HP 316095-B21 - StorageWorks Edge Switch 2/24 Service Manual

Edge switch 2/24 service manual.
Hide thumbs
hp StorageWorks
edge switch 2/24 service manual
Part Number: AA-RTDXA-TE
First Edition (January 2003)
This manual describes the HP StorageWorks Edge Switch 2/24 and
attached HP StorageWorks High Availability Fabric Manager
(HAFM) application. For service representatives, it describes
diagnostic procedures, repair procedures, and the removal and
replacement procedures for field-replaceable units (FRUs).

Advertising

   Related Manuals for HP 316095-B21 - StorageWorks Edge Switch 2/24

   Summary of Contents for HP 316095-B21 - StorageWorks Edge Switch 2/24

  • Page 1

    hp StorageWorks edge switch 2/24 service manual Part Number: AA-RTDXA-TE First Edition (January 2003) This manual describes the HP StorageWorks Edge Switch 2/24 and attached HP StorageWorks High Availability Fabric Manager (HAFM) application. For service representatives, it describes diagnostic procedures, repair procedures, and the removal and replacement procedures for field-replaceable units (FRUs).

  • Page 2

    © Hewlett-Packard Company, 2003. All rights reserved. Hewlett-Packard Company makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

  • Page 3: Table Of Contents

    Contents Contents About This Manual Intended Audience ............xi Related Documentation .

  • Page 4: Table Of Contents

    MAP 0400: Loss of Console Communication ....... 2–44 MAP 0500: FRU Failure Analysis ........2–59 MAP 0600: Port Failure and Link Incident Analysis .

  • Page 5: Table Of Contents

    Block and Unblock Ports ..........3–25 Block a Port .

  • Page 6

    Event Codes System Events (000 through 199)......... B–3 Power Supply Events (200 through 299) .

  • Page 7

    3–6 Threshold Alert Log ..........3–11 3–7 Hardware View .

  • Page 8

    2–10 MAP 600: Event Codes ......... . 2–65 2–11 Port Operational and LED States.

  • Page 9: Intended Audience, Related Documentation

    About This Manual This manual describes the service procedures for the HP StorageWorks Edge Switch 2/24. Intended Audience This publication is intended for service personnel, and any individuals who monitor, configure, and repair the Edge Switch 2/24. Related Documentation For a list of corresponding documentation included with this product, see the Related Documents section of the HP StorageWorks Edge Switch Release Notes.

  • Page 10: Document Conventions

    About This Manual Document Conventions The conventions included in Table 1 apply. Table 1: Document Conventions Element Convention Cross-reference links Blue text: Figure 1 Key names, menu items, buttons, and Bold dialog box titles File names, application names, and text Italics emphasis User input, command names, system...

  • Page 11

    About This Manual Symbols on Equipment Any enclosed surface or area of the equipment marked with these symbols indicates the presence of electrical shock hazards. Enclosed area contains no operator serviceable parts. WARNING: To reduce the risk of injury from electrical shock hazards, do not open this enclosure.

  • Page 12: Rack Stability, Getting Help, Hp Technical Support

    About This Manual Rack Stability WARNING: To reduce the risk of personal injury or damage to the equipment, be sure that: • The leveling jacks are extended to the floor. • The full weight of the rack rests on the leveling jacks. •...

  • Page 13: Hp Authorized Reseller

    About This Manual HP Website The HP website has the latest information on this product, as well as the latest drivers. http://thenew.hp.com/country/us/eng/prodserv/storage.html. Access storage at: From this website, select the appropriate product or solution. HP Authorized Reseller For the name of your nearest HP Authorized Reseller: •...

  • Page 15: Switch Description

    General InformationI The HP StorageWorks Edge Switch 2/24 provides dynamic switched connections between Fibre Channel servers and devices in a storage area network (SAN) environment. SANs introduce the concept of server-to-device networking and multi-switch fabrics, eliminate requirements for dedicated connections, and enable the enterprise to become data centric.

  • Page 16

    General InformationI The switch, shown in Figure 1–1, provides dynamic switched connections for servers and devices, supports mainframe and open-systems interconnection (OSI) computing environments, and provides data transmission and flow control between device node ports (N_Ports) as dictated by the Fibre Channel Physical and Signaling Interface (FC-PH 4.3).

  • Page 17: Maintenance Approach

    General InformationI Maintenance Approach Whenever possible, the maintenance approach instructs service personnel to perform fault isolation and repair procedures without degrading or interrupting operation of the switch, attached devices, or associated applications. Switch fault isolation begins when one or more of the following occur: •...

  • Page 18: Tools And Test Equipment, Tools Supplied With The Switch

    General InformationI Tools and Test Equipment This section describes tools and test equipment that may be required to install, test, service, and verify operation of the switch and attached HAFM server. Tools Supplied with the Switch The following tools are supplied with the switch. Use of the tools may be required to perform one or more installation, test, service, or verification tasks.

  • Page 19: Tools Supplied By Service Personnel

    General InformationI • Null modem cable - An asynchronous RS-232 null modem cable is required to configure switch network addresses and acquire event log information through the maintenance port. The cable has nine conductors and DB-9 male and female connectors. A null modem cable is not a standard (straight-through) RS-232 cable. Refer to Figure 1–4.

  • Page 20: Additional Information

    General InformationI Additional Information The following Edge Switch 2/24 documents provide additional information: • For detailed information about Edge Switch 2/24 front and rear panel features, field replaceable units (FRUs), management options and operational features, installation, configuration and technical specifications, see the hp StorageWorks edge switch 2/24 installation guide.

  • Page 21: Maintenance Analysis Procedures, Factory Defaults

    Diagnostics This chapter describes diagnostic procedures used by service representatives to isolate HP StorageWorks Edge Switch 2/24 problems or failures to the field-replaceable unit (FRU) level. The chapter specifically describes how to perform maintenance analysis procedures (MAPs). Maintenance Analysis Procedures Maintenance Analysis Procedures (MAPs) provide fault isolation and related service procedures.

  • Page 22: Quick Start

    Diagnostics Quick Start Table 2–2 lists the MAPs in this chapter. Fault isolation normally begins at 0000: Start MAP on page 2–6. Table 2–2: MAP Summary Page MAP 0000: Start MAP page 2–6 MAP 0100: Power Distribution Analysis page 2–27 MAP 0200: POST Failure Analysis page 2–35 MAP 0300: Console Application Problem Determination...

  • Page 23

    Diagnostics Table 2–3: Event Codes versus Maintenance Action (Continued) Event Code Explanation Action 0700. E_Port is segmented. Go to 0700. Switch is isolated. Go to 0700. E_Port connected to unsupported switch. Go to Fabric initialization error. Refer to Collecting Maintenance Data on page 3–22.

  • Page 24

    Diagnostics Table 2–3: Event Codes versus Maintenance Action (Continued) Event Code Explanation Action Cooling fan propeller recovered. No action required. Cooling fan propeller recovered. No action required. Cooling fan propeller recovered. No action required. 0200. Power-up diagnostic failure. Go to CTP reset.

  • Page 25

    Diagnostics Table 2–3: Event Codes versus Maintenance Action (Continued) Event Code Explanation Action 0600. Bit error threshold exceeded. Go to 0600. Loss of signal or loss of synchronization. Go to 0600. Not operational primitive sequence Go to received. 0600. Primitive sequence timeout. Go to 0600.

  • Page 26: Map 0000: Start Map

    Diagnostics MAP 0000: Start MAP This MAP describes initial fault isolation for the Edge Switch 2/24. Fault isolation begins at the High Availability Fabric Manager (HAFM) server, failed switch, Internet-connected personal computer (PC) running the Embedded Web Server (EWS) interface, or attached host. Prior to fault isolation, acquire the following information from the customer: •...

  • Page 27

    Diagnostics Are you at the HAFM server (or customer-supplied server)? Go to step 22 Did the HAFM server (or customer-supplied server) lock up or crash and: • Display an application warning or error message, or • Not display an application warning or error message, or •...

  • Page 28

    Diagnostics Reboot the HAFM server (or customer-supplied server) PC. If the customer-supplied server does not use the Windows 2000 operating system, refer to the supporting documentation to reboot the server. Reboot the HAFM server PC and perform system diagnostics. a. Click the Windows Start button. The Windows Workstation menu displays. b.

  • Page 29

    Diagnostics Did the Products View display and does the HAFM application appear operational? An HAFM server (or customer-supplied server) hardware problem is indicated. Event codes are not recorded. Go to MAP 0800: Console PC Problem Determination on page 2–91. Exit MAP. Inspect the alert indicators of each managed switch (or switch) at the top of the Products View.

  • Page 30

    Diagnostics Does the switch appear powered on? A power distribution problem is indicated. Go to step 21 to obtain event codes. If no event codes are found, go to MAP 0100: Power Distribution Analysis on page 2–27. Exit MAP. At the switch, inspect the amber LED on the switch. Is the amber LED illuminated on the switch? Failure of the CTP is indicated.

  • Page 31

    Diagnostics Do blinking red and yellow diamonds overlay FRU graphics? Failure of all installed FRUs is indicated. Go to step 21 to obtain event codes. If no event codes are found, go to MAP 0700: Fabric, ISL, and Segmented Port Problem Determination on page 2-79.

  • Page 32

    Diagnostics A green circle appears as the background to the icon representing the switch reporting the problem. Although the switch is operational, a minor problem may exist. Double-click the icon representing the switch reporting the problem. The Hardware View displays. At the Hardware View: •...

  • Page 33

    Diagnostics Inspect the port state and LED status for all ports with an attention indicator. a. Double-click a port to open the Port Properties dialog box (Figure 2–2). Figure 2–2: Port Properties Dialog Box b. Inspect the Operational State field. Does the Operational State field display a Segmented E_Port message? Expansion port (E_Port) segmentation is indicated.

  • Page 34

    Diagnostics A link incident may have occurred, but the LIN alerts option is not enabled for the port and the attention indicator does not appear. At the Hardware View, click Logs and select Link Incident Log. The Link Incident Log displays (Figure 2–3).

  • Page 35

    Diagnostics Link failure - primitive sequence timeout. Link failure - invalid primitive sequence received for the current link state. Did one of the listed messages appear in the Link Incident Log? The switch appears operational. Exit MAP. A link incident problem is indicated. Go to step 21 to obtain event codes.

  • Page 36

    Diagnostics Is the power LED (green) at the switch front bezel illuminated? Go to step Is the switch connected to facility AC power and powered on? Go to step Connect the switch to facility AC power. Inspect the switch for indications of being powered on, such as: •...

  • Page 37

    Diagnostics Inspect the switch for indications of being powered on, such as: • At the front bezel, an illuminated power LED (green) or system error LED (amber). • Audio emanations and airflow from cooling fans. Does the switch appear powered on? A power distribution problem is indicated.

