Page 1 ALAXALA AX6300S Hardware Instruction Manual AX63S-H001-50X Reading and storing this manual: Before you use the equipment, carefully read the manual and make sure that you understand all safety precautions. After reading the manual, store it in a convenient place for easy reference.
Page 2 If you export this product, please check all restrictions, such as Japan's Foreign Exchange and Foreign Trade Law and USA export control laws and regulations, and carry out all required procedures. If you require more information, please contact an ALAXALA Networks Corporation sales representative. Trademarks - Ethernet is a product name of Xerox Corporation.
Page 3: About This Manual
Preface About this manual This manual provides hardware instructions for the ALAXALA AX6300S series of multilayer Switches. Before you operate the Switch, read this manual carefully and make sure that you understand all instructions and safety precautions. After reading the manual, store it in a convenient place for easy reference.
Page 4 Preface Reading sequence of AX6300S series manuals NOTE The Troubleshooting Guide is common to the AX2400S, AX3600S, AX6300S, AX6600S, and AX6700S series.
Page 5 The term switch (lower-case "s") might refer to a Switch, another type of switch from the current vendor, or a switch from another vendor. The context decides the meaning. How to obtain this manual The AX6300S series manuals are available on the ALAXALA website at the following address: http://www.alaxala.com/en/index.html Acronyms...
Page 7: Table Of Contents
Contents 1. Components Overview ......................1 1.1 Switch..........................2 1.1.1 AX6304S ......................2 1.1.2 AX6308S ......................6 1.1.3 Accessories....................10 1.2 Fan unit (FAN)......................12 1.2.1 FAN-11 ......................12 1.3 Power supply unit (PS)....................13 1.3.1 PS-A11......................13 1.3.2 PS-D11......................14 1.4 Management and switching unit (MSU) ..............
Page 8 Contents 3.3 Terminals and connection cables................84 3.3.1 When connecting an operation terminal to the CONSOLE port ....84 3.3.2 When connecting an operation terminal to the MANAGEMENT port.... 84 3.3.3 Connecting a modem to the AUX port ............86 4.
Page 9: Safety Information
Using the AX6300S series switches correctly and safely This guide provides important information for ensuring safe use of the AX6300S series switches. Please read this guide completely before using your Switch. Keep this guide handy after reading it, so that it is available for later reference.
Page 10 Safety Information If anything seems wrong, immediately turn off the power. If smoke or an unusual smell is emanating from the Switch, or if liquid is spilled into the Switch or a foreign object falls into the Switch, immediately turn off power to the Switch as described below.
Page 11: Ground The Switch
Safety Information Ensure that the capacity for incoming current to the distribution board is greater than the operating current of the circuit breaker. Ensure that the capacity for incoming current to the distribution board is greater than the operating current of the circuit breaker. If it is not, the circuit breaker might not operate properly in the event of a failure, which could result in fire.
Page 12 Safety Information Place an insulation cover over the 0 V and −48 V terminals of a DC power cable. Place an insulation cover over the 0 V and −48 V terminals of a DC power cable before using them. Using the terminals without an insulation cover could result in fire or electric shock.
Page 13 Safety Information Handle power cables carefully. Do not place anything heavy on a power cable. Do not pull, bend, or modify a cable. Doing so could damage the cable, resulting in fire or electric shock. If the power cable is covered with a carpet or the like, it is easy to forget that the cable is there and to place something heavy on it.
Page 14 Safety Information When pressing the reset button, do not use anything with a fragile tip, or anything that might become caught in the Switch, such as a pin or paper clip. When pressing the reset button on the front panel, do not use anything with a fragile tip, or anything that might become caught in the Switch, such as a pin or paper clip.
Page 15 Safety Information Do not install the Switch in a dusty or humid location. Do not install the Switch in a dusty or humid location. Doing so could result in fire or electric shock. Condensation might form on the surfaces and the inside of the Switch if it is moved from a cold location to a warm location.
Page 16 Safety Information Do not obstruct the ventilation slots. Do not obstruct the ventilation slots of the Switch. Doing so causes heat to accumulate inside the Switch, and could result in fire. Maintain a space of at least 70 mm around the ventilation slots. Safety-8...
Page 17 Safety Information Do not allow hair or objects near the ventilation slots. Because a Switch is equipped with internal cooling fan units, do not allow anything near ventilation slots. Doing so causes heat to accumulate inside the Switch and could cause a failure. Do not allow hair or other light material or objects near the ventilation slots because they might be sucked into the Switch, resulting in injury.
Page 18 Safety Information When removing a fan unit, do not place your hands near the fan if it is rotating. Immediately after a fan unit is removed, the blades might still be rotating. While the fan blades are rotating, do no place your hands near them. Doing so might result in injury.
Page 19 Safety Information Cleaning Remove dust on and around the Switch regularly. In addition to causing the switch to stop, accumulated dust could result in fire or electric shock. Safety-11...
Page 20 Do not attach any labels to a transceiver. A label attached to the transceiver indicates that the transceiver is a standard product from ALAXALA or another manufacturer. However, such labels are attached where they do not interfere with heat dissipation from the transceiver or the mechanism that prevents the transceiver from coming loose from the cage.
Page 21 Safety Information When replacing a fan unit with the Switch turned on, observe the time limit. When replacing a fan unit with the Switch on, you must remove and replace the unit within one minute. If the operation takes longer than one minute, the temperature inside the Switch will rise and possibly cause a failure.
Page 22 Safety Information Install an optional module carefully. Follow the procedure below when you install an optional module. Failure to do so could result in a failure or a malfunction of the Switch. Open the levers as shown in the figure. While holding the levers, push the optional module carefully until the levers touch the Switch.
Page 23 Safety Information Do not use a TV or a radio near a Switch. Placing a Switch near a TV or a radio could affect both devices. If you hear noise on the TV or radio, do the following: Place the Switch as far away as possible from the TV or radio. Adjust the orientation of the TV or radio antenna.
Page 24 Safety Information Disposing of a Switch When disposing of a Switch, you should either follow local ordinances or regulations or contact your local waste disposal and treatment facility. Safety-16...
Page 25: Components Overview
Components Overview This chapter provides an overview of the various parts of the Switch. 1.1 Switch 1.2 Fan unit (FAN) 1.3 Power supply unit (PS) 1.4 Management and switching unit (MSU) 1.5 Network interface unit (NIF) 1.6 Memory card (MC) 1.7 Transceiver 1.8 Blank panel 1.9 Power cable...
Page 26: Switch
1. Components Overview 1.1 Switch The AX6300S series switches are Layer 3 switches suitable for the backbone of a large-scale independent network, the core of a medium-scale network, or the edge of a service provider's Layer 3 network. The following are the features of AX6300S series switches:...
Page 27 1. Components Overview (1) External appearance Figure 1-1 Front view (1) Management and switching unit (MSU) slot (2) Network interface unit (NIF) slot (3) Rack fixture (4) Handles (5) Wrist strap terminal NOTE A rack fixture attached to a Switch is used to secure the rack pillars and the front of the Switch so that they are flat when the Switch is installed in a rack.
Page 28 1. Components Overview (1) Power supply unit (PS) slot (2) Fan unit (FAN) slot (3) Handles Figure 1-3 Rear view (with a DC power supply unit installed) (1) Power supply unit (PS) slot (2) Fan unit (FAN) slot (3) Handles (2) Slot number The following figures show the slot numbers of optional modules for the Switch.
