-C Switches Hardware Guide Aviso Antes de executar um dos seguintes procedimentos, certifique-se que desligou a fonte de alimentação de energia do circuito de corrente contínua. Para se assegurar que toda a corrente foi DESLIGADA, localize o disjuntor no painel que serve o circuito de corrente contínua e coloque-o na posição OFF...
Page 277: Dc Power Wiring Sequence Warning
Wire the DC power supply using the appropriate lugs. When connecting power, the proper wiring sequence is ground to ground, +RTN to +RTN, then –48 V to –48 V. When disconnecting power, the proper wiring Copyright © 2016, Juniper Networks, Inc.
Page 278 EX2200 and EX2200-C Switches Hardware Guide sequence is –48 V to –48 V, +RTN to +RTN, then ground to ground. Note that the ground wire must always be connected first and disconnected last. Waarschuwing De juiste bedradingsvolgorde verbonden is aarde naar aarde, +RTN naar +RTN, en –48 V naar –...
Page 279: Dc Power Wiring Terminations Warning
à circuit fermé ou du type à plage ouverte avec cosses rebroussées. Ces douilles terminales doivent être de la taille qui convient aux fils et doivent être refermées sur la gaine isolante et sur le conducteur. Copyright © 2016, Juniper Networks, Inc.
Page 280 EX2200 and EX2200-C Switches Hardware Guide Warnung Wenn Litzenverdrahtung erforderlich ist, sind zugelassene Verdrahtungsabschlüsse, z.B. für einen geschlossenen Regelkreis oder gabelförmig, mit nach oben gerichteten Kabelschuhen zu verwenden. Diese Abschlüsse sollten die angemessene Größe für die Drähte haben und sowohl die Isolierung als auch den Leiter festklemmen.
Page 281: Multiple Power Supplies Disconnection Warning
Warnung Das Gerät ist für die Verwendung mit TN-Stromsystemen ausgelegt. Avvertenza Il dispositivo è stato progettato per l'uso con sistemi di alimentazione TN. Advarsel Utstyret er utfomet til bruk med TN-strømsystemer. Aviso O dispositivo foi criado para operar com sistemas de corrente TN. Copyright © 2016, Juniper Networks, Inc.
Page 282 EX2200 and EX2200-C Switches Hardware Guide ¡Atención! El equipo está diseñado para trabajar con sistemas de alimentación tipo TN. Varning! Enheten är konstruerad för användning tillsammans med elkraftssystem av TN-typ. Related General Safety Guidelines and Warnings on page 211 Documentation...
Page 283: Agency Approvals And Compliance Statements
FCC 47CFR Part 15 Class A (USA) EN 55022 Class A Emissions (Europe) ICES-003 Class A VCCI Class A (Japan) AS/NZS CISPR 22 Class A (Australia/New Zealand) CISPR 22 Class A EN 55024 EN 300386 Copyright © 2016, Juniper Networks, Inc.
Page 284: Compliance Statements For Emc Requirements For Ex Series Switches
EX2200 and EX2200-C Switches Hardware Guide EN 61000-3-2 Power Line Harmonics EN 61000-3-3 Voltage Fluctuations and Flicker EN 61000-4-2 ESD EN 61000-4-3 Radiated Immunity EN 61000-4-4 EFT EN 61000-4-5 Surge EN 61000-4-6 Low Frequency Common Immunity EN 61000-4-11 Voltage Dips and Sags...
Page 285: European Community
Japan The preceding translates as follows: This is a Class A device. In a domestic environment this device might cause radio interference, in which case the user needs to take adequate measures. VCCI-A Copyright © 2016, Juniper Networks, Inc.
Page 286: Korea
EX2200 and EX2200-C Switches Hardware Guide Korea Korean Class A Warning The preceding translates as follows: This equipment is Industrial (Class A) electromagnetic wave suitability equipment and seller or user should take notice of it, and this equipment is to be used in the places except...
Page 287: Nonregulatory Environmental Standards
The battery return connection is to be treated as an Isolated DC return (DC-I), as defined in GR-1089-CORE. Related Agency Approvals for EX Series Switches on page 261 Documentation Compliance Statements for Acoustic Noise for EX Series Switches on page 266 Copyright © 2016, Juniper Networks, Inc.
Page 288: Compliance Statements For Acoustic Noise For Ex Series Switches
EX2200 and EX2200-C Switches Hardware Guide Compliance Statements for Acoustic Noise for EX Series Switches This topic applies to hardware devices in the EX Series product family, which includes EX Series switches, the EX Series Redundant Power System (RPS), and the XRE200 External Routing Engine.

This manual is also suitable for:

Ex2200-c

Juniper EX2200 Hardware Manual

Chapter 1 System Overview

Chapter 2 Chassis Components and Descriptions

Chapter 3 Cooling System and Airflow

Chapter 4 Power Supplies

Chapter 5 Viewing System Information

Chapter 6 Preparation Overview

Chapter 7 Power Specifications and Requirements

Chapter 8 Transceiver and Cable Specifications

Chapter 9 Pinout Specifications

Chapter 10 Unpacking the Switch

Chapter 11 Installing the Switch

Chapter 12 Connecting the Switch to Power

Chapter 13 Switch

Chapter 14 Performing Initial Configuration

Chapter 15 Replacing Transceiver

Chapter 16 Maintaining and Replacing Fiber-Optic Cable

Chapter 17 Contactingcustomersupportandreturningthe Chassisor

Chapter 18 Alarms and Syslog Messages

Chapter 19 General Safety Guidelines and Warnings

Chapter 20 Fire Safety Requirements

Chapter 21 Installation Safety Guidelines and Warnings

Chapter 22 Radiation and Laser Safety Guidelines and Warnings

Chapter 23 Maintenance and Operational Safety Warnings

Chapter 24 Electrical Safety Guidelines and Warnings

Quick Links

Related Manuals for Juniper EX2200

Summary of Contents for Juniper EX2200