  • Page 38

    Diagnostics Is the system error LED (amber) at the switch front bezel illuminated? The switch appears operational. Verify operation at the HAFM server (or customer-supplied server). Go to step Check FRUs for failure symptoms. Are any amber LEDs associated with Fibre Channel ports illuminated? A Fibre Channel port failure is indicated.

  • Page 39

    Diagnostics Is the web browser PC powered on and communicating with the switch through the Internet connection? Go to step Boot the web browser PC. a. Power on the PC in accordance with the instructions delivered with the PC. The Windows desktop appears.

  • Page 40

    Diagnostics Ensure the switch reporting the problem is connected to facility AC power. Inspect the switch for indications of being powered on, such as: • At the front bezel, an illuminated power LED (green) or system error LED (amber). • Audio emanations and airflow from cooling fans.

  • Page 41

    Diagnostics At the View panel, inspect the Status field. Does the switch status indicate Operational? The switch appears operational. Exit MAP. Inspect Fibre Channel port operational states. a. At the View panel, click the Port Properties tab. The View panel (Port Properties tab) displays with port 0 highlighted.

  • Page 42

    Diagnostics b. Inspect the Beaconing and Operational State fields. Does the Beaconing field display an On message? Go to step Port beaconing is enabled. a. Consult the customer and next level of support to determine the reason port beaconing is enabled. b.

  • Page 43

    Diagnostics Repeat step 43 through step 46 for each remaining Fibre Channel port for which a problem is suspected (ports 0 through 23). Is an problem indicated for any of the ports? Go to step 50 to obtain event codes. If no event codes are found, go to 0700: Fabric, ISL, and Segmented Port Problem Determination on page 2-79.

  • Page 44

    Diagnostics Does the Status field display a Failed message for either power supply? A power supply failure is indicated. Go to step 50 to obtain event codes. If no event codes are found, go to MAP 0100: Power Distribution Analysis on page 2-27.

  • Page 45

    Diagnostics Figure 2–7: Monitor Panel (Log) c. Record the event code, date, time, and severity (Informational, Minor, Major, or Severe). d. Record all event codes that may relate to the reported problem. Were one or more event codes found? Go to Table 2–3 on page 2-2.

  • Page 46

    Diagnostics The link incident record provides the attached switch port number(s) and one or more of the following event codes and messages. Record all event codes that may relate to the reported problem. 581 - Link interface incident - implicit incident. 582 - Link interface incident - bit-error threshold exceeded.

  • Page 47: Map 0100: Power Distribution Analysis

    Diagnostics MAP 0100: Power Distribution Analysis This MAP describes fault isolation for the switch power distribution system, including defective AC power cords or redundant power supplies. Was an event code 200, 201, 202, or 208 observed at the Edge Switch 2/24 Event Log (HAFM server) or at the EWS Event Log? Go to step...

  • Page 48

    Diagnostics Was a corrective action performed? Go to step Verify redundant power supply operation. a. Inspect the power supply and ensure all amber LEDs are extinguished. b. At the Hardware View, observe the graphic representing the power supply and ensure a failure symbol (blinking red and yellow diamond) does not appear. Is a failure indicated? The switch appears operational.

  • Page 49

    Diagnostics A redundant power supply failed and must be removed and replaced (See RRP 2: Redundant Power Supply on page 4–5). • This procedure is concurrent and can be performed while switch power is on. • Perform the data collection procedure as part of FRU removal and replacement. Did power supply replacement solve the problem? The switch appears operational.

  • Page 50

    Diagnostics Is a failure indicated? The switch appears operational. Exit MAP. Contact the next level of support. Exit MAP. Is fault isolation being performed at the switch? Fault isolation is being performed at the HAFM server (or customer-supplied server) or EWS interface. Go to step Verify the switch is connected to facility power and is powered on.

  • Page 51

    Diagnostics Does inspection of a power supply indicate a failure (the amber LED is illuminated)? A redundant power supply failed. Go to step The switch appears operational. Exit MAP. The switch AC power distribution system failed. Possible causes include failure of: •...

  • Page 52

    Diagnostics Both power supplies failed and must be removed and replaced. (See RRP 2: Redundant Power Supply on page 4–5.) Perform the data collection procedure as part of FRU removal and replacement. Did dual power supply replacement solve the problem? The switch appears operational.

  • Page 53

    Diagnostics At the Hardware View, does a grey square appear at the alert panel, a No Link status appear at the Edge-24 Status table, and graphical FRUs appear uninstalled? A green circle appears at the alert panel and the switch appears operational. Exit MAP.

  • Page 54

    Diagnostics A Page cannot be found, Unable to locate the server, HTTP 404 - file not found, or other similar message appears. The message indicates the web browser PC cannot communicate with the switch because: • The switch-to-PC Internet link could not be established. •...

  • Page 55: Map 0200: Post Failure Analysis

    Diagnostics MAP 0200: POST Failure Analysis When the switch is powered on, it performs a series of power-on self-tests (POSTs). When POSTs complete, the switch performs an initial program load (IPL) that loads firmware and brings the unit online. This MAP describes fault isolation for problems that may occur during the POST/IPL process.

  • Page 56

    Diagnostics Table 2–5 lists event codes, brief explanations of the codes, and the associated steps that describe fault isolation procedures. Table 2–5: MAP 200: Event Codes Event Code Explanation Action Power-up diagnostic failure. Go to step Firmware fault. Go to step POST/IPL diagnostics detected a FRU failure as indicated by an event code 400 with supplementary event data.

  • Page 57

    Diagnostics A fan module failed POSTs (indicated by a 05 FRU code) and the power supply must be removed and replaced (See RRP 2: Redundant Power Supply on page 4–5). • This procedure is concurrent and can be performed while switch power is on. •...

  • Page 58: Map 0300: Console Application Problem Determination

    Diagnostics MAP 0300: Console Application Problem Determination This map describes isolation of HAFM server (or customer-supplied server) application problems, including problems associated with the Windows NT operating system, HAFM, and Edge Switch 2/24 Product Manager applications. Did the HAFM server (or customer-supplied server) lock up or crash without displaying a warning or error message? Go to step...

  • Page 59

    Diagnostics e. Simultaneously press Ctrl, Alt, and Delete to display the Logon Information dialog box. Type a user name and password (obtained in MAP 0000: Start MAP on page 2-6) and click OK. The HAFM application starts and the HAFM Login dialog box displays (Table 2–8).

  • Page 60

    Diagnostics Did the HAFM application display a dialog box with the message Connection to HAFM server lost - click OK to exit application or HAFM error n (where n is an error message number 1 through 8 inclusive)? An HAFM application error occurred. Click OK to close the window and close the HAFM application.

  • Page 61

    Diagnostics Did the Product Manager application display a window with the message Product Manager error 5001 or Product Manager error 5002? A Product Manager application error occurred. Click OK to close the window and close the HAFM and Product Manager applications. Go to step Did the Product Manager application display a window with the message Send firmware failed?

  • Page 62

    Diagnostics The data collection process failed. Retry the process using a new Zip disk (Collecting Maintenance Data on page 3–22). Did the data collection process complete? Exit MAP. Contact the next level of support. Exit MAP. Did the HAFM server (or customer-supplied server) lock up or crash and display a Dr. Watson for Windows dialog box (Figure 2–9)?

  • Page 63

    Diagnostics Attempt to clear the problem by power cycling the HAFM server (or customer-supplied server) PC. a. Power off the PC. b. Wait approximately 30 seconds and power on the PC. After POSTs complete, the Begin Logon dialog box displays. c.

  • Page 64: Map 0400: Loss Of Console Communication

    Diagnostics Did the Products View display and does the HAFM application appear operational? The problem is transient and the HAFM server (or customer-supplied server) appears operational. Exit MAP. Contact the next level of support. Exit MAP. MAP 0400: Loss of Console Communication This MAP describes fault isolation of the Ethernet communication link between a switch and the HAFM server (or customer-supplied server), or between a switch and a web browser PC running the EWS interface.

  • Page 65

    Diagnostics Table 2–7 lists event codes, brief explanations of the codes, and associated steps that describe fault isolation procedures. Table 2–7: MAP 400: Event Codes Event Code Explanation Action Excessive Ethernet transmit errors. Go to step Excessive Ethernet receive errors. Go to step Ethernet adapter reset.

  • Page 66

    Diagnostics Ensure the switch reporting the problem is connected to facility AC power. Inspect the switch for indications of being powered on, such as: • At the front bezel, an illuminated power LED (green) or system error LED (amber). • Audio emanations and airflow from cooling fans.

  • Page 67

    Diagnostics Table 2–8: MAP 400: Error Messages (Continued) Error Message Action Duplicate session. Go to step Unknown network address. Go to step Incorrect product type. Go to step Transmit or receive errors for a switch’s Ethernet adapter exceeded a threshold, the switch-to-server link was not connected, or the switch-to-server link timed out.

  • Page 68

    Diagnostics Verify the hubs are correctly daisy-chained (Figure 2–11.) 1 2 x Switch set to MDIX (in) M D IX M D I 1 2 x Switch set to MDI (out) M D IX M D I 1 2 x Switch set to MDIX (in) Figure 2–11: Ethernet Hubs, daisy-chained...

  • Page 69

    Diagnostics Verify operation of the Ethernet hub or hubs. Inspect each hub for indications of being powered on, such as: • Green Power LED illuminated. • Green Status LEDs illuminated. Is a hub failure indicated? Go to step Remove and replace the Ethernet hub. Refer to the supporting documentation shipped with the hub for instructions.

  • Page 70

    Diagnostics The Ethernet adapter on the switch CTP reset in response to an error. The connection to the HAFM server (or customer-supplied server) terminated briefly, then recovered upon reset. Perform the data collection procedure and return the Zip disk to HP for analysis. Exit MAP.

  • Page 71

    Diagnostics An instance of the HAFM application is open at another HAFM server (or customer-supplied server) and communicating with the switch (duplicate session). Notify the customer and either: • Power off the HAFM server (or customer-supplied server) running the second instance of the application, or •...

  • Page 72

    Diagnostics g. At the Network dialog box, click OK to close the dialog box. Figure 2–12: Microsoft TCP/IP Properties Dialog Box Continue. Configure the HAFM server (or customer-supplied server) reporting the Duplicate Session communication problem as a client. a. At the Products View, click Logout/Exit and select Logout. The HAFM Login dialog box displays.

  • Page 73

    Diagnostics Did the HAFM server (or customer-supplied server) reconfigure as a client and did the Ethernet connection recover? The switch-to-server connection is restored and the second HAFM server (or customer-supplied server) appears operational as a client. Exit MAP. Contact the next level of support. Exit MAP. The IP address defining the switch to the HAFM application is incorrect or unknown and must be verified.