Page 29 1. Components Overview Figure 1-6 Rear of the Switch (with a DC power supply unit installed) NOTE A network interface unit comes in a single-size model and a double-size model. The NIF number when a double-size network interface unit is installed is the number indicated by *1. (3) Number of installed power supply units and installation location NOTE Power supply units come in an AC model and a DC model.
Page 30: Ax6308S
1. Components Overview Table 1-3 Installation locations of DC power supply units Power supply Power supply Basic Redundancy redundancy redundancy method 1+1 redundancy None Required NOTE If you install a power supply unit in a location other than those above, it will not operate properly.
Page 31 1. Components Overview (2) Network interface unit (NIF) slot (3) Rack fixture (4) Handles (5) Wrist strap terminal NOTE A rack fixture attached to a Switch is used to secure the rack pillars and the front of the Switch so that they are flat when the Switch is installed in a rack.
Page 32 1. Components Overview Figure 1-9 Rear view (with a DC power supply unit installed) (1) Power supply unit (PS) slot (2) Fan unit (FAN) slot (3) Handles (2) Slot number The following figures show the slot numbers of optional modules for the Switch. Figure 1-10 Front of the Switch NOTE A network interface unit comes in a single-size model and a...
Page 33 1. Components Overview Figure 1-11 Rear of the Switch (with an AC power supply unit installed) NOTE A power supply unit can be installed in the PS1 to PS4 slots. The PS5 and PS6 slots cannot be used. Figure 1-12 Rear of the Switch (with a DC power supply unit installed) A power supply unit can be installed in the PS1 and PS2 slots.
Page 34: Accessories
1.1.3 Accessories The items listed in Table 1-6 Switch accessories are shipped with the Switch when it is shipped from the factory. Table 1-6 Switch accessories Name Quan Remarks tity Before using an AX6300S series switch Using the Switch Safely...
Page 35 1. Components Overview (1) Before using an AX6300S series switch This document lists the items supplied with a Switch when it is shipped from the factory. (2) Using the Switch Safely This document includes important notes regarding safe use of the Switch.
Page 36: Fan Unit (Fan)
1. Components Overview 1.2 Fan unit (FAN) 1.2.1 FAN-11 The FAN-11 fan unit is common to AX6300S series switches, and is included in each Switch. (1) External appearance Figure 1-13 External appearance (1) Handles (2) Installation screw (3) LEDs (2) LED...
Page 37: Power Supply Unit (Ps)
Switch. If you install both units, they will not operate properly. 1.3.1 PS-A11 The PS-D11 power supply unit is common to AX6300S series switches. This power supply unit supports 100 V AC and 200 V AC. (1) External appearance...
Page 38: Ps-D11
NOTE For the specifications defined by ALAXALA for power cables, see 2.4.2 Power supply facility for 200 V AC. 1.3.2 PS-D11 The PS-D11 power supply unit is common to AX6300S series switches. The power supply unit supports −48 V DC.
Page 39 1. Components Overview (1) External appearance Figure 1-16 External appearance (1) ALARM LED (2) POWER LED (3) Terminal for measuring voltage (4) Cable clamp (5) Terminal board cover (6) Handles (7) Installation screw (8) Circuit breaker (9) Terminal board A power supply unit has a terminal for measuring voltage. This terminal is used for inspection before the unit is shipped from the factory.
Page 40 When using a Switch in a −48 V DC environment, use only a power cable that meets ALAXALA specifications. Using another cable could result in fire or electric shock. NOTE For the specifications defined by ALAXALA for power cables, see 2.4.3 Power supply facility for −48 V DC.
Page 41: Management And Switching Unit (Msu)
1. Components Overview 1.4 Management and switching unit (MSU) The following figures show the external appearance of the management and switching units. Figure 1-17 External appearance of the MSU-1A and the MSU-1B (1) Memory (2) Installation screw (3) Lever Figure 1-18 External appearance of the MSU-1A1 and the MSU-1B1 (1) Memory (2) Installation screw (3) Lever...
Page 42: Msu-1A And Msu-1A1
Management in the Software Manual Configuration Guide Vol. 1. 1.4.1 MSU-1A and MSU-1A1 The MSU-1A and MSU-1A1 management and switching units (standard table size) are common to the AX6300S series switches. The MSU-1A and the MSU-1A1 have the following hardware specifications: Memory card slot: 1 slot AUX port (RS-232C): 1 port (In the MSU-1A, the AUX port is supported by software version 10.3 and later.)
Page 43 1. Components Overview that can be displayed on the LCD. Figure 1-20 External appearance of the system operation panel (1) LCD (2) Back button (3) Enter button (4) Forward button NOTE If you press the back and forward buttons at the same time, you can perform a lamp test.
Page 44 1. Components Overview Name Type Status Description LED: Green Indicates the memory Green: The memory card is being card status. accessed. (Do not remove the memory card.) Off: The memory card is in idle mode. (A memory card can be plugged in or removed.) RESET Switch...
Page 45: Msu-1B And Msu-1B1
1.4.2 MSU-1B and MSU-1B1 This is a management and switching unit (extended table size type) which is used in common among the AX6300S series switches. The MSU-1B and the MSU-1B1 have the following hardware specifications: Memory card slot: 1 slot AUX port (RS-232C): 1 port (In the MSU-1B, the AUX port is supported by software version 10.3 and later.)
Page 46 1. Components Overview Figure 1-22 External appearance of the system operation panel (1) LCD (2) Back button (3) Enter button (4) Forward button NOTE If you press the back and forward buttons at the same time, you can perform a lamp test. For details about operations in addition to the lamp test and the information that can be displayed on the LCD, see 11 Switch Management in the Software Manual Configuration Guide Vol.
Page 47 1. Components Overview Name Type Status Description LED: Green Indicates the memory Green: The memory card is being card status. accessed. (Do not remove the memory card.) Off: The memory card is in idle mode. (A memory card can be plugged in or removed.) RESET Switch...
Page 48 1. Components Overview...
Page 49: Network Interface Unit (Nif)
1. Components Overview 1.5 Network interface unit (NIF) The following table lists network interface units supported by the Switch. Table 1-12 Network interface units Size Name Interface 10/100/1000BASE-T 1000BASE-X 10GBASE-R Single-size NH1G-24T 24 ports NH1G-16S 16 ports NH1G-24S 24 ports NH1GS-6M 4 ports 2 ports...
Page 50 1. Components Overview Front view The front view is shown below. For information about LEDs, see Table 1-13 LED indications. Figure 1-24 Front view (1) STATUS LED (2) LINK/TR LED (3) Ethernet port (10/100/1000BASE-T) Table 1-13 LED indications Name Type Status Description STATUS...
Page 51 1. Components Overview #6: Always turns off if the interface port LED is set to off. When an operation key on the system operation panel is used, the LED lights up, and the operating status can be checked. If no keys are used for 60 seconds, the LED turns off again. NOTE If no system recovery is set and a failure occurs in a Switch, the Switch can stay stopped without recovering the failed part.
Page 52 1. Components Overview Name Type Status Description LINK/TR LED: Green or Indicates the Indicates the operating status of the Orange operating status of Ethernet port. the Ethernet port. Green: A link is established. Blinking green: A frame is being sent or received.
Page 53 1. Components Overview Figure 1-26 Front view (1) STATUS LED (2) LINK/TR LED (3) Ethernet port (1000BASE-X) Table 1-15 LED indications Name Type Status Description LED: Green, Indicates the STATUS Green: Operation is possible. orange, or red operating status of Orange: A reset is in progress.
Page 54 1. Components Overview NOTE If no system recovery is set and a failure occurs in a Switch, the Switch can stay stopped without recovering the failed part. This function is supported by software version 10.3 and later. (4) NH1GS-6M The NH1GS-6M is a network interface unit with the following hardware specifications: Ethernet port (10/100/1000BASE-T): 4 ports Ethernet port (1000BASE-X): 2 ports...
Page 55 1. Components Overview Table 1-16 LED indications Name Type Status Description LED: Green, Indicates the operating STATUS Green: Operation is possible. orange, or red status of the network Orange: A reset is in progress. interface unit. Blinking green: Startup is in progress.
Page 56 1. Components Overview Front view The front view is shown below. For information about LEDs, see Table 1-17 LED indications. Figure 1-28 Front view (1) STATUS LED (2) LINK LED (3) T/R LED (4) Ethernet port (10GBASE-R) Table 1-17 LED indications Name Type Status...
Page 57 1. Components Overview the system operation panel is used, the LED lights up, and the operating status can be checked. If no keys are used for 60 seconds, the LED turns off again. If no system recovery is set and a failure occurs in a Switch, the NOTE Switch can stay stopped without recovering the failed part.
