Example 4-2 Unsigned Unpack Instructions
; Input:
;
;
;
;
; Output:
;
;
;
;
;
;
movq
punpcklwd
punpckhwd

Signed Unpack

Signed numbers should be sign-extended when unpacking the values.
This is similar to the zero-extend shown above except that the
instruction (packed shift right arithmetic) is used to effectively sign
extend the values. Example 4-3 assumes the source is a packed-word
(16-bit) data type.
MM0 source value
MM7 0 a local variable can be used
instead of the register MM7 if
desired.
MM0 two zero-extended 32-bit
doublewords from two low-end
words
MM1 two zero-extended 32-bit
doublewords from two high-end
words
MM1, MM0 ; copy source
MM0, MM7 ; unpack the 2 low-end words
; into two 32-bit doubleword
MM1, MM7 ; unpack the 2 high-end words
; into two 32-bit doublewords
Optimizing for SIMD Integer Applications
4
psrad
4-7