  • Page 74

    Diagnostics f. Type Edge-32 in the Name field. Click OK. The Connect To dialog box displays. g. Ensure the Connect using field displays COM1 or COM2 (depending on the serial communication port connection to the switch) and click OK. The COMn dialog box displays (where n is 1 or 2).

  • Page 75

    Diagnostics i. At the > prompt, type the user-level password (the default is password) and press Enter. The password is case sensitive. The HyperTerminal window displays with software and hardware version information for the switch, and an C> prompt at the bottom of the window.

  • Page 76

    Diagnostics n. Click No to exit and close the HyperTerminal application. o. Power off the maintenance terminal. p. Disconnect the RS-232 modem cable from the switch and the maintenance terminal. Replace the protective cap over the maintenance port. Continue. Define the switch’s correct IP address to the HAFM server (or customer-supplied server).

  • Page 77

    Diagnostics d. At the Products View, click Configure and select New Product. The New Product dialog box displays. e. Type the configured IP address in the Network Address field. f. Select Edge Switch 2/24 from the Product Type list box and click OK. Did the IP address below the switch icon change to the new entry and did the Ethernet connection recover? The switch-to-server connection is restored and appears operational.

  • Page 78

    Diagnostics Ensure the switch reporting the problem is connected to facility AC power. Inspect the switch for indications of being powered on, such as: • At the front bezel, an illuminated green power LED or amber system error LED. • Audio emanations and airflow from cooling fans.

  • Page 79: Map 0500: Fru Failure Analysis

    Diagnostics MAP 0500: FRU Failure Analysis This MAP describes fault isolation for the switch and FRUs. Failure indicators include: • The amber LED on the FRU illuminates. • The amber emulated LED on a power supply at the Hardware View illuminates. •...

  • Page 80

    Diagnostics Table 2–9: MAP 500: Event Codes (Continued) Event Code Explanation Action High temperature warning (CTP Go to step thermal sensor). Critically hot temperature warning Go to step (CTP thermal sensor). Is fault isolation being performed at the switch? Fault isolation is being performed at the HAFM server (or customer-supplied server) or EWS interface.

  • Page 81

    Diagnostics Inspect the front of the switch. Is the amber LED illuminated but not blinking (beaconing)? Go to step Contact the next level of support. Exit MAP. Is fault isolation being performed at the HAFM server (or customer-supplied server)? Fault isolation is being performed at the EWS interface. Go to step Does a blinking red and yellow diamond (failed FRU indicator) appear to overlay a fan module/power supply graphic at the Hardware View?

  • Page 82

    Diagnostics At the switch, inspect the amber LED. Is the amber LED illuminated? A CTP card failure is indicated. Replace the switch. Exit MAP. Analysis for an Ethernet link or AC power distribution failure is not described in this MAP. Go to MAP 0000: Start MAP on page 2-6.

  • Page 83

    Diagnostics At the switch, inspect the amber LED. Is the amber LED illuminated? A CTP card failure is indicated. Replace the switch. Exit MAP. Analysis for an Ethernet link failure is not described in this MAP. Go to MAP 0000: Start MAP on page 2-6.

  • Page 84: Map 0600: Port Failure And Link Incident Analysis

    Diagnostics MAP 0600: Port Failure and Link Incident Analysis This MAP describes fault isolation shortwave laser small form factor pluggable (SFP) optical transceivers, and longwave laser SFP optical transceivers; and for Fibre Channel link incidents. Failure indicators include: • One or more amber LEDs on the ports illuminate. •...

  • Page 85

    Diagnostics Table 2–10 lists event codes, brief explanations of the codes, and associated steps that describe fault isolation procedures. Table 2–10: MAP 600: Event Codes Event Code Explanation Action Unauthorized worldwide name. Go to step Invalid attachment. Go to step Fibre Channel port failure.

  • Page 86

    Diagnostics Each port has an amber and green LEDs next to the ports. The amber LED illuminates and the green LED extinguishes if the port fails. Are an amber port LED and the amber LED illuminated but not blinking (beaconing)? The switch appears operational, however a link incident or other problem may have occurred.

  • Page 87

    Diagnostics Did a Fibre Channel port fail a loopback test? Go to step Does a yellow triangle (attention indicator) appear adjacent to a port graphic at the Hardware View? Go to step Inspect the port state and LED status for all ports with an attention indicator. a.

  • Page 88

    Diagnostics Table 2–11: Port Operational and LED States (Continued) Operational Green Amber State Action Link Incident Go to step 0700. Segmented Go to E_Port A link incident may have occurred, but the LIN alerts option is not enabled for the port and the attention indicator does not appear.

  • Page 89

    Diagnostics A Fibre Channel port failed an internal or external loopback test. a. Reset each port that failed the loopback test. 1. At the Hardware View, right-click the port. A pop-up menu appears. 2. Select Reset Port. A Reset Port n message box displays, where n is the port number.

  • Page 90

    Diagnostics The port has an invalid attachment. The information in the Port Properties dialog box specifies the reason (Table 2–12). Table 2–12: Port Properties, Invalid Attachment Reasons and Actions Reason Action Unknown Contact the next level of support. ISL connection not allowed on this port. Go to step Incompatible switch at other end of ISL.

  • Page 91

    Diagnostics The switch is configured for Open Fabric mode but the switch or switch at the other end of the ISL is not configured to Open Fabric mode, or switch is connected to a non-HP switch and the interop mode is set to homogeneous fabric mode. Configure the switch operating mode: a.

  • Page 92

    Diagnostics A loopback (wrap) plug is connected to the port and there is no diagnostic test running. Is a loopback plug in the port receptacle? Contact the next level of support. Exit MAP. Remove the loopback plug from the port receptacle. If directed by the customer, connect a fiber-optic jumper cable attaching a device to the switch.

  • Page 93

    Diagnostics Clean the fiber-optic connectors on the cable. a. Notify the customer the port will be blocked. Ensure the customer’s system administrator quiesces Fibre Channel frame traffic through the port and sets the attached device offline. b. Block the port (Block and Unblock Ports on page 3–25).

  • Page 94

    Diagnostics A link incident message appeared in the Link Incident Log or in the Link Incident field of the Port Properties dialog box; or an event code 581, 582, 583, 584, 585, or 586 was observed at the console of an OSI server attached to the switch reporting the problem.

  • Page 95

    Diagnostics Was a corrective action performed? Go to step Monitor port operation for approximately five minutes. Did the link incident recur? The Fibre Channel link and switch appear operational. Exit MAP. Clean fiber-optic connectors on the jumper cable. a. Notify the customer the port will be blocked. Ensure the customer’s system administrator quiesces Fibre Channel frame traffic through the port and sets the attached device offline.

  • Page 96

    Diagnostics The attached device is causing the recurrent link incident. Notify the customer of the problem and have the system administrator: a. Inspect and verify operation of the attached device. b. Repair the attached device if a failure is indicated. c.

  • Page 97

    Diagnostics Ensure the switch reporting the problem is connected to facility AC power. Inspect the switch for indications of being powered on, such as: • At the front bezel, an illuminated power LED (green) or system error LED (amber). • Audio emanations and airflow from cooling fans.

  • Page 98

    Diagnostics Install an SFP optical transceiver in the port receptacle (RRP 1: SFP Optical Transceiver on page 4–2). a. This procedure is concurrent and can be performed while switch power is on. b. Verify the location of the failed port. c.

  • Page 99: Map 0700: Fabric, Isl, And Segmented Port Problem Determination

    Diagnostics MAP 0700: Fabric, ISL, and Segmented Port Problem Determination This MAP describes isolation of fabric logout, interswitch link (ISL), and E_Port segmentation problems. Failure indicators include: • An event code recorded at the Edge Switch 2/24 Event Log or the EWS Event Log.

  • Page 100

    Diagnostics Table 2–14: MAP 600: Event Codes (Continued) Event Code Explanation Action switch is isolated. Go to step E_Port connected to unsupported switch. Go to step Is fault isolation being performed at the HAFM server (or customer-supplied server)? Fault isolation is being performed through the EWS interface. Go to step Does a yellow triangle (attention indicator) appear adjacent to a Fibre Channel port graphic at the Hardware View?

  • Page 101

    Diagnostics Inspect the Segmentation Reason field at the Port Properties dialog box. Table 2–15 lists port segmentation reasons and associated steps that describe fault isolation procedures. Table 2–15: Port Segmentation Reasons and Actions Segmentation Reason Action Incompatible operating parameters. Go to step Duplicate domain IDs.

  • Page 102

    Diagnostics A minor error occurred that caused fabric controller database to be re-initialized to an empty state. As a result, the switch briefly lost interswitch link capability. The following explains the error. • Event code 061 - The fabric controller database failed CRC validation. All interswitch links resume operation after CTP reset.

  • Page 103

    Diagnostics A 070 event code indicates an E_Port detected an incompatibility with an attached switch and prevented the switches from forming a multiswitch fabric. A segmented E_Port cannot transmit Class 2 or Class 3 Fibre Channel traffic. A 071 event code indicates the switch is isolated from all switches in a multiswitch fabric, and is accompanied by a 070 event code for each segmented E_Port.

  • Page 104

    Diagnostics A switch E_Port segmented because the error detect time out value (E_D_TOV) or resource allocation time out value (R_A_TOV) is incompatible with the attached fabric element. a. Contact HP customer support or engineering personnel to determine the recommended E_D_TOV and R_A_TOV values for both switches. b.

  • Page 105

    Diagnostics d. At the Hardware View for the first switch reporting the problem, click Configure and select Operating Parameters. The Configure Operating Parameters dialog box displays. e. Type the customer-determined preferred domain ID value, then click Activate. f. Repeat steps d and e at the Hardware View for the switch attached to the segmented E_Port (second switch).

  • Page 106

    Diagnostics Figure 2–16: Zone Set View e. Inspect zone names in the active zone set to determine the incompatible name. f. Modify the incompatible zone name as directed by the customer: 1. Click Configure and select Zoning Library. The Zoning Library dialog box displays.

  • Page 107

    Diagnostics 6. To activate the zone set, click Configure and select Active Zone Set. The Active Zone Set dialog box displays. Select the zone to be activated and click Next. 7. The new display summarizes the zone member changes that will be made by activating the new zone set.

  • Page 108

    Diagnostics A switch E_Port segmented because no switch in the fabric is capable of becoming the principal switch. a. Notify the customer the switch will set offline. Ensure the system administrator quiesces Fibre Channel frame traffic through the switch and sets attached devices offline.

  • Page 109

    Diagnostics A switch E_Port segmented (at an operational switch) because a response to a verification check indicates an attached switch is not operational. a. Perform the data collection procedure at the operational switch and return the Zip disk to HP for analysis. This information may assist in fault isolating the failed switch.