Page 58 1. Components Overview Name Type Status Description LED: Green Blinking green: A frame is being sent or received. Off: No frames are being sent or received. #1: A network interface unit can be turned off by the Inactivate operation from the system operation panel or by entering a command from the operation terminal.
Page 59 1. Components Overview (1) STATUS LED (2) LINK LED (3) T/R LED (4) Ethernet port (10GBASE-R) Table 1-19 LED indications Name Type Status Description STATUS LED: Green, Indicates the operating Green: Operation is possible. orange, or red status of the network Orange: A reset is in progress.
Page 60: Double-Size
1. Components Overview 1.5.2 Double-size The external appearance of a double-size network interface unit is shown below. Figure 1-31 External appearance (1) Installation screw (2) Lever (3) Interface port (1) NH1G-48T The NH1G-48T is a network interface unit with the following hardware specification: Ethernet port (10/100/1000BASE-T): 48 ports Front view The front view is shown below.
Page 61 1. Components Overview Table 1-20 LED indications Name Type Status Description LED: Green, Indicates the STATUS Green: Operation is possible. orange, or red operating status of the Orange: A reset is in progress. network interface unit. Blinking green: Startup is in progress.
Page 62: Memory Card (Mc)
This memory card is an SD memory card with a capacity of 128 MB. Figure 1-33 External appearance Label: ALAXALA SD128 NOTE Make sure that you use standard ALAXALA memory cards labeled as shown in the figure. If non-standard products are used, correct operation is not guaranteed. NOTE...
Page 63: Transceiver
Attaching a label to a location that interferes with these functions could cause a malfunction in the transceiver or damage to the Switch. NOTE Make sure that you use standard ALAXALA products labeled as shown in the figures. If non-standard products are used, correct operation is not guaranteed.
Page 64 1. Components Overview (1) SFP-SX Figure 1-34 External appearance (1) Label: ALAXALA SFP-SX Label color: Black (2) Lever color: Black (2) SFP-SX2 Figure 1-35 External appearance (1) Label: ALAXALA SFP-SX2 Label color: White (2) Lever color: Silver (3) SFP-LX Figure 1-36 External appearance...
Page 65 (5) SFP-LHB Figure 1-38 External appearance (1) Label: ALAXALA SFP-LHB Label color: White (2) Lever color: Yellow-green (6) SFP-BX1U Figure 1-39 External appearance (1) Label at the back of the transceiver: ALAXALA SFP-BX1U Label color: White (2) Lever color: Blue...
Page 66: Xfp
1. Components Overview (7) SFP-BX1D Figure 1-40 External appearance (1) Label at the back of the transceiver: ALAXALA SFP-BX1D Label color: White (2) Lever color: Magenta (8) SFP-BX4U Figure 1-41 External appearance (1) Label at the back of the transceiver: ALAXALA SFP-BX4U...
Page 67 Attaching a label to a location that interferes with these functions could cause a malfunction in the transceiver or damage to the Switch. NOTE Make sure that you use standard ALAXALA products labeled as shown in the figures. If non-standard products are used, correct operation is not guaranteed.
Page 68 1. Components Overview (2) XFP-LR Figure 1-44 External appearance (1) Label: ALAXALA XFP-LR (2) Lever color: Blue (3) XFP-ER Figure 1-45 External appearance (1) Label: ALAXALA XFP-ER (2) Lever color: Red (4) XFP-ZR Figure 1-46 External appearance (1) Label: ALAXALA XFP-ZR...
Page 69: Blank Panel
1. Components Overview 1.8 Blank panel When a slot does not contain an optional module, a blank panel is inserted in the slot. The blank panel serves the following purposes: Ensures the flow of air inside the Switch. Reduces radio interference from the Switch. Protects the Switch from radio interference by another device.
Page 70 1. Components Overview (3) BPNL-NF11 The blank panel for a network interface unit. Figure 1-49 BPNL-NF11...
Page 71: Power Cable
Doing so could result in fire or electric shock. NOTE If an optional ALAXALA power cable cannot be used with your power supply facility, use a power cable that meets ALAXALA specifications. For information about ALAXALA specified power cables, see 2.4.2 Power supply facility for 200 V AC.
Page 72: Rack Fixture
1. Components Overview 1.10 Rack fixture A bracket (sold separately) used to attach the Switch to a 19-inch cabinet rack. With this bracket, you can fix a Switch so that it is recessed 50 mm from the rack pillar. 1.10.1 BRK-11 The BRK-11 is a rack fixture for the AX6304S.
Page 73 1. Components Overview (1) External appearance Figure 1-54 BRK-12 (1) Left: L (2) Right: R (2) Accessories Installation screws for the BRK-12. Figure 1-55 Screws (M4 x 8, 8 screws)
Page 74: Support Bracket
1. Components Overview 1.11 Support bracket 1.11.1 BRK-14 The BRK-14 support brackets are a pair of brackets used for installation of the AX6304S in a rack. When the support brackets are used together with the rack fixture, the Switch can be installed in the rack without using a guide rail.
Page 75: Preparation For Installation
Preparation for Installation This chapter describes the environment conditions and preparations required for installation of the Switch. Before preparing for the installation, read this chapter carefully and be sure that you understand all instructions and notes within. 2.1 Preparation workflow 2.2 Installation conditions 2.3 Carrying a Switch 2.4 Power supply facility...
Page 76: Preparation Workflow
2. Preparation for Installation 2.1 Preparation workflow The workflow to prepare for installation is shown in Figure 2-1 Flowchart of preparation for installation. Be sure to schedule enough time to complete the following work before installing the Switch: power supply work, communications equipment work, and laying down LAN cables.
Page 77: Installation Conditions
2. Preparation for Installation 2.2 Installation conditions The general installation requirements for the Switch are described below. The installation environment must meet these requirements. Table 2-1 Switch installation conditions Item Specifications AX6304S AX6308S When an AC When a DC When an AC When a DC power supply power supply...
Page 78 2. Preparation for Installation #4: The value is measured at 1 m from the side of the Switch. The number of rotations of the fan varies according to the intake temperature. Because of this, the value of the noise changes. #5: According to JIS Z 8813 Measuring Methods for Suspended Particulate Matter Concentration in Air.
Page 79: Carrying A Switch
2. Preparation for Installation 2.3 Carrying a Switch (1) Number of people The weight of the Switch is shown in the table below. The Switch must be installed and carried by at least three people. Table 2-2 Number of people required to carry a Switch: Model Weight Number of people...
Page 80 Also, the fan unit or power supply unit might become deformed, resulting in fire or electric shock. NOTE To install a Switch in an elevated location, ALAXALA Networks Corporation recommends that you use a hand lifter or equivalent device.
Page 81: Power Supply Facility
2. Preparation for Installation 2.4 Power supply facility 2.4.1 Power supply facility for 100 V AC (1) Outlet Use an outlet shown below, that conforms to the JIS and NEMA standards. This type of electrical outlet is available from electrical equipment suppliers. Table 2-3 Electrical outlet standards Standards Specifications...
Page 82: Power Supply Facility For 200 V Ac
200 V AC environment. For information about the 200 V AC power cable, see 1.9 Power cable. NOTE If an optional ALAXALA power cable cannot be used with your power supply facility, use a power cable that meets the following ALAXALA specifications.
Page 83 The above outlet supports the ALAXALA 200 V AC optional power NOTE cable. If you do not want to use the ALAXALA optional power cable, use the outlet below. This type of electrical outlet is available from electrical equipment suppliers.
Page 84: Power Supply Facility For −48 V Dc
2. Preparation for Installation (4) Requirements for the incoming current to the distribution board The capacity of the incoming current to the distribution board must be greater than that of the breaker operating current described in the above (3) Distribution board. Ensure that the capacity for incoming current to the distribution board is greater than the operating current of the circuit breaker.
Page 85 2. Preparation for Installation Figure 2-8 0 V and −48 V terminals (1) 17.8 mm (max) (2) 17.5 mm (max) (3) 6.3 to 6.9 mm (4) Insulation cover Place an insulation cover over the 0 V and -48 V terminals. Using the terminals without an insulation cover could result in fire or electric shock.
