Field Service Ver. 3.0 Jan. 2008
16.5.3

C0211: Manual feed up/down abnormality

Transport motor (M1)
Manual pick-up solenoid (SL1)
Manual lift-up position sensor (PS17)
Step
2
Check the M1 connector for proper connec-
1
tion and correct as necessary.
Check the connector of M1 for proper drive
2
coupling and correct as necessary.
3 PS17 I/O check, sensor check
4 SL1 operation check
5 M1 operation check
6 Change SL1
7 Change M1
8 Change PRCB
16.5.4

C0301: Suction fan motor's failure to turn

Suction fan motor (FM8)
Step
Check the FM8 connector for proper con-
1
nection and correct as necessary.
Check the fan for possible overload and
2
correct as necessary.
3 FM8 operation check
2
4 Change the right door assy
5 Change PRCB
Relevant parts
Action
Relevant parts
Action
Printer control board (PRCB)
WIRING DIAGRAM
Control signal
—
—
PRCB CN6-7 (ON)
PRCB CN6-4 (ON)
PRCB CN34-10 (REM)
PRCB CN34-13 (LOCK)
—
—
—
Printer control board (PRCB)
WIRING DIAGRAM
Control signal
—
—
PRCB CN3-2 (ON)
PRCB CN3-3 (LOCK)
—
—
16. Malfunction code
Location (Electri-
cal component)
—
—
D-2
D-1
D-23
—
—
—
Location (Electri-
cal component)
—
—
D-5
—
—
517