  • Page 110

    Diagnostics Is the Segmentation Reason field blank or does it display an N/A message? The switch ISL appears operational. Exit MAP. The Segmentation Reason field displays a reason message. Table 2–17 lists segmentation reasons and associated steps that describe fault isolation procedures. Table 2–17: Segmentation Reasons and Actions Segmentation Reason Action...

  • Page 111: Map 0800: Console Pc Problem Determination

    Diagnostics MAP 0800: Console PC Problem Determination This MAP describes isolation of hardware-related problems with the HAFM server (or customer-supplied server) platform. Although this MAP provides high-level fault isolation instructions, refer to the documentation provided with the PC for detailed problem determination and resolution.

  • Page 112

    Diagnostics d. Close the dialog box by clicking Close at the upper right corner of the window. Does the computer have sufficient memory? A memory upgrade is required. Inform the customer of the problem and contact the next level of support. Reboot the HAFM server PC and perform system diagnostics.

  • Page 113

    Diagnostics Did POSTs detect a problem? A computer hardware problem exists. Refer to the supporting documentation shipped with the PC for instructions on resolving the problem. After rebooting the PC, the HAFM application starts and the HAFM Login dialog box displays.

  • Page 114

    Diagnostics Reboot the HAFM server PC. a. Click the Windows Start button. The Windows Workstation menu displays. b. At the Windows Workstation menu, select Shut Down. The Shut Down Windows dialog box appears. c. At the Shut Down Windows dialog box, select Shut down the Computer and click Yes to power off the PC.

  • Page 115

    Diagnostics Advise the customer and next level of support that the PC hard drive should be formatted. If the customer and support personnel do not concur, go to step a. Format the PC hard drive. Refer to supporting documentation shipped with the PC for instructions.

  • Page 117: Repair Information

    Repair Information isible Body Tag This chapter describes the repair and repair-related procedures for the HP StorageWorks Edge Switch 2/24, and associated field-replaceable units (FRUs). These procedures are described: • Obtaining log information at the HP StorageWorks HA-Fabric Manager (HAFM) server.

  • Page 118: Procedural Notes

    Repair Information Factory Defaults Table 3–1 lists the defaults for the passwords, and IP, subnet, and gateway addresses. Table 3–1: Factory-Set Defaults Item Default Customer password password Maintenance password level-2 IP address 10.1.1.10 Subnet mask 255.0.0.0 Gateway address 0.0.0.0 Procedural Notes NOTE: HAFM and Product Manager screens in this manual may not match the screens on your server and workstation.

  • Page 119: Using Log Information, Hafm Audit Log

    Repair Information Using Log Information The HAFM and switch product manager provide access to ten logs that provide information for administration, operation, and maintenance personnel. Each log stores up to 1,000 entries. The most recent entry appears at the top of a log. If a log is full, a new entry overwrites the oldest entry.

  • Page 120: Hafm Event Log

    Repair Information HAFM Event Log The HAFM Event Log (Figure 3–1) displays events or error conditions recorded by the HAFM services application. Entries reflect the status of the application and managed switches. Information associated with a call-home failure is intended for maintenance personnel to fault isolate the problem (modem failure, no dial tone, etc.), while information provided in all other entries is generally intended for use by third-level support personnel to isolate more significant problems.

  • Page 121: Session Log, Product Status Log

    Repair Information • Data - additional event data for fault isolating a problem. Use the information when fault isolating a call-home problem, or include the information when reporting an event to third-level customer support. To ensure recently-created events appear in the log, periodically refresh the log display.

  • Page 122: Fabric Log

    Repair Information The log contains the following columns: • Date/Time - the date and time the switch status change occurred. • Network Address - the IP address or configured name of the switch. This address or name corresponds to the address or name displayed under the switch icon at the Product View.

  • Page 123: Edge Switch 2/24 Audit Log, Edge Switch 2/24 Event Log

    Repair Information Edge Switch 2/24 Audit Log The switch Audit Log displays a history of all configuration changes made to a switch from the Product Manager or a simple network management protocol (SNMP) management workstation. This information is useful for system administrators and users.

  • Page 124: Hardware Log, Refresh The Event Log, Clear The Event Log

    Repair Information • FRU-Position - an acronym representing the FRU or non-FRU elements, followed by a number representing the FRU or chassis position. The acronyms are: — CTP - control processor (CTP) card. The chassis slot is 0. The CTP card is not a FRU.

  • Page 125: Link Incident Log

    Repair Information The log contains the following columns: • Date/Time - the date and time the FRU was inserted or removed. • FRU - an acronym representing the FRU type or non-FRU element. The acronyms are: A failed CTP — CTP - control processor (CTP) card. The CTP card is not a FRU. card requires replacement of the switch —...

  • Page 126

    Repair Information Figure 3–5: Link Incident Log The log contains the following columns: • Date/Time - the date and time the link incident occurred. • Port - the port number that reported the link incident (0 through 23). • Link Incident - a brief description of the link incident. Problem descriptions include: —...

  • Page 127: Threshold Alert Log, Refresh The Link Incident Log, Clear The Link Incident Log

    Repair Information Refresh the Link Incident Log To ensure recently-created link incidents appear in the Link Incident Log, periodically refresh the log display. To refresh the log, click Refresh at the bottom of the log window. Clear the Link Incident Log To ensure the Link Incident Log is up-to-date and not filled with archived incidents, periodically clear the log display.

  • Page 128

    Repair Information • Date/Time Date and time stamp for when the alert occurred. • Name Name for the alert as configured through the Configure Threshold Alerts dialog box. • Port Port number where the alert occurred. • Type The type of alert: transmit (TX) or receive (RX). •...

  • Page 129: Performing Port Diagnostics, Port Leds

    Repair Information Performing Port Diagnostics Fibre channel port diagnostics are performed at the switch and Product Manager application. These diagnostics include: • Inspecting port LEDs at the switch front panel or emulated port LEDs at the HAFM Hardware View. • Inspecting parameters at the HAFM server (Edge Switch 2/24 Product Manager application).

  • Page 130

    Repair Information Table 3–2: Port Operational States (Continued) Port Blue/Green Amber Alert State Symbol Description Offline None The port is blocked and transmitting the offline sequence (OLS) to the attached device. Yellow The port is unblocked and receiving Triangle the OLS, indicating the attached device is offline.

  • Page 131: Hardware View

    Repair Information Table 3–2: Port Operational States (Continued) Port Blue/Green Amber Alert State Symbol Description Yellow The port is receiving the not Operati Triangle operational sequence (NOS) from an onal attached device. Port Red and The port failed and requires service. Failure Yellow Blinking...

  • Page 132

    Repair Information Figure 3–7: Hardware View Click the port connector (leftmost port) to open the Port Properties dialog box (Figure 3–8). Figure 3–8: Port Properties Dialog Box Refer to the hp StorageWorks edge switch 2/24 product manager user guide for an explanation of the Hardware View and Port Properties dialog box.

  • Page 133: Performance View

    Repair Information Performance View The Performance View (Figure 3–9) displays statistical information about the performance of the ports. The information is useful for isolating port problems. To open the Performance View from the Hardware View, select Performance from the View menu on the navigation control panel. Figure 3–9: Performance View Refer to the hp StorageWorks edge switch 2/24 product manager user guide for an explanation of the Performance View.

  • Page 134: Perform Loopback Tests, Internal Loopback Test

    Repair Information Perform Loopback Tests This section describes procedures to perform an: • Internal loopback test - an internal loopback test checks internal port, serializer, and deserializer circuitry and checks for the presence of an optical transceiver, but does not check fiber-optic components of the installed transceiver. Operation of the attached device is disrupted during the test.

  • Page 135

    Repair Information Figure 3–10: Port Diagnostics Dialog Box 8. Click Next. The message Press START TEST to begin diagnostics appears, and the Next button changes to a Start Test button. 9. Click Start Test. The test begins and: — The Start Test button changes to a Stop Test button —...

  • Page 136: External Loopback Test

    Repair Information External Loopback Test To perform an external loopback test for a single port: 1. Notify the customer that a disruptive external loopback test will be performed on a port and the fiber-optic cable or cables will be disconnected. Ensure the customer’s system administrator quiesces Fibre Channel frame traffic through the port and sets attached devices offline.

  • Page 137

    Repair Information 12. Click Start Test. The test begins and: — The Start Test button changes to a Stop Test button — The message Port xx: TEST RUNNING appears. — A red progress bar (indicating percent completion) travels from left to right across the Completion Status field.

  • Page 138: Collecting Maintenance Data

    Repair Information Collecting Maintenance Data When the switch operational firmware detects a critical error, the switch automatically copies the contents of dynamic random access memory (DRAM) to a dump area in FLASH memory on the CTP card, then transfers (through the Ethernet connection) the captured dump file from FLASH memory to the HAFM server hard drive.

  • Page 139: Set The Switch Online Or Offline, Set Online State

    7. Click Close to close the dialog box. 8. Remove the Zip disk with the newly-collected maintenance data from the HAFM server Zip drive. Return the Zip disk to Hewlett-Packard for failure analysis. 9. To ensure the QuikSync backup application operates normally, replace the original backup disk in the HAFM server Zip drive.

  • Page 140: Set Offline State

    Repair Information 3. At the navigation control panel, select Set Online State from the Maintenance menu. If the switch is offline, the Set Online State dialog box displays, indicating the state is OFFLINE. Figure 3–13: Set Online Warning dialog box 4.

  • Page 141: Block And Unblock Ports, Block A Port

    Repair Information Block and Unblock Ports This section describes procedures to block or unblock the switch Fibre Channel ports. Blocking a port prevents the attached device or fabric switch from communicating. A blocked port continuously transmits the offline sequence (OLS). NOTE: When a port is blocked, the operation of an attached Fibre Channel device is disrupted.

  • Page 142: Unblock A Port

    Repair Information Unblock a Port To unblock a port: 1. At the HAFM server, open the HAFM application. The Product View displays. 2. Select the icon representing the switch with the port to be unblocked. The Hardware View for the selected switch displays. 3.

  • Page 143: Clean Fiber-optic Components

    Repair Information Clean Fiber-Optic Components Perform this procedure as directed in this publication and when connecting or disconnecting fiber-optic cables from port optical transceivers (if necessary). To clean fiber-optic components: 1. Obtain the appropriate tools (portable can of oil-free compressed air and alcohol pads) from the fiber-optic cleaning kit.

  • Page 144: Power-on Procedure

    1. One alternating current (AC) power cord is required for each power supply. Ensure power cord(s) are available to connect the switch to facility power. A Hewlett-Packard-supplied power cord is provided for each switch WARNING: power supply. To prevent electric shock when connecting the switch to primary facility power, use only the supplied power cord(s), and ensure the facility power receptacle is the correct type, supplies the required voltage, and is properly grounded.