Page 86 2. Preparation for Installation Figure 2-10 Terminal board of the DC power supply unit (1) Cable clamp (2) 0V terminal (screw: M6) (3) −48V terminal (screw: M6) (4) Ground terminal (screw: M6) (2) Distribution board Use circuit breakers on the branch circuit supplying power to the Switch. See the following table for the rated breaker capacity and the required quantity.
Page 87 2. Preparation for Installation NOTE Generally, the breaker operating current is greater than the rated current. Check the specifications of the circuit breaker. In addition, if a Switch is turned on, the inrush current described in Table 2-12 Inrush current flows. Consider measures for avoiding a voltage drop in the power supply facility caused by the inrush current.
Page 88: Notes On Electric Noise
2. Preparation for Installation 2.5 Notes on electric noise Electric noise emitted by other devices can cause failures. Note the following points when designing a plan for the power supply facility: The branch circuit of the power supply to the Switch should not be connected to devices that use a relay, micro-switches, or other means to power them on and off repeatedly, such as air conditioners.
Page 89: Leakage Current
2. Preparation for Installation 2.6 Leakage current The Switch is equipped with a noise filter to prevent failure due to electric noise. As a result, a maximum leakage current of 3.5 mA flows through the protective ground line (Type D grounding). Be sure to consider whether the installation of a residual current circuit breaker is required for compliance with the Fire Service Act or other legislation.
Page 90: Environment Conditions
2. Preparation for Installation 2.7 Environment conditions (1) Dust Because cooling fan units are mounted in a Switch, do not install them in a humid or dusty place. Dust requirements for the Switch are as follows: Airborne dust concentration: 0.15 mg/m or less (according to JIS Z 8813 Measuring Methods for Suspended Particulate Matter Concentration in Air: General Requirements)
Page 91 2. Preparation for Installation (8) Spraying When spraying pesticide or disinfectant in the room where the Switch is installed, cover the Switch beforehand to prevent direct exposure to chemicals. (9) Earthquake countermeasures Earthquakes can cause Switches to shift, fall over, or fall out of windows, possibly resulting in bodily injury or death.
Page 92: Installation Location
#1: A rack fixture attached to a Switch supports a 19-inch cabinet rack conforming to the EIA standard. To use a 19-inch cabinet rack conforming to the JIS standard, contact an ALAXALA Networks Corporation sales representative. #2: When using the Switch in a 200 V AC environment, ensure 100 mm of space behind the Switch.
Page 93 2. Preparation for Installation can use an optional fixture that secures the Switch so that it is recessed 50 mm from the rack pillar. For information about this separately sold fixture, see 1.10 Rack fixture. Table 2-15 Required brackets Bracket AX6304S AX6308S Specifications...
Page 94 2. Preparation for Installation Purpose AX6304S AX6308S Specifications For securing a Switch When a For securing the support support bracket bracket is For securing a used Switch Note 1: For the number of screws used to secure a guide rail or a shelf, see the documentation supplied with your rack.
Page 95: Maintenance Area
2. Preparation for Installation 2.9 Maintenance area Ensure a proper amount of space for Switch maintenance as described below. (1) Maintenance area for a desktop installation Figure 2-12 Maintenance area for a desktop installation (2) Maintenance area for a rack installation Figure 2-13 Maintenance area for a rack installation...
Page 96: Cooling Requirements
2. Preparation for Installation 2.10 Cooling requirements 2.10.1 Airflow The following describes the airflow of the Switch. (1) AX6304S Figure 2-14 AX6304S (2) AX6308S Figure 2-15 AX6308S 2.10.2 Cooling requirements for a desktop installation Ensure at least 70 mm of space for airflow on all sides of the Switch. Do not obstruct the ventilation slots of the Switch.
Page 97: Cooling Requirements For A Rack Installation
2. Preparation for Installation NOTE When equipment with forced air cooling systems is installed near the Switch, interference due to the airflow from multiple devices can adversely affect the cooling of the Switch, which might result in a malfunction. The exhaust airflow from nearby equipment might be drawn into the Switch, and the Switch air intake temperature might exceed the environment requirements.
Page 98: Device Noise
2. Preparation for Installation 2.11 Device noise Switches contain cooling fans that generate noise. Consider this noise when planning the layout for the installation of devices. For details about the noise emitted by the Switch, see 2.2 Installation conditions. NOTE Some examples of a layout that takes noise into account are given below.
Page 99: Preparation Of Interface Cables And Terminals
Preparation of Interface Cables and Terminals This chapter describes the interface cables and the terminals used for the Switch. 3.1 List of interface cables 3.2 Details about interface cables 3.3 Terminals and connection cables...
Page 100: List Of Interface Cables
3. Preparation of Interface Cables and Terminals 3.1 List of interface cables This section describes the interface cables used for the Switch. The customer is responsible for obtaining these cables. Table 3-1 Interface cables Port Transceiver Interface Cable Connector 10/100/1000B 10BASE-T UTP cable (Category 3 or RJ-45...
Page 101 3. Preparation of Interface Cables and Terminals Port Transceiver Interface Cable Connector SFP-BX4D 1000BASE-BX4 10GBASE-R XFP-SR 10GBASE-SR Multimode fiber optic cable LC duplex port (core/cladding diameter = 50 connector μm/125 μm) Multimode fiber optic cable (core/cladding diameter = 62.5 μm/125 μm) XFP-LR 10GBASE-LR Single-mode fiber optic cable...
Page 102: Details About Interface Cables
3. Preparation of Interface Cables and Terminals 3.2 Details about interface cables NOTE To allow for Switch maintenance, fiber optic cables should be the necessary length (3 m), and the excess cabling should be bundled near the Switch. When fiber optic cables and other interface cables are used together, be sure to avoid applying excessive stress on the fiber optic cables.
Page 103: Fiber Optic Cables (1000Base-X)
3. Preparation of Interface Cables and Terminals RJ45 Physical specifications Pin number 10BASE-T 100BASE-TX 1000BASE-T Send (+) Send (+) Send/receive (+) Not used Not used Send/receive C (+) Not used Not used Send/receive C (-) Send (-) Send (-) Send/receive (-) Not used Not used Send/receive D (+)
Page 104 3. Preparation of Interface Cables and Terminals Item Physical specifications Optical reception power -19.0 to -3.0 dBm (mean) Optical transmission 10.0 dB loss (max) Transmission distance 2 m to 2 km 2 m to 1 km #1: The transmission distance can be increased by using the mode conditioning patch code.
Page 105: Fiber Optic Cables (10Gbase-R)
3. Preparation of Interface Cables and Terminals Table 3-8 Physical specifications for 1000BASE-LHB Item Physical specifications Cable type Single-mode Single-mode (DSF) 10 μm/125 μm 8 μm/125 μm Core/cladding diameter Center emission 1.480 to 1.580 μm wavelength Optical transmission power +2.0 to +7.0 dBm (mean) Optical reception power -34.0 to -9.0 dBm...
Page 106 3. Preparation of Interface Cables and Terminals Table 3-10 Physical specifications for 10GBASE-SR Item Physical specifications Cable type Multi-mode 50 μm/125 μm 62.5 μm/125 μm Core/cladding diameter Transmission band 400 MHz x km 500 MHz x km 2,000 MHz x 160 MHz x 200 MHz x Center emission...
Page 107 3. Preparation of Interface Cables and Terminals Item Physical specifications 1.530 to 1.565 μm Center emission wavelength Optical transmission power (mean) +0.5 to +4.0 dBm Optical reception power (mean) -24.0 to -7.0 dBm Optical transmission loss (max) 24.5 dB Transmission distance 2 m to 80 km #1: When optical transmission loss is 15 dB or less, use an optical attenuator to adjust the loss.
Page 108: Terminals And Connection Cables
3. Preparation of Interface Cables and Terminals 3.3 Terminals and connection cables 3.3.1 When connecting an operation terminal to the CONSOLE port (1) Operation terminal To connect an operation terminal to the CONSOLE port of the Switch, prepare a personal computer or a workstation that meets the specifications in the following table.
Page 109 3. Preparation of Interface Cables and Terminals Table 3-15 Operation terminal (when connecting to the MANAGEMENT port) Item Specifications Communication port 10BASE-T/100BASE-TX port Communication Tera Term Pro (Version 2.3) or another Telnet client software FTP client Communication Telnet, FTP procedure #1: Used for transferring software and dump files.
Page 110: Connecting A Modem To The Aux Port
