Figure 1-7 Pentium D Processor, Pentium Processor Extreme Edition And Intel Core Duo Processor - Intel ARCHITECTURE IA-32 Reference Manual

Figure 1-7 Pentium D Processor, Pentium Processor Extreme Edition
and Intel Core Duo Processor
IA-32 Intel® Architecture Processor Family Overview
Pentium D Processor
Architectual State
Execution Engine
Local APIC
Caches
Bus Interface
System Bus
Pentium Processor Extreme Edition
Architectual Architectual
State State
Execution Engine
Local APIC Local APIC
Caches
Bus Interface
System Bus
Intel Core Duo Processor
Architectual State
Execution Engine
Local APIC
Second Level Cache
Bus Interface
System Bus
Architectual State
Execution Engine
Local APIC
Caches
Bus Interface
Architectual Architectual
State State
Execution Engine
Local APIC Local APIC
Caches
Bus Interface
Architectual State
Execution Engine
Local APIC