  • Page 145: Power-off Procedure, Iml, Ipl Or Reset The Switch

    Repair Information Power-Off Procedure To power-off the switch: 1. Notify the customer the switch is to be powered off. Ensure the customer’s system administrator quiesces Fibre Channel frame traffic through the switch and sets attached devices offline. 2. Set the switch offline (Set Offline State on page 3–24).

  • Page 146: Switch Iml, Switch Ipl

    Repair Information Switch IML To IML the switch from the front panel: 1. Press and hold the IML/RESET button until the amber ERR LED blinks at twice the unit beaoning rate (approximately three seconds). 2. Release the button to IML the switch. During the IML, the switch-to-HAFM server Ethernet link drops momentarily and the following occur at the Hardware View: —...

  • Page 147: Switch Reset

    Repair Information Switch Reset To reset the switch from the front panel: 1. Press and hold the IML/RESET button for approximately ten seconds. — After holding the button for three seconds, the amber ERR LED blinks at twice the unit beaoning rate. —...

  • Page 148: Manage Firmware Versions, Determine A Switch Firmware Version

    Repair Information Manage Firmware Versions Firmware is the internal operating code stored in FLASH memory on the the switch’s CTP card. Up to eight versions can be stored on the HAFM server hard drive and made available for download to a switch. Service personnel can perform the following firmware management tasks: •...

  • Page 149: Add A Firmware Version

    Repair Information Add a Firmware Version The firmware version shipped with the switch is provided on the Edge Switch 2/24 documentation kit CD. Subsequent firmware versions for upgrading the switch are provided to customers through the HP website. NOTE: When adding a firmware version, follow all the instructions in the release notes that accompany the firmware version.

  • Page 150

    Repair Information 4. At the navigation control panel, select Firmware Library from the Maintenance menu. The Firmware Library dialog box displays. Figure 3–19: Firmware Library dialog box 5. Click New. The New Firmware Version dialog box displays. Figure 3–20: New Firmware Version dialog box 6.

  • Page 151: Download A Firmware Version To A Switch

    Repair Information The New Firmware Description dialog box displays. Figure 3–21: Firmware Description dialog box 7. Enter a description (up to 24 characters) for the new firmware version and click OK. The description should include the installation date and text that uniquely identify the firmware version.

  • Page 152

    Repair Information 3. Before downloading firmware version XX.YY.ZZ to a switch, ensure version XX.YY.ZZ or higher of the HAFM application is running on the HAFM server. a. Select About from the Help menu. The About dialog box displays the HAFM application version.

  • Page 153

    Repair Information As the download begins, a Sending Files message displays at the top of the dialog box. This message remains for a few moments as a progress bar travels across the dialog box to show percent completion of the download. As the download progresses, a Writing data to FLASH message displays.

  • Page 154: Manage Configuration Data, Back Up The Configuration

    Repair Information Manage Configuration Data The Product Manager application provides maintenance options to back up, restore, or reset the configuration file stored in nonvolatile random-access memory (NV-RAM) on the switch CTP card. Configuration data in the file include: • Switch identification data. •...

  • Page 155: Restore The Configuration

    Repair Information 4. Click Backup. When the backup process finishes, the Backup Complete message displays. Figure 3–25: Backup Complete message 5. Click OK to close the dialog box and return to the Hardware View. Restore the Configuration To restore the switch configuration file from the HAFM server: 1.

  • Page 156: Reset Configuration Data

    Repair Information 7. Click Yes. When the restore process finishes, the Restore Complete message displays. Figure 3–27: Restore Complete message 8. Click OK to close the dialog box and return to the Hardware View. Reset Configuration Data NOTE: This procedure resets the switch IP address to the default of 10.1.1.10 and may disrupt server-to-switch communication.

  • Page 157

    Repair Information 8. To change the switch IP address and restart the HAFM server session, go to step 9. To restart an HAFM server session using the default IP address of 10.1.1.10: a. Close the Edge Switch 2/24 Product Manager application and return to the Products View.

  • Page 158: Install Or Upgrade Software

    Applications CD-ROM. Subsequent software versions for upgrading the switch are provided to customers through the HAFM Applications CD-ROM or through Hewlett-Packard’s home page. NOTE: When installing or upgrading a software version, follow all procedural information in the release notes or instructions that accompany the software version. This information supplements information in this general procedure.

  • Page 159

    Repair Information 5. At the Run dialog box, select directory path (hard drive or CD-ROM drive) and filename of the executable file ( ) using the Browse HAFM_ServerInstall.exe button. The directory path and filename display in the Open field. 6. Click OK. A series of message boxes appear as the InstallAnywhere third-party application prepares to install the HAFM application software, followed by the HAFM dialog box.

  • Page 160

    Repair Information 9. The HAFM application automatically opens. At the HAFM splash screen, enter a user name, password, and HAFM server name (all are case sensitive), and click Login. The application opens and the Product View displays. NOTE: If required, obtain the user name, password, and HAFM server name from the customer or next level of support.

  • Page 161: Remove And Replace Frus, Fru Removal And Replacement

    Invisible Body4 FRU Removal and Replacement This chapter describes the removal and replacement procedures (RRPs) for the HP StorageWorks Edge Switch 2/24 field-replaceable units (FRUs). Do not remove a FRU until a failure is isolated to that FRU. If fault isolation was not performed, see 0000: Start MAP on page 2–6.

  • Page 162: Tools Required, Rrp 1: Sfp Optical Transceiver

    FRU Removal and Replacement Table 4–1 lists concurrent FRUs that are removed and replaced while the switch is powered on and operational. The table also lists ESD precautions (yes or no) for each FRU, and references the page number of the removal and replacement procedure. Table 4–1: Concurrent FRUs ESD Precaution Concurrent FRU Name...

  • Page 163

    FRU Removal and Replacement 4. Disconnect the fiber-optic jumper cable from the port: a. Pull the keyed LC connector free from the port’s optical transceiver. b. Place a protective cap over the jumper cable connector. 5. The optical transceiver has a wire locking bale to secure the transceiver in the port receptacle and to assist in removal.

  • Page 164

    FRU Removal and Replacement b. Clean the jumper cable and transceiver connectors. Refer to Clean Fiber-Optic Components on page 3–27 for instructions. c. Insert the keyed LC cable connector into the port’s optical transceiver. 5. Ensure the amber LED adjacent to the port transceiver is extinguished. If the amber LEDs is illuminated, go to MAP 0000: Start MAP on page 2–6 to isolate...

  • Page 165: Rrp 2: Redundant Power Supply

    FRU Removal and Replacement c. Right-click the graphic representing the port with the replacement transceiver and select Port Technology from the menu. The Port Technology dialog box displays. Verify port technology information is correct. d. If a problem is indicated, go to MAP 0000: Start MAP on page 2–6 to isolate the problem.

  • Page 166

    FRU Removal and Replacement b. Use the finger handles to pull the power supply out of the switch chassis as shown in part (B) of Figure 4–1. Support the power supply as it is pulled from the chassis. WARNING: To prevent electric shock, do not reach into nonvisible areas of a Edge Switch 2/24 connected to primary facility power.

  • Page 167

    FRU Removal and Replacement If at the HAFM server, open the Hardware View, click Logs, and select Event Log. The Event Log displays. The Event Log displays. The following event codes appear: — 200 - Power supply AC voltage failure (recorded when AC power is disconnected).

  • Page 168

    FRU Removal and Replacement If at a web browser connected to the EWS interface, click the Log tab at the Monitor panel. The Event Log displays. Ensure the following event codes appear. If the event codes do not appear, go to MAP 0000: Start MAP on page 2–6 to isolate the problem.

  • Page 169

    FRU Removal and Replacement 9. Perform one of the following to clear the system error (ERR) LED on the switch front bezel: — If at a web browser connected to the EWS interface, click the Log tab at the Monitor panel. The Event Log displays. Click Clear System Error Light. —...

  • Page 171: Hafm Application Messages

    Invisible Body TagA Messages This appendix lists information and error messages that appear in pop-up message boxes at the HP StorageWorks HA-Fabric Manager (HAFM) application and HP StorageWorks Edge Switch 2/24 Product Manager applications. The first section of the appendix lists HAFM application messages. The second section lists Product Manager messages.

  • Page 172

    Messages Message Description Action All zone members An attempt was made Information message - no are logged. to display all zone action required. members not logged-in using the Zone Set tab, but all members are logged Are you sure you The currently- Click Yes to delete or No to want to delete this...

  • Page 173

    Messages Message Description Action Cannot add a switch The device that you Specify the port number or to a zone. are attempting to add corresponding world wide to the zone is a name (WWN) for the device switch, which cannot you want to add to the zone.

  • Page 174

    Messages Message Description Action Cannot display route. The user cannot Enable the default zone or Device is not a show the route for a activate the zone for the member of a zone in device that is not a device before attempting to the active zone set.

  • Page 175

    Messages Message Description Action Cannot modify The selected product Verify the HAFM product. cannot be modified. server-to-product link is up. • If the link is up, the HAFM server may be busy. • Another Product Manager instance may be open. •...

  • Page 176

    Messages Message Description Action Cannot show zoning The user cannot Identify a Director or Edge library. No fabric show the zoning Switch to the HAFM exists. library if no fabric application from the New exists. A Director or Product dialog box. Edge Switch must be identified to the HAFM application for...

  • Page 177

    Messages Message Description Action Device is not a The selected device Enable the default zone or member of a zone in is not a member of a activate a zone set containing the active zone set. zone in the active the member before zone set and cannot attempting to show the route.

  • Page 178

    Messages Message Description Action Duplicate zone More than one Delete one of the duplicate member in zone instance of a zone zone members from the zone. configuration. member is defined in a zone. Enabling this zone Only one zone set Click OK to continue or set will replace the can be active.

  • Page 179

    Messages Message Description Action Error transferring files An error occurred Try the file transfer operation < message >. while transferring files again. If the problem persists, from the PC hard contact the next level of drive to the HAFM support. application.

  • Page 180

    Messages Message Description Action HAFM error <error The HAFM Contact the next level of number 1 through 8 application support to report the problem. >. encountered an internal error (1 through 8 inclusive) and cannot continue operation. HAFM server is The HAFM Reboot the HAFM server.

  • Page 181

    Messages Message Description Action Invalid name. One of the following Select a valid name and retry invalid names was the operation. used: CON, AUX, COM1, COM2, COM3, COM4, COM5, COM6, COM7, COM8, COM9, LPT1, LPT2, LPT3, LPT4, LPT5, LPT6, LPT7, LPT8, LPT9, NUL, or PRN.

  • Page 182

    Messages Message Description Action Invalid request. Three conditions Select the action that is result in this appropriate to the activity that message: caused the error: • The user tried to • Network address: Specify add or modify a a unique network (IP) product from address for the product.

  • Page 183

    Messages Message Description Action Invalid UDP port The specified user Verify and enter a valid UDP number. datagram protocol port number. (UDP) port number is invalid. The number must be an integer from 1 through 65535 inclusive. Invalid World-Wide The specified Enter a world-wide name Name or nickname.