3. Preparation of Interface Cables and Terminals RJ 45 pin Physical specifications number 10BASE-T 100BASE-TX Not used Not used #1: Connect to the pin if you are using a 4-pair, 8-core cable. #2: Twisted pair line. Use (A) and (a), (B) and (b), (C) and (c), (D) and (d) in pairs for a 4-pair, 8-core cable.
Page 111: Installing A Switch
Installing a Switch This chapter describes the procedure for installing a Switch. 4.1 Required tools 4.2 Read prior to operation 4.3 Installing a Switch on a desktop 4.4 Replacing the rack fixture 4.5 Mounting in a rack 4.6 Connecting and disconnecting the power cable 4.7 Attaching a wrist strap 4.8 Inserting and removing memory cards 4.9 Inserting and removing SFP transceivers...
Page 112: Required Tools
4. Installing a Switch 4.1 Required tools The following tools are necessary to install a Switch: No. 2 Phillips screwdriver Required when using M5 screws to replace a rack fixture or mount a Switch on a rack. This screwdriver is also required when connecting or disconnecting a DC power cable.
Page 113: Read Prior To Operation
4. Installing a Switch 4.2 Read prior to operation When installing the Switch on a table, position the Switch horizontally on a worktable strong enough to bear the weight of the Switch. Placing the Switch in an unstable location, such as on an unsteady or tilting surface, might cause the Switch to fall, resulting in injury.
Page 114: Installing A Switch On A Desktop
4. Installing a Switch 4.3 Installing a Switch on a desktop A Switch can be placed on a stable, flat surface. Rubber pads are attached to the bottom of the Switch when it is shipped from the factory. When installing a Switch on a desktop, do so without removing the rubber pads.
Page 115: Replacing The Rack Fixture
4. Installing a Switch 4.4 Replacing the rack fixture A rack fixture attached to a Switch is used to secure the rack pillars and the front of the Switch so that they are flat when the Switch is installed in a rack. If you purchased an optional fixture, which secures the Switch so that it is recessed 50 mm, use the following procedure to replace the rack fixture.
Page 116: Ax6308S
4. Installing a Switch Figure 4-3 Attaching the rack fixture (1) Left: L (2) Right: R (3) Screws NOTE Use the screws supplied with the optional rack fixture to secure it to the Switch. 4.4.2 AX6308S Step 1 Remove the rack fixture that was attached to the Switch when it was shipped from the factory.
Page 117 4. Installing a Switch Figure 4-4 Removing the rack fixture (1) Left: L (2) Right: R (3) Screws NOTE Make sure you keep the rack fixture and screws you remove. Step 2 Attach the optional rack fixture.
Page 118 4. Installing a Switch Figure 4-5 Attaching the rack fixture (1) Left: L (2) Right: R (3) Screws NOTE Use the screws supplied with the optional rack fixture to secure it to the Switch.
Page 119: Mounting In A Rack
4. Installing a Switch 4.5 Mounting in a rack The Switch can be mounted in to a 19-inch cabinet rack that conforms to the EIA standard. The procedure for mounting in a rack is described below. It is not possible for the provided rack fixture alone to support the weight of a Switch.
Page 120 4. Installing a Switch Figure 4-7 Installation location of the guide rail (1) Rubber pad (2) Guide rail (3) Rack pillar NOTE Dotted lines (- - -) in the Figure indicate the boundary between units (U). When attaching a guide rail, align the top of the guide rail with the boundary (U).
Page 121: Ax6304S (When Support Brackets Are Used)
Also, the fan unit or power supply unit might become deformed, resulting in fire or electric shock. NOTE To install a Switch in an elevated location, ALAXALA Networks Corporation recommend that you use a hand lifter or equivalent device.
Page 122 4. Installing a Switch Step 1 Install brackets L and R in the rack. For the installation location of the brackets, see Figure 4-11 Installation location of the support brackets. Figure 4-10 Installing support brackets (1) Bracket L (2) Bracket R (3) Screws (M5 or M6 x 4) supplied with the rack NOTE To attach the brackets, use the M5 or M6 screws supplied with the...
Page 123 4. Installing a Switch Figure 4-11 Installation location of the support brackets (1) Support bracket (2) Rack pillar NOTE Dotted lines (- - -) in the Figure indicate the boundary between units (U). Align the top of a support bracket with the boundary. Step 2 Attach crossbar A to brackets L and R.
Page 124 Also, the fan unit or power supply unit might become deformed, resulting in fire or electric shock. NOTE To install a Switch in an elevated location, ALAXALA Networks Corporation recommend that you use a hand lifter or equivalent device.
Page 125 4. Installing a Switch Step 4 Secure the Switch to the rack. Use the screws to secure the Switch to the rack pillar. Figure 4-14 Securing the Switch (1) Screws (M5 or M6 x 4) supplied with the rack Support the front and the back of the Switch until the screws have been tightened.
Page 126: Ax6308S
4. Installing a Switch Figure 4-15 Attaching crossbar B (1) Mounting hole 1 (2) Mounting hole 2 (3) Cross bar B (4) Thumb screw NOTE Securely tighten the thumb screws with your hand. 4.5.3 AX6308S Step 1 Attach a guide rail or a shelf to the rack. For the installation location of the guide rail, see Figure 4-17 Installation location of the guide rail.
Page 127 4. Installing a Switch Figure 4-16 Installing a guide rail (1) Guide rail Figure 4-17 Installation location of the guide rail (1) Rubber pad (2) Guide rail (3) Rack pillar NOTE Dotted lines (- - -) in the Figure indicate the boundary between units (U).
Page 128 Also, the fan unit or power supply unit might become deformed, resulting in fire or electric shock. To install a Switch in an elevated location, ALAXALA Networks NOTE Corporation recommend that you use a hand lifter or equivalent device.
Page 129 4. Installing a Switch Figure 4-19 Mounting a Switch on the rack (1) Screws (M5 or M6 x 8) NOTE To secure a Switch to the rack, use the M5 or M6 screws supplied with the rack.
Page 130: Connecting And Disconnecting The Power Cable
4. Installing a Switch 4.6 Connecting and disconnecting the power cable 4.6.1 Replacing the bracket preventing disconnection of the power cable (when a 200 V AC power cable is used) The bracket attached when a Switch is shipped from the factory supports only the supplied power cable.
Page 131: Connecting And Disconnecting The Ac Power Cable
4. Installing a Switch Figure 4-21 Attaching the bracket (1) Bracket preventing disconnection of the power cable (2) Support A (3) Support B 4.6.2 Connecting and disconnecting the AC power cable (1) Connecting the AC power cable The figure below shows an example of connecting the 100 V AC NOTE power cable supplied with a Switch.
Page 132 When using a Switch in a 200 V AC environment, use only the separately sold ALAXALA power cable, or a power cable that meets ALAXALA specifications. Using another cable could result in fire or electric shock.
Page 133: Connecting And Disconnecting The Dc Power Cable
ON could result in fire or electric shock. For the specifications defined by ALAXALA for power cables, see NOTE 2.4.3 Power supply facility for −48 V DC.
Page 134 4. Installing a Switch Step 2 Remove the terminal board cover from the terminal board. Figure 4-26 Removing the terminal cover (1) Terminal cover Step 3 Remove the 0 V terminal, −48 V terminal, and ground terminal screws. Figure 4-27 Removing the screws (1) 0V terminal (2) −48 V terminal (3) Ground terminal...
Page 135 4. Installing a Switch Figure 4-28 Releasing the cable clamp (1) Cable clamp (2) Screws (M5) Step 5 Pass the DC power cable through the cable clamp, and then tighten the screws of the ground terminals. Figure 4-29 Securing the ground terminals (1) DC power cable (2) Cable clamp (3) Ground terminal...
Page 136 4. Installing a Switch Step 6 Tighten the 0 V terminal and −48 V terminal screws in that order. Figure 4-30 Securing the 0 V terminal and the -48 V terminal (1) 0V terminal (2) −48 V terminal (3) Screws (M6) Step 7 Secure the DC power cable with the cable clamp.
Page 137 4. Installing a Switch Figure 4-32 Attaching the terminal cover (1) Terminal cover Step 9 Attach the terminal board cover. Figure 4-33 Attaching the terminal board cover (1) Terminal board cover (2) Screw (M3)
Page 138 4. Installing a Switch After connecting the DC power cable, attach the terminal board cover. Using the power supply unit without the cover could result in electric shock. (2) Disconnecting the DC power cable Reverse the steps described in (1) Connecting the DC power cable to remove the power cable.
Page 139: Attaching A Wrist Strap
4. Installing a Switch 4.7 Attaching a wrist strap A Switch has a terminal for an antistatic wrist strap. The terminal supports 4 mm banana plugs. Use a 4 mm banana plug for the wrist strap terminal. Figure 4-34 Location of the wrist strap terminal (1) Wrist strap terminal...
Page 140: Inserting And Removing Memory Cards
