Field Service Ver. 3.0 Jan. 2008
5.5

Firmware rewriting by compact flash

• The firmware is updated using the compact flash.
5.5.1

Updating method

NOTE
• NEVER remove or insert the compact flash card with the machine power turned
ON.
1. Turn OFF the main power switch.
2. Open the rear right door.
[1]
[1]
5. Turn ON the main power switch and the sub power switch.
6. Control panel shows F/W items to be updated.
[2]
A02EF2C039DA
A02EF2C040DA
5. Firmware upgrade
3. Remove the screw [1] and the metal
blanking plate [2].
4. Insert the compact flash card [1] into
the slot.
67