  • Page 184

    Messages Message Description Action No address selected. You cannot complete Select an address and retry the operation the operation. because an address has not been selected. No attached nodes An operation was Select an attached node and selected. attempted without an try the operation again.

  • Page 185

    Messages Message Description Action No zone selected or A zoning operation Select a zone and try the zone no longer exists. was attempted operation again. without a zone selected, or the zone selected no longer exists in the fabric. No zone set active. A zone set cannot be Informational message deactivated if there...

  • Page 186

    Messages Message Description Action Remote session The connection Consult with the customer’s support has been between the network administrator to disabled. specified remote determine if the workstation workstation and the entry should be modified at HAFM server was the Session Options dialog disallowed.

  • Page 187

    Messages Message Description Action The Domain ID was A user attempted to Enter a unique domain ID for not accepted. The add a Director or the switch in the Add World Wide Name Edge Switch to the Detached Switch dialog box. and Domain ID must fabric membership be unique in the...

  • Page 188

    Messages Message Description Action The maximum The maximum Close a Product Manager number of open number of open session (existing open products has already products allowed was product) before opening a been reached. reached. new session. The maximum The number of Delete an existing product number of products managed HA Fabric...

  • Page 189

    Messages Message Description Action The maximum The number of HAFM Delete an existing IP address number of HAFM server IP addresses before adding a new address. server network that can be defined to addresses has the HAFM application already been was reached.

  • Page 190

    Messages Message Description Action The software version A second HAFM Upgrade the software version on this HAFM server server PC (client) on the downlevel HAFM is not compatible with connecting to the server PC. the version on the HAFM server must remote HAFM server.

  • Page 191

    Messages Message Description Action This user name has The specified user Modify (to make it unique) or already been name is already delete the duplicate name. assigned. assigned and configured. This Worldwide A user attempted to Enter a unique WWN for the Name was not add a product to the Director or Edge Switch at the...

  • Page 192

    Messages Message Description Action You must define at At least one e-mail Define an e-mail address at least one E-mail address must be the Configure E-Mail dialog address. defined and box. configured for e-mail to be activated. You must define at At least one IP Define an IP address for at least one remote...

  • Page 193

    Messages Edge Switch 2/24 Product Manager Messages This section lists switch Product Manager information and error messages in alphabetical order. Message Description Action Activating this Confirmation Click Yes to confirm activating configuration will message to activate the new address overwrite the current a new address configuration or No to cancel configuration.

  • Page 194

    Messages Message Description Action Are you sure you This message Click Yes to send the want to send requests confirmation firmware version or No to firmware version? to send a firmware abort the operation. version from the HAFM server’s firmware library to the switch or director.

  • Page 195

    Messages Message Description Action Cannot perform this This operation cannot Set the switch offline through operation while the be performed while the Set Online State dialog switch is offline. the switch is offline. box and retry the operation. Cannot retrieve The switch or director Retry the operation later.

  • Page 196

    Messages Message Description Action Cannot retrieve port Port information Retry the operation later. If information. cannot be retrieved the condition persists, contact by the Product the next level of support. Manager application because the Ethernet link is down or busy. Cannot retrieve port Port statistics cannot Retry the operation later.

  • Page 197

    Messages Message Description Action Cannot run Port diagnostics Ensure the device is logged diagnostics while a (internal loopback out and perform diagnostics device is logged-in to test) cannot be again. the port. performed on a port while an attached Fibre Channel device is logged in.

  • Page 198

    Messages Message Description Action Cannot set fibre Fibre Channel Retry the operation later. If channel parameters. parameters for the the condition persists, contact switch or director the next level of support. cannot be set at the Product Manager application because the Ethernet link is down or busy.

  • Page 199

    Messages Message Description Action Could not export log A log file I/O error If the disk is full, use another to file. occurred and the file disk. If the disk is write could not be saved to protected, change the the specified write-protect properties or destination.

  • Page 200

    Messages Message Description Action Date entered is The date is entered Verify each entry is valid and invalid. incorrectly at the consistent. Configure Date and Time dialog box. Individual field entries may be correct, but the overall date is invalid (for example, a day entry of 31 for a 30-day month).

  • Page 201

    Messages Message Description Action Disabling Switch A user attempting to Disable Enterprise Fabric Binding will disable disable switch Mode at the Enterprise Enterprise Fabric binding through the Fabric Mode dialog box Mode. Do you want to Switch Binding before disabling switch continue? State Change dialog binding.

  • Page 202

    Messages Message Description Action Error retrieving port An error occurred at Retry the operation later. If information. the Product Manager the condition persists, contact application while the next level of support. retrieving port information because the Ethernet link is down or busy. Error retrieving port An error occurred at Retry the operation later.

  • Page 203

    Messages Message Description Action File transfer is in A firmware file is Informational message progress. being transferred only-no action is required. from the HAFM server hard drive, or a data collection file is being transferred to a diskette. Firmware download A firmware download Retry the operation.

  • Page 204

    Messages Message Description Action Installing this feature If the switch is online, Click Yes to install the feature key, while online, will installing a feature key or No to discontinue the cause an IPL key causes a switch operation. operation on the IPL.

  • Page 205

    Messages Message Description Action Invalid response An error occurred at Retry the firmware download received from switch. the switch or director operation. If the problem during a firmware persists, contact the next level download operation. of support. Invalid serial number The switch serial Ensure the entered feature for this feature key.

  • Page 206

    Messages Message Description Action Invalid value for At the Configure Verify and enter a valid time. minute (0 - 59). Date and Time dialog box, the MM value (minute) must be an integer from 0 through 59 inclusive. Invalid value for At the Configure Verify and enter a valid date.

  • Page 207

    Messages Message Description Action Invalid World-Wide The specified Enter a world-wide name Name. world-wide name using the correct format. format is invalid. The valid format is eight two-digit hexadecimal numbers separated by colons (xx:xx:xx:xx:xx:xx:xx: xx). Link dropped. The HAFM Retry the operation. If the server-to-switch or condition persists, contact the director Ethernet link...

  • Page 208

    Messages Message Description Action No firmware versions There are no Informational message to delete. firmware versions in only-no action is required. the firmware library to delete, therefore the operation cannot be performed. No firmware version A file was not Click on a firmware version in was selected.

  • Page 209

    Messages Message Description Action Performing this This message Click OK to set the switch or operation will change requests confirmation director online or Cancel to the current state to to set the switch or cancel the operation. Online. director online. Periodic Date/Time Action cannot be Click Periodic Date/Time...

  • Page 210

    Messages Message Description Action Send firmware failed. A firmware download Retry the firmware download operation failed. operation. If the problem persists, contact the next level of support. SNMP trap address If an SNMP Enter a corresponding SNMP not defined. community name is trap recipient address.

  • Page 211

    Messages Message Description Action System diagnostics System diagnostics Replace failed ports. cannot run. The cannot run on switch Operational Status is or Director or Edge invalid. Switch with failed ports. The add firmware The user aborted the Verify the firmware addition is process has been process to add a to be aborted, then click OK...

  • Page 212

    Messages Message Description Action The switch did not The switch or director Retry the operation. If the accept the request. cannot perform the condition persists, contact the requested action. next level of support. The switch did not While waiting to Retry the operation.

  • Page 213

    Messages Message Description Action This feature has not A user selected an Contact your sales been installed. option that is representative to obtain and Please contact your unavailable because install the desired optional sales representative. a necessary feature feature. is not installed. This feature key does The installed feature Set the switch offline through...

  • Page 214

    Messages Message Description Action Unable to save data The HAFM server Retry the operation. If the collection file to could not save the condition persists, contact the destination. data collection file to next level of support. the specified location (PC hard drive, diskette, or network).

  • Page 215: Event Codes

    Event Codes This appendix lists all three-digit HP StorageWorks Edge Switch 2/24 event codes and provides detailed information about each code. Event codes are listed in numerical order and in tabular format. An event is an occurrence (state change, problem detection, or problem correction) that requires user attention or that should be reported to a system administrator or service representative.

  • Page 216

    Event Codes In addition to numerical event codes, the tables in this appendix also provide a: • Message - a brief text string that describes the event. • Severity - a severity level that indicates event criticality as follows: — 0 - informational. —...

  • Page 217

    Fabric logout of all attached devices. Action: Perform the data collection procedure and return the Zip disk to Hewlett-Packard support personnel. Event Data: No supplementary data included with this event.

  • Page 218

    All Fabric Services databases are initialized to an empty, state resulting in an implicit Fabric logout of all attached devices. Action: Perform the data collection procedure and return the Zip disk to Hewlett-Packard support personnel. Event Data: No supplementary data included with this event.

  • Page 219

    CRC validation. All Management Services databases are initialized to an empty state, resulting in an implicit logout of all devices logged in to the Management Server. Action: Perform the data collection procedure and return the Zip disk to Hewlett-Packard support personnel. Event Data: No supplementary data included with this event.

  • Page 220

    Action: Management Server internal error: Perform the data collection procedure and return the Zip disk to Hewlett-Packard support personnel. Asynchronous status report activation: No action required. Mode register update: No action required. Event Data: Supplementary data consists of reporting tasks of type eMST_SB2, with component_id eMSCID_SB2_CHPGM.

  • Page 221

    All Fabric Controller databases are initialized to an empty state, resulting in a momentary loss of interswitch communication capability. Action: Perform the data collection procedure and return the Zip disk to Hewlett-Packard support personnel. Event Data: No supplementary data included with this event.

  • Page 222

    Event Codes Event Code: 063 Message: Remote switch has too many ISLs. Severity: Major. Explanation: The fabric element (director or switch) whose domain ID is indicated in the event data has too many ISLs attached, and that element is unreachable from this switch. HAFM application Version 3.2 and earlier supports up to 32 ISLs.

  • Page 223

    Event Codes Event Code: 070 Message: E_Port is segmented. Severity: Informational. Explanation: A switch E_Port recognized an incompatibility with an attached fabric element (Director or Edge Switch), preventing the switch from participating in the fabric. A segmented port does not transmit Class 2 or Class 3 traffic (data from attached devices), but transmits Class F traffic (management and control data from the attached Director or Edge Switch).

  • Page 224

    Disconnect the E_Port link, reconnect the link, and initial program load (IPL) the switch. If the condition persists, perform the data collection procedure and return the Zip disk to Hewlett-Packard support personnel. 5 = No principal switch. No Director or Edge Switch in the fabric can become the principal switch.

  • Page 225

    Event Codes Event Code: 070 (continued) Distribution: Switch HAFM Server Host System Event E-Mail Call Sense Link Event Error Home Info Incident Event Code: 071 Message: Switch is isolated. Severity: Informational. Explanation: The switch is isolated from other fabric elements (Director or Edge Switch). This event code is accompanied by one or more 070 event codes.