4. Installing a Switch 4.8 Inserting and removing memory cards To use a memory card, insert it in the management and switching unit. CAUTION Remove the memory card before moving the Switch. If a card is subjected to excessive force when the Switch is moved, the connector of the memory card slot might be damaged.
Page 141 4. Installing a Switch Figure 4-36 Checking the ACC LED CAUTION If the ACC LED is lit, the memory card is being accessed. While a memory card is being accessed, do not remove the memory card or turn off the power. Doing so might damage the memory card. In addition, some commands require a certain amount of time after being entered to finish accessing the card.
Page 142 4. Installing a Switch Figure 4-38 Removing a memory card CAUTION When removing a memory card, do not forcibly pull out the card if it is locked. Doing so might damage the connector of the memory card slot.
Page 143: Inserting And Removing Sfp Transceivers
4. Installing a Switch 4.9 Inserting and removing SFP transceivers SFP transceivers with a network interface unit attached can be inserted and removed while the Switch is on. (1) Inserting an SFP transceiver Keep the lever upright as shown in the figure, and insert the SFP transceiver until you hear a click.
Page 144 4. Installing a Switch (1) Lever (2) SFP transceiver (3) Ethernet port (2) Removing an SFP transceiver Press the lever down in the direction of the arrow. While holding down the lever, pull out the SFP transceiver. Figure 4-41 Removing an SFP transceiver (1) Lever (2) SFP transceiver...
Page 145: Inserting And Removing Xfp Transceivers
4. Installing a Switch 4.10 Inserting and removing XFP transceivers XFP transceivers with a network interface unit attached can be inserted and removed while the Switch is on. NOTE The following procedures describe how to insert and remove a type-A module.
Page 146: Connecting Operation Terminals
4. Installing a Switch 4.11 Connecting operation terminals Connect an operation terminal to the CONSOLE port of the Switch. To do so, use an RS-232C crossover cable with 9-pin (female) D-sub connectors on both ends, and use #4-40 screws. Figure 4-44 Connecting the operation terminal (1) RS-232C cable (2) Operation terminal Step 1...
Page 147 4. Installing a Switch NOTE After the cable is connected to the port, tighten the screws. Also make sure the cable is firmly connected. Step 2 In the same way, connect the RS-232C cable to the operation terminal.
Page 148: Connecting Interface Cables
4. Installing a Switch 4.12 Connecting interface cables (1) UTP cable Push the connector until you hear a click. Figure 4-46 Connecting a UTP cable (1) UTP cable (2) Tab (3) Ethernet port NOTE To detach the cable, hold the tab down and pull out the connector. (2) Fiber optic cable (LC duplex connector) Push the connector until you hear a click.
Page 149 4. Installing a Switch NOTE For details about cleaning optical connectors, see A Cleaning Optical Connectors. (3) Fiber optic cable (LC simplex connector) Push the connector until you hear a click. Figure 4-48 Fiber optic cable (LC simplex connector) (1) Fiber optic cable (LC simplex connector) (2) Tab (3) Transceiver NOTE...
Page 150: Turning The Switch On And Off
4. Installing a Switch 4.13 Turning the Switch on and off 4.13.1 AX6304S (AC power supply unit installed) (1) Turning the Switch on Step 1 Make sure the power supply unit is installed correctly. Figure 4-49 Checking the installation location of the power supply unit (1) Slot number (2) Power supply unit NOTE...
Page 151 4. Installing a Switch Figure 4-50 Turning on the power (1) Power switch NOTE Set all power switches to ON within five seconds of turning the first switch on. If you take longer than five seconds, the management and switching unit detects a power failure, and the failure information is displayed on the LCD.
Page 152 4. Installing a Switch executed) and the memory card is not being accessed. Figure 4-51 Checking the LED (1) Management and switching unit (2) STATUS LED (3) ACC LED CAUTION When the command is executed, the Switch restarts ppupdate automatically. Do not turn off the Switch until it is restarted (until the STATUS LED on the management and switching unit changes from blinking green to constant green).
Page 153: Ax6304S (Dc Power Supply Unit Installed)
4. Installing a Switch Figure 4-52 Turning off the power (1) Power switch A Switch has multiple input power supplies. Before turning off the power, set all power switches of the Switch to OFF. 4.13.2 AX6304S (DC power supply unit installed) (1) Turning the Switch on Step 1 Make sure the power supply unit is installed correctly.
Page 154 4. Installing a Switch Figure 4-53 Checking the installation location of the power supply unit (1) Power supply unit (2) Slot number NOTE If you do not want a redundant power supply, install the power supply unit in PS1. For a redundant power supply, install power supply units in both the PS1 and PS2 slots.
Page 155 4. Installing a Switch Figure 4-54 Turning on the power Circuit breaker NOTE Set all power switches to ON within five seconds of turning the first switch on. If you take longer than five seconds, the management and switching unit detects a power failure, and the failure information is displayed on the LCD.
Page 156 4. Installing a Switch (2) Turning off the power Step 1 Make sure the software is not being updated (the command is not being ppupdate executed) and the memory card is not being accessed. Figure 4-55 Checking the LED (1) Management and switching unit (2) STATUS LED (3) ACC LED CAUTION...
Page 157: Ax6308S (Ac Power Supply Unit Installed)
4. Installing a Switch Figure 4-56 Turning off the power (1) Circuit breaker A Switch has multiple input power supplies. Before turning off the power, set all circuit breakers of the Switch to OFF. 4.13.3 AX6308S (AC power supply unit installed) (1) Turning the Switch on Step 1 Make sure the power supply unit is installed correctly.
Page 158 4. Installing a Switch Figure 4-57 Checking the installation location of the power supply unit (1) Slot number (2) Power supply unit NOTE If you do not want a redundant power supply, install the power supply units in PS1 and PS2. For a redundant power supply, install power supply units in the PS1 to PS4 slots.
Page 159 4. Installing a Switch Figure 4-58 Turning on the power (1) Power switch NOTE Set all power switches to ON within five seconds of turning the first switch on. If you take longer than five seconds, the management and switching unit detects a power failure, and the failure information is displayed on the LCD.
Page 160 4. Installing a Switch (2) Turning off the power Step 1 Make sure the software is not being updated (the command is not being ppupdate executed) and the memory card is not being accessed. Figure 4-59 Checking the LED (1) Management and switching unit (2) STATUS LED (3) ACC LED CAUTION...
Page 161: Ax6308S (Dc Power Supply Unit Installed)
4. Installing a Switch Figure 4-60 Turning off the power (1) Power switch A Switch has multiple input power supplies. Before turning off the power, set all power switches of the Switch to OFF. 4.13.4 AX6308S (DC power supply unit installed) (1) Turning the Switch on Step 1 Make sure the power supply unit is installed correctly.
Page 162 4. Installing a Switch Figure 4-61 Checking the installation location of the power supply unit (1) Power supply unit (2) Slot number NOTE If you do not want a redundant power supply, install the power supply unit in PS1. For a redundant power supply, install power supply units in both the PS1 and PS2 slots.
Page 163 4. Installing a Switch Figure 4-62 Turning on the power Circuit breaker NOTE Set all power switches to ON within five seconds of turning the first switch on. If you take longer than five seconds, the management and switching unit detects a power failure, and the failure information is displayed on the LCD.
Page 164 4. Installing a Switch (2) Turning off the power Step 1 Make sure the software is not being updated (the command is not being ppupdate executed) and the memory card is not being accessed. Figure 4-63 Checking the LED (1) Management and switching unit (2) STATUS LED (3) ACC LED CAUTION...
Page 165 4. Installing a Switch Figure 4-64 Turning off the power (1) Circuit breaker A Switch has multiple input power supplies. Before turning off the power, set all circuit breakers of the Switch to OFF.
Page 166: Other Operations
Before actual system operation, conduct a test to check the configuration settings. (3) Troubleshooting See the following manual for corrective actions to problems. (The number in the parentheses is the manual number. Troubleshooting Guide (AX36S-T001) NOTE The Troubleshooting Guide is common to the AX2400S, AX3600S, AX6300S, AX6600S, and AX6700S series.
Page 167: Adding And Replacing Optional Modules