  • Page 226

    Check the status of the attached Director or Edge Switch. If the condition persists, perform the data collection procedure (at the attached device) and return the Zip disk to Hewlett-Packard support personnel. 7 = ELP retransmission failure timeout. A switch that exhibits a hardware or link failure attempted to join a fabric and transmitted multiple ELP frames to a fabric element (Director or Edge Switch).

  • Page 227

    An error was detected during the fabric initialization sequence, most likely caused by frame delivery errors. Event data is intended for engineering evaluation. Action: Perform the data collection procedure and return the Zip disk to Hewlett-Packard support personnel. Event Data: Byte 0 = error reason code for engineering evaluation.

  • Page 228

    Event Codes Event Code: 080 Message: Unauthorized world-wide name. Severity: Informational. Explanation: The world-wide name of the device or switch plugged in the indicated port is not authorized for that port. Action: Change the port binding definition or plug the correct device or switch into this port. Event Data: Byte 0 = Port number reporting the unauthorized connection.

  • Page 229

    Event Codes Event Code: 081 Message: Invalid attachment. Severity: Informational. Explanation: A switch port recognized an incompatibility with the attached fabric element or device and isolated the port. An isolated port does not transmit Class 2, Class 3, or Class F traffic.

  • Page 230

    Event Codes B = Unresponsive node - The attached node did not respond, resulting in a G_Port ELP timeout. Check the status of the attached device and clean the link’s fiber-optic components (cable and connectors). If the problem persists, contact support personnel to report the problem.

  • Page 231

    No action is required for an isolated event. If this event persists, perform a data collection for this switch using the HAFM application. Perform the data collection procedure and return the Zip disk to Hewlett-Packard support personnel. Event Data: No supplementary data included with the event.

  • Page 232

    Action: Replace the failed power supply. Perform the data collection procedure and return the Zip disk and failed power supply to Hewlett-Packard support personnel. Event Data: No supplementary data included with this event.

  • Page 233

    Event Codes Event Code: 203 Message: Power supply AC voltage recovery. Severity: Informational. Explanation: AC voltage recovered for the power supply. Both power supplies adjust to share operating load for the switch. Action: No action required. Event Data: No supplementary data included with the event. Distribution: Switch HAFM Server...

  • Page 234

    Event Codes Event Code: 206 Message: Power supply removed. Severity: Informational. Explanation: A power supply was removed while the Switch was powered on and operational. The second power supply assumes the full operating load for the switch. Action: No action required or install an operational power supply. Event Data: No supplementary data included with this event.

  • Page 235

    Event Codes Fan Module Events (300 through 399) Event Code: 300 Message: Cooling fan propeller failed. Severity: Major. Explanation: One cooling fan (out of six) failed or is rotating at insufficient angular velocity. The remaining fans are operational. The amber LED illuminates at the rear of the power supply assembly associated with the failed fan.

  • Page 236

    Event Codes Event Code: 302 Message: Cooling fan propeller failed. Severity: Major. Explanation: Three cooling fans (out of six) failed or are rotating at insufficient angular velocity. The remaining fans are operational. The amber LED illuminates at the rear of the power supply assembly (or assemblies) associated with the failed fans.

  • Page 237

    Event Codes Event Code: 304 Message: Cooling fan propeller failed. Severity: Major. Explanation: Five cooling fans (out of six) failed or are rotating at insufficient angular velocity. The remaining fan is operational. The amber LED illuminates at the rear of both power supply assemblies.

  • Page 238

    Event Codes Event Code: 310 Message: Cooling fan propeller recovered. Severity: Informational. Explanation: One cooling fan (out of six) recovered or the associated power supply assembly was replaced. All fans are operational. Action: No action required. Event Data: The first byte of event data (byte 0) specifies the recovered fan number (0 through 5 inclusive).

  • Page 239

    Event Codes Event Code: 312 Message: Cooling fan propeller recovered. Severity: Informational. Explanation: Three cooling fans (out of six) recovered or the associated power supply assembly (or assemblies) were replaced. All fans are operational. Action: No action required. Event Data: The first byte of event data (byte 0) specifies the recovered fan numbers (0 through 5 inclusive).

  • Page 240

    Event Codes Event Code: 314 Message: Cooling fan propeller recovered. Severity: Informational. Explanation: Five cooling fans (out of six) recovered or both power supply assemblies were replaced. All fans are operational. Action: No action required. Event Data: The first byte of event data (byte 0) specifies the recovered fan numbers (0 through 5 inclusive).

  • Page 241

    If a CTP card failure is indicated, replace the switch. If a fan or power supply failure is indicated, replace the power supply assembly. Perform the data collection procedure and return the Zip disk to Hewlett-Packard support personnel. Event Data: Byte 0 = FRU code as follows: 02 = CTP card, 05 = cooling fan, 06 = power supply assembly.

  • Page 242

    The switch performs a software reset, during which all attached Fibre Channel devices are momentarily disrupted, log out, and log back in. Action: Perform the data collection procedure and return the Zip disk to Hewlett-Packard support personnel. Event Data: Bytes 0 through 3 = fault identifier, least significant byte first.

  • Page 243

    Event Codes Event Code: 421 Message: Firmware download complete. Severity: Informational. Explanation: A switch firmware version was downloaded from the HAFM Server or embedded web server. The event data indicates the firmware version in hexadecimal format xx.yy.zz bbbb, where xx is the release level, yy is the maintenance level, zz is the interim release level, and bbbb is the build ID.

  • Page 244

    Event Codes Event Code: 423 Message: CTP firmware download initiated. Severity: Informational. Explanation: The HAFM server initiated download of a new firmware version to the switch. Action: No action required. Event Data: No supplementary data included with this event. Distribution: Switch HAFM Server Host...

  • Page 245

    Event Codes Event Code: 440 Message: Embedded port hardware failed. Severity: Major. Explanation: The embedded port hardware detected a fatal CTP error. Action: Replace the switch. Event Data: Byte 0 = CTP slot position (00). Byte 1 = engineering reason code Bytes 4 through 7 = elapsed millisecond tick count.

  • Page 246

    Event Codes Event Code: 442 Message: Embedded port anomaly detected. Severity: Informational. Explanation: The switch detected a deviation in the normal operating mode or status of the embedded port. Action: No action required. An additional event code is generated if this incident exceeds an error threshold or results in a port failure.

  • Page 247

    Event Codes Event Code: 445 Message: ASIC detected a system anomaly. Severity: Informational. Explanation: The application-specific integrated chip (ASIC) detected a deviation in the normal operating mode or operating status of the switch. Action: No action required. An additional event code is generated if this incident exceeds an error threshold that results in a system event.

  • Page 248

    Event Code: 453 Message: New feature key installed. Severity: Informational. Explanation: This event occurs when a new feature key is installed from the HAFM server or EWS interface. The switch performs an IPL when the feature key is enabled. Event data indicates which feature or features are installed.

  • Page 249

    A Fibre channel port failed. The amber LED corresponding to the port illuminates to indicate the failure. Other ports remain operational if their LEDs are extinguished. Action: Perform the data collection procedure and return the Zip disk to Hewlett-Packard support personnel. Perform a switch reset. If the problem persists, replace the switch.

  • Page 250

    Event Codes Event Code: 507 Message: Loopback diagnostics port failure. Severity: Informational. Explanation: A loopback diagnostic test detected a Fibre Channel port failure. Action: No action required. An event code 506 is generated if this diagnostic failure results in a hard port failure.

  • Page 251

    Event Codes Event Code: 508 Message: Fibre Channel port anomaly detected. Severity: Informational. Explanation: The CTP detected a deviation in the normal operating mode or status of the indicated Fibre Channel port. Action: No action required. An event code 506 is generated if this anomaly results in a hard port failure.

  • Page 252

    Event Codes Event Code: 510 Message: SFP optical transceiver hot-insertion initiated. Severity: Informational. Explanation: Installation of a small form factor pluggable (SFP) optical transceiver was initiated with the switch powered on and operational. The event indicates that operational firmware detected the presence of the transceiver. Action: No action required.

  • Page 253

    Event Codes Event Code: 513 Message: SFP optical transceiver hot-removal completed. Severity: Informational. Explanation: A SFP optical transceiver was removed while the switch was powered on and operational. Action: No action required. Event Data: Byte 0 = port number (00 through 23). Bytes 4 through 7 = elapsed millisecond tick count.

  • Page 254

    Event Codes Event Code: 523 Message: FL_Port open request failed. Severity: Informational. Explanation: When the indicated FL_Port attempted to open a loop device, the port open (OPN) sequence was returned. Action: No action required. Event Data: Byte 0 = port number (00 through 23). Byte 1 = arbitrated loop physical address (AL_PA) of the device transmitting the OPN sequence.

  • Page 255

    Event Codes Event Code: 525 Message: FL_Port arbitration timeout. Severity: Informational. Explanation: A switch port could not win loop arbitration within the specified loop protocol time out value (LP_TOV). Action: Switch firmware reinitializes the arbitrated loop. No user action required. Event Data: Byte 0 = port number (00 through 23).

  • Page 256

    Event Codes Event Code: 582 Message: Bit error threshold exceeded. Severity: Major. Explanation: An attached OSI server determined the number of code violation errors recognized exceeded the bit error threshold. Action: A LIR is generated and sent to the attached server using the reporting procedure defined in T11/99-017v0 (OSI).

  • Page 257

    Event Codes Event Code: 584 Message: Not operational primitive sequence received. Severity: Major. Explanation: An attached OSI server received a not-operational primitive sequence (NOS). Action: A LIR is generated and sent to the attached server using the reporting procedure defined in T11/99-017v0 (OSI). If fault isolation at the server does not detect a failure, the problem may be due to a port failure.

  • Page 258

    Event Codes Event Code: 586 Message: Invalid primitive sequence received for current link state. Severity: Major. Explanation: An attached OSI server recognized either a link reset (LR) or a link-reset response (LRR) sequence while in the wait-for-online sequence (OLS) state. Action: A LIR is generated and sent to the attached server using the reporting procedure defined in T11/99-017v0 (OSI).

  • Page 259

    The thermal sensor associated with a CTP card indicates the warm temperature threshold was reached or exceeded. Action: Replace the failed switch. Perform the data collection procedure and return the Zip disk and faulty switch to Hewlett-Packard support personnel. Event Data: No supplementary data included with this event. Distribution:...

  • Page 261

    Glossary This glossary defines terms used in this manual or related to this product and is not a comprehensive glossary of computer terms. NUMERICS 8B/10B A data encoding scheme developed by IBM, translating byte-wide data to an encoded 10-bit format. 10BaseT An implementation of the Institute of Electrical and Electronics Engineers (IEEE) Ethernet standard on 24-gauge unshielded twisted-pair wiring, a baseband medium at 10 Mbps.