Adding and Replacing Optional Modules This chapter describes how to add and replace a fan unit, power supply unit, management and switching unit, and network interface unit. 5.1 Required tools 5.2 Read prior to operation 5.3 Replacing a fan unit 5.4 Adding or replacing a power supply unit 5.5 Adding or replacing a management and switching unit 5.6 Adding or replacing a network interface unit...
Page 168: Required Tools
5. Adding and Replacing Optional Modules 5.1 Required tools The following tools are necessary to add, replace, or remove devices: No. 1 Phillips screwdriver Used to install or remove an optional module. No. 2 Phillips screwdriver Used to connect or disconnect a DC power cable, and to install or remove a single guide rail.
Page 169: Read Prior To Operation
5. Adding and Replacing Optional Modules 5.2 Read prior to operation Adding or replacing optional modules must be performed by a trained technician or maintenance personnel. Adding or replacing a power supply unit requires connecting or disconnecting the power cable. If an untrained person performs the operation and mishandles the power cable, fire or electric shock could result.
Page 170: Replacing A Fan Unit
5. Adding and Replacing Optional Modules 5.3 Replacing a fan unit A fan unit can be replaced while the Switch is on. Replacing a fan unit must be performed by a trained technician or maintenance personnel. If another person performs the above and mishandles the fan unit, injury or damage could result.
Page 171 5. Adding and Replacing Optional Modules Figure 5-2 Removing a fan unit (2) (1) Handle (2) Fan Immediately after you have moved the fan unit, the fan might be still rotating. While the fan blades are rotating, do no place your hands near them.
Page 172 5. Adding and Replacing Optional Modules (1) Handle (2) Installing a fan unit Step 1 Insert a fan unit in a fan unit slot. Figure 5-4 Installing a fan unit (1) (1) Fan unit (2) Fan unit slot Step 2 Push the fan unit in as far as it will go, and then tighten the fan unit screw.
Page 173 5. Adding and Replacing Optional Modules Figure 5-5 Installing a fan unit (2) (1) Screws NOTE Use a screwdriver to tighten the screws. Make sure the screws are firmly tightened.
Page 174: Adding Or Replacing A Power Supply Unit
5. Adding and Replacing Optional Modules 5.4 Adding or replacing a power supply unit A power supply unit can be added while the Switch is on. If the power supply is redundant, a power supply unit can be replaced while the Switch is on.
Page 175 5. Adding and Replacing Optional Modules Figure 5-6 Turning off the power (1) Power switch (2) Power supply unit Step 2 Disconnect the power cable from the power supply unit you are replacing. (For details about how to disconnect the power cable, see 4.6 Connecting and disconnecting the power cable.) Figure 5-7 Disconnecting the power cable (1) Power cable...
Page 176 5. Adding and Replacing Optional Modules Step 3 Loosen the screws of the power supply unit. Figure 5-8 Removing a power supply unit (1) (1) Screws Step 4 Remove the power supply unit. (Pull the unit a little way toward you while holding the handles and supporting the bottom of the unit.) Figure 5-9 Removing a power supply unit (2) (1) Handles...
Page 177 5. Adding and Replacing Optional Modules CAUTION When removing a power supply unit, install a blank panel. If you continue using the Switch without attaching a blank panel, the airflow in the Switch cannot be maintained. As a result, the temperature inside the Switch will rise, possibly resulting in a failure.
Page 178: Adding Or Replacing A Dc Power Supply Unit
5. Adding and Replacing Optional Modules Figure 5-11 Installing a power supply unit (2) (1) Screws Use a screwdriver to tighten the screws. Make sure the screws are NOTE firmly tightened. Step 3 Connect a power cable to the power supply unit. (For details about how to connect a power cable, see 4.6 Connecting and disconnecting the power cable.) 5.4.2 Adding or replacing a DC power supply unit (1) Removing a DC power supply unit...
Page 179 5. Adding and Replacing Optional Modules Figure 5-12 Turning off the power (1) Circuit breaker (2) Power supply unit Step 2 Set the circuit breaker of the power supply facility to OFF to turn off the power. The circuit breaker of the power supply facility must be set to OFF. Adding or replacing a DC power supply unit with the circuit breaker set to ON could result in fire or electric shock.
Page 180 5. Adding and Replacing Optional Modules Figure 5-13 Disconnecting the power cable (1) Power cable Step 4 Loosen the screws of the power supply unit. Figure 5-14 Removing a power supply unit (1) (1) Screws Step 5 Remove the power supply unit. (Pull the unit a little way toward you while holding the handles and supporting the bottom of the unit.)
Page 181 5. Adding and Replacing Optional Modules Figure 5-15 Removing a power supply unit (2) (1) Handles The weight of a DC power supply unit is 5.6 kg and the front-to-back measurement is 163 mm. When removing a DC power supply unit from a Switch, support the DC power supply unit itself.
Page 182 5. Adding and Replacing Optional Modules Figure 5-16 Installing a power supply unit (1) (1) Power supply unit (2) Power supply unit slot Step 2 Push the power supply unit in as far as it will go, and then tighten the power supply unit screws.
Page 183 5. Adding and Replacing Optional Modules Step 3 Connect a power cable to the power supply unit. (For details about how to connect a power cable, see 4.6 Connecting and disconnecting the power cable.) Make sure the circuit breaker of the power supply facility is set to OFF before connecting or disconnecting the DC power cable.
Page 184: Adding Or Replacing A Management And Switching Unit
5. Adding and Replacing Optional Modules 5.5 Adding or replacing a management and switching unit Adding or replacing a management and switching unit must be performed by a trained technician or maintenance personnel. If another person performs the above and mishandles the management and switching unit, injury or damage could result.
Page 185 5. Adding and Replacing Optional Modules Figure 5-18 Overview of removing a management and switching unit Step 1 Make sure the management and switching unit you are removing has been turned off (when the STATUS LED is on, the unit is turned on; when it is off, the unit is off).
Page 186 5. Adding and Replacing Optional Modules Figure 5-19 Checking the STATUS LED (1) STATUS LED (2) Management and switching unit Step 2 Turn off the management and switching unit if the power is being supplied (execute the Inactivate operation). NOTE For details about the Inactivate operation, see 11 Switch Management in the Software Manual Configuration Guide Vol.
Page 187 5. Adding and Replacing Optional Modules Step 4 Open the right and left levers of the management and switching unit at the same time (the unit comes out toward you about 15 mm). Figure 5-21 Removing a management and switching unit (2) (1) Lever NOTE Use the levers so that the connectors on the optional module and the...
Page 188 5. Adding and Replacing Optional Modules (2) Side Components in a management and switching unit might be very hot. Do not touch any components with your hands. Doing so could result in burns. CAUTION When removing a management and switching unit, install a blank panel.
Page 189 5. Adding and Replacing Optional Modules Figure 5-23 Installation overview Step 1 Insert a management and switching unit halfway into the slot for it. (Do this while holding the sides of the unit.)
Page 190 5. Adding and Replacing Optional Modules Figure 5-24 Installing a management and switching unit (1) (1) Management and switching unit (2) Management and switching unit slot Step 2 While holding the levers, push the unit carefully until the levers touch the Switch. The levers must be opened parallel to the direction of insertion.
Page 191 5. Adding and Replacing Optional Modules Step 3 Close the levers of the management and switching unit. (The unit is inserted completely.) Figure 5-26 Installing a management and switching unit (3) (1) Lever CAUTION Use the levers so that the connectors on the optional module and the Switch will be engaged correctly.
Page 192 5. Adding and Replacing Optional Modules NOTE Use a screwdriver to tighten the screws. Make sure the screws are firmly tightened. Step 5 Turn on the management and switching unit. (Execute the Activate operation.) NOTE For details about the Activate operation, see 11 Switch Management in the Software Manual Configuration Guide Vol.
Page 193 5. Adding and Replacing Optional Modules operation). Activate Match the software version used in the standby system with the version used in the active system (use the command). ppupdate Synchronize the configuration, user account, password, and license key settings of the standby system with the settings of the active system (use the command).
Page 194: Adding Or Replacing A Network Interface Unit
5. Adding and Replacing Optional Modules 5.6 Adding or replacing a network interface unit Adding or replacing a network interface unit must be performed by a trained technician or maintenance personnel. If another person performs the above and mishandles the network interface unit, injury or damage could result.
Page 195 5. Adding and Replacing Optional Modules the STATUS LED is on, the unit is on; when it is off, the unit is off). Figure 5-29 Checking the STATUS LED (1) STATUS LED (2) Network interface unit Step 2 Turn off the network interface unit if power is being supplied (execute the Inactivate operation).
Page 196 5. Adding and Replacing Optional Modules Figure 5-30 Removing a network interface unit (1) (1) Screws CAUTION Loosen the screws completely. If the screws are not loose enough, the network interface unit might be damaged when the levers are opened. Step 4 Open the right and left levers of the network interface unit at the same time (the unit comes out toward you about 15 mm).
Page 197 5. Adding and Replacing Optional Modules Step 5 Remove the network interface unit. (Pull the unit a little way toward you while holding the levers and supporting the sides.) Figure 5-32 Removing a network interface unit (3) (1) Lever (2) Side The components in a network interface unit might be very hot.
Page 198 5. Adding and Replacing Optional Modules NOTE For details about steps 1 to 5 in the figure, see the description of the steps that follow Figure 5-33 Installation overview. Figure 5-33 Installation overview Step 1 Insert a network interface unit halfway into the slot for it. (Do this while holding the sides of the unit.)
Page 199 5. Adding and Replacing Optional Modules Figure 5-34 Installing a network interface unit (1) (1) Network interface unit (2) Network interface unit slot Step 2 While holding the levers, push the unit carefully until the levers touch the Switch. The levers must be opened parallel to the direction of insertion. Figure 5-35 Installing a network interface unit (2) (1) Contact point (2) Lever...
Page 200 5. Adding and Replacing Optional Modules CAUTION While holding the levers, push the network interface unit carefully until the levers touch the Switch. Failure to do this could result in a Switch malfunction or fault. CAUTION Open the levers as shown in the figure when you install a network interface unit.
Page 201: Double-Size Network Interface Unit
5. Adding and Replacing Optional Modules Figure 5-37 Installing a network interface unit (4) (1) Screws NOTE Use a screwdriver to tighten the screws. Make sure the screws are firmly tightened. NOTE If you install a network interface unit (NIF) while the Switch is on, the NIF is turned on automatically when the NIF is installed.
Page 202 5. Adding and Replacing Optional Modules Figure 5-38 Overview of removing a network interface unit Step 1 Make sure the network interface unit you are removing has been turned off (when the STATUS LED is on, the unit is on; when it is off, the unit is off). Figure 5-39 Checking the STATUS LED (1) STATUS LED (2) Network interface unit...
Page 203 5. Adding and Replacing Optional Modules Step 2 Turn off the network interface unit if power is being supplied (execute the Inactivate operation). NOTE For details about the Inactivate operation, see 11 Switch Management in the Software Manual Configuration Guide Vol. 1. Step 3 Loosen the screws of the network interface unit.
Page 204 5. Adding and Replacing Optional Modules Figure 5-41 Removing a network interface unit (2) (1) Lever NOTE Use the levers so that the connectors on the optional module and the Switch can be disengaged correctly. When moving a lever, move the right and left levers slowly and at the same time without exerting excessive force.
Page 205 5. Adding and Replacing Optional Modules (1) Lever (2) Side The components in a network interface unit might be very hot. Do not touch any components with your hands. Doing so could result in burns. CAUTION When removing a network interface unit, install a blank panel. If you continue using the Switch without attaching a blank panel, the airflow in the Switch cannot be maintained.
Page 206 5. Adding and Replacing Optional Modules Figure 5-43 Installation overview Step 1 Make sure a tray is installed in the network interface unit slot (the tray is secured with screws).
Page 207 5. Adding and Replacing Optional Modules Figure 5-44 Checking a tray (1) Screws (2) Tray NOTE For details about how to install a tray, see 5.6.3 Installing and removing a single-guide rail. Step 2 Insert a network interface unit halfway into the slot for it. (Do this while holding the sides of the unit.) Figure 5-45 Installing a network interface unit (1) (1) Network interface unit...
Page 208 5. Adding and Replacing Optional Modules (2) Network interface unit slot Step 3 While holding the levers, push the unit carefully until the levers touch the Switch. The levers must be opened parallel to the direction of insertion. Figure 5-46 Installing a network interface unit (2) (1) Contact point (2) Lever CAUTION...
Page 209 5. Adding and Replacing Optional Modules Figure 5-47 Installing a network interface unit (3) (1) Lever CAUTION Use the levers so that the connectors on the optional module and the Switch will be engaged correctly. When moving the levers, move them slowly (one second or longer) without exerting any force.
Page 210: Installing And Removing A Single-Guide Rail
5. Adding and Replacing Optional Modules NOTE If you install a network interface unit (NIF) while the Switch is on, the NIF is turned on automatically when the NIF is installed. Note, however, that if no power enable is set in the configuration, the NIF is not turned on automatically.
Page 211 5. Adding and Replacing Optional Modules Step 2 Remove the tray. (Hold inside the tray and pull it a little way toward you, and then remove it while supporting the bottom of the tray.) Figure 5-50 Removing a tray (2) Step 3 Remove the three screws securing the single-guide rail.
Page 212 5. Adding and Replacing Optional Modules Figure 5-52 Removing a single-guide rail (2) NOTE Make sure you keep the single-guide rail and the screws you remove. Step 5 Install the tray in the network interface unit slot. Figure 5-53 Installing a tray (1) (1) Tray (2) Network interface unit slot Step 6...
Page 213 5. Adding and Replacing Optional Modules Figure 5-54 Installing a tray (2) (1) Screws (2) Tray (2) Installing a single-guide rail To install the single-guide rail, reverse the steps described in (1) Removing a single-guide rail.
Page 214 5. Adding and Replacing Optional Modules...
Page 215: Appendix
Appendix Appendix A. Cleaning Optical Connectors...
Page 216: Cleaning Optical Connectors
A. Cleaning Optical Connectors A. Cleaning Optical Connectors A.1 Cleaning the optical connectors of transceivers To clean the optical connector for the transceiver, follow the procedure below. The fiber optic cable uses a laser beam that is colorless and transparent, and invisible to the eye. Never look directly into the optical transceiver.
Page 217 A. Cleaning Optical Connectors Step 2 Check the tip of the optical connector cleaner (stick-type) for irregularities, such as lint, dirt, or other foreign matter. Figure A-2 Checking the optical connector cleaner (1) Optical connector cleaner (stick-type) (2) Part to check CAUTION Before cleaning, make sure that the tip of the optical connector cleaner is clean and free of defects, such as lint, dirt, or other foreign...
Page 218: Cleaning Fiber Optic Cables
A. Cleaning Optical Connectors NOTE For instructions on how to use the optical connector cleaner, see the documentation for the optical connector cleaner. A.2 Cleaning fiber optic cables To clean fiber optic cables, follow the procedure below. The fiber optic cable uses a laser beam. (Laser beams are colorless and transparent, and invisible to the eye.) Never look directly into the optical transceiver.
Page 219 A. Cleaning Optical Connectors Step 2 Use an optical connector cleaner (reel-type) to clean any dirt from the ferrule tip. Figure A-5 Cleaning the ferrule tip CAUTION Always use a dedicated optical connector cleaner. If you use another type of cleaner, the ferrule tip might be damaged. CAUTION Do not apply excessive pressure when cleaning.

This manual is also suitable for:

Ax63s-h001-50x Ax6304s Ax6308s

Alaxala AX6300S Series Instruction Manual

1 Components Overview

2 Preparation for Installation

3 Preparation of Interface Cables and Terminals

4 Installing a Switch

5 Adding and Replacing Optional Modules

Appendix

Cleaning Optical Connectors

Quick Links

Related Manuals for Alaxala AX6300S Series

Summary of Contents for Alaxala AX6300S Series

This manual is also suitable for:

Table of Contents