  • Page 262

    Glossary access time The amount of time, including seek time, latency, and controller time, necessary for a storage device to retrieve information. active configuration In S/390 mode, the Director or Edge Switch configuration that is determined by the status of the connectivity attributes.

  • Page 263

    Glossary allowed connection In S/390 mode, in a Director or Edge Switch, the attribute that when set, establishes dynamic connectivity capability. Contrast with blocked connection. See connectivity attribute. See also dynamic connectivity; unblocked connection. allowed port connection In S/390 mode, this attribute establishes dynamic connectivity capability. alternating current AC.

  • Page 264

    Glossary application-specific integrated circuit ASIC. An asynchronous transfer mode (ATM) local area network/ wide area network (LAN/WAN) circuit using cell relay transport technology. ASICs are designed for a specific application or purpose, such as implementing the lower-layer Fibre Channel protocol (FC-0). They are particularly suited to sending video and audio information, as well as text.

  • Page 265

    Glossary See bit. See byte. backbone Cable on which two or more stations or networks may be attached, typically used to link computer networks at one site with those at another. Smaller branch networks are sometimes called ribs. backplane The backplane provides direct current (DC) power distribution and connections for all logic cards.

  • Page 266

    Glossary bezel A removable panel that covers empty drive bays and port cards. bidirectional In Fibre Channel protocol, the capability to simultaneously communicate at maximum speeds in both directions over a link. Abbreviated as b. (1) Binary digit, the smallest unit of data in computing, with a value of zero or one (D).

  • Page 267

    Glossary Bytes per second. bridge (1) An attaching device that connects two local area network (LAN) segments to allow the transfer of information from one LAN segment to the other. A bridge can connect the LAN segments directly by network adapters and software in a single device, or can connect network adapters in two devices through software and use of a telecommunication link between the two adapters.

  • Page 268

    Glossary buffer-to-buffer credit BB_Credit. (1) The maximum number of receive buffers allocated to a transmitting node port (N_Port) or fabric port (F_Port). Credit represents the maximum number of outstanding frames that can be transmitted by that N_Port or F_Port without causing a buffer overrun condition at the receiver.

  • Page 269

    Glossary channel (1) A system element that controls one channel path, and whose mode of operation depends on the type of hardware attached. Each channel controls an I/O interface between the channel control element and the attached control units (D). (2) Point-to-point link that transports data from one point to the other.

  • Page 270

    Glossary community name (SNMP) A name that represents an simple network management protocol (SNMP) community that the agent software recognizes as a valid source for SNMP requests. A product recognizes a management station as a valid recipient for trap information when the station’s community names are configured.

  • Page 271

    Glossary connectivity attribute In S/390 mode, the characteristic that determines port address status for the Director or Edge Switch. See allowed connection; blocked connection; connectivity capability; connectivity control; dynamic connection; dynamic connectivity; unblocked connection. connectivity capability (1) The capability that allows attachment of a device to a system without requiring physical reconfiguration of either the device or the interconnections.

  • Page 272

    Glossary database A collection of data with a given structure for accepting, storing, and providing on-demand data for multiple users. (T) data directory Critical information for all managed products (including Directors and Edge Switches). Information stored here includes: • All configuration data •...

  • Page 273

    Glossary device (1) Mechanical, electrical, or electronic hardware with a specific purpose (D). See also managed product. (2) See node. diagnostics (1) The process of investigating the cause or nature of a problem in a product or system. (2) Procedures or tests used by computer users and service personnel to diagnose hardware or software problems (D).

  • Page 274

    Glossary domain ID Domain identifier. A number that uniquely identifies a switch in a multiswitch fabric. A distinct domain ID is automatically allocated to each switch in the fabric by the principal switch. The preferred domain ID is the domain ID value that a switch requests from the principal switch.

  • Page 275

    Glossary enhanced availability feature. electronic data interchange. E_D_TOV error-detect time-out value. EE-PROM electronically erasable programmable read-only memory. Electronic Industries Association. electromagnetic interference EMI. Undesirable electromagnetic emissions generated by solar activity, lightning, and electronic devices. The emissions interfere with or degrade the performance of another electronic device (D).

  • Page 276

    Glossary embedded web server interface The interface provides a graphical user interface (GUI) similar to the Product Manager application, and supports Director or Edge Switch configuration, statistics monitoring, and basic operations. With Director or Edge Switch firmware installed, administrators or operators with a browser-capable personal computer (PC) and an Internet connection can monitor and manage the Director or Edge Switch through an embedded web server interface.

  • Page 277

    Glossary Ethernet A widely implemented local area network (LAN) protocol that uses a bus or star topology and serves as the basis for the Institute of Electrical and Electronics Engineers (IEEE) 802.3 standard, which specifies the physical and software layers. Ethernet hub A device used to connect the HAFM server and the directors it manages.

  • Page 278

    Glossary fabric Entity that interconnects node ports (N_Ports) and is capable of routing (switching) Fibre Channel frames, using the destination ID information in the Fibre Channel frame header accompanying the frames. A switch is the smallest entity that can function as a complete switched fabric topology.

  • Page 279

    Glossary FC-0 The Fibre Channel layer that describes the physical link between two ports, including the transmission media, transmitter and receiver circuitry, and interfaces (D). This consists of a pair of either optical fiber or electrical cables (link media) along with transceiver circuitry which work together to convert a stream of bits at one end of the link to a stream of bits at the other end.

  • Page 280

    A unique key to enable additional product features. This key is entered into the Configure Feature Key dialog box in the Product Manager application to activate optional hardware and software features. Upon purchasing a new feature, Hewlett-Packard will provide the feature key to the customer.

  • Page 281

    Glossary Fibre Channel Association FCA. The FCA is a non-profit corporation consisting of over 150 members throughout the world. Its mission is to nurture and help develop the broadest market for Fibre Channel products through market development, education, standards monitoring, and fostering interoperability among members’...

  • Page 282

    Glossary Fibre Connection FICON. An IBM set of products and services introduced in 1999 that is based on the Fibre Channel Standard. FICON technology uses fiber-optic cables as the data transmission medium, and significantly improves I/O performance (including one Gbps bi-directional data transfer).

  • Page 283

    Glossary F_Port fabric port. frame A variable-length packet of data that is transmitted in frame relay technology. field-replaceable unit. file transfer protocol. full-duplex The capability to transmit in two directions simultaneously. gateway address (1) In transmission control protocol/Internet protocol (TCP/IP), a device that connects two systems that use the same or different protocols.

  • Page 284

    Glossary gigabyte GB. A unit of measure for data storage, equal to 1,073,741,824 bytes. Generally approximated as one billion bytes (D). gigahertz GHz. One billion cycles per second (Hertz) (D). G_Port generic port. graphical user interface GUI. A visually oriented interface where the user interacts with representations of real-world objects displayed on the computer screen.

  • Page 285

    Glossary HAFM application HP StorageWorks HA-Fabric Manager (HAFM) application. (1) Software application that is the system management framework providing the user interface for managing Fibre Channel connectivity products. (2) The software application that implements the management user interface for all managed hardware products. The HAFM application can run both locally on the HAFM server and remotely on a user workstation.

  • Page 286

    Glossary heterogeneous fabric A fabric containing open-fabric-compliant products from various vendors. Contrast with homogeneous fabric. hexadecimal A numbering system with base of sixteen; valid numbers use the digits 0 through 9 and characters A through F, where A represents 10 and F represents 15 (D). high availability A performance feature characterized by hardware component redundancy and concurrent maintenance.

  • Page 287

    Glossary (1) In Fibre Channel protocol, a device that connects nodes into a logical loop by using a physical star topology. (2) In Ethernet, a device used to connect the HAFM server and the directors it manages. hyperlink A predefined link for jumping from one location to another, within the same computer or network site or even to a location at a completely different physical location.

  • Page 288

    Glossary initial program load IPL. The process of initializing the device and causing the operating system to start. An IPL may be initiated through a menu option or a hardware button. initial program load configuration IPL configuration. In S/390 mode, information stored in a Director or Edge Switch’s nonvolatile memory that contains default configurations.

  • Page 289

    Glossary interswitch link ISL. Physical expansion port (E_Port) connection between two directors in a fabric. interswitch link hop ISL hop. See hop. IOPS Input/output operations per second. Internet protocol. IP address Internet protocol address. initial program load. IPL configuration initial program load configuration.

  • Page 290

    Glossary jumper cable Optical cable that provides physical attachment between two devices or between a device and a distribution panel. Contrast with trunk cable. See also optical cable. See kilobit. See kilobyte. kilobit Kb. A unit of measure for data storage, equaling 1,024 bits, or two to the tenth power. Kilobits are generally approximated as being one thousand bits.

  • Page 291

    Ability to evenly distribute traffic over multiple interswitch links within a fabric. Load balancing on Hewlett-Packard Directors and Edge Switches takes place automatically. loader/monitor area LMA. Code that resides in the loader/monitor area of the control processor (CTP) card.

  • Page 292

    Glossary logical port address In a Director or Edge Switch, the address used to specify port connectivity parameters and to assign link addresses for the attached channels and control units. logical switch number LSN. A two-digit number used by the I/O configuration program (IOCP) to identify a Director or Edge Switch (D).

  • Page 293

    Code for Information Interchange (ASCII) terminal emulator can be attached or dial-up connection made for specialized maintenance support. managed product Hardware product that can be managed with the HAFM application. Hewlett-Packard Directors and Edge Switches are managed products. See also device. management information base MIB.

  • Page 294

    Glossary MBps Megabytes per second. media access control address MAC address. Hardware address of a node (device) connected to a network. megabyte MB. A unit of measure for data storage, equal to 1,048,576 bytes. Generally approximated as one million bytes. memory A device or storage system capable of storing and retrieving data.

  • Page 295

    Glossary multiswitch fabric Fibre Channel fabric created by linking more than one director or fabric switching device within a fabric. name server (1) In TCP/IP, see domain name server. (2) In Fibre Channel protocol, a server that allows node ports (N_Ports) to register information about themselves. This information allows N_Ports to discover and learn about each other by sending queries to the name server.

  • Page 296

    Glossary network management The broad subject of managing computer networks. There exists a wide variety of software and hardware products that help network system administrators manage a network. Network management covers a wide area, including security, performance, and reliability. never principal The setting that prevents the product from becoming the principal switch for a fabric.

  • Page 297

    Glossary octet An 8-bit quantity, often called a byte or word. An octet can equal a byte as long as the byte equals eight bits. See also byte. original equipment manufacturer. offline Referring to data stored on a medium, such as tape or even paper, that is not available immediately to the user.

  • Page 298

    Product Manager application. When enabled, host control and management of the Director or Edge Switch are provided through an Open System Interconnection (OSI) device attached to a Director or Edge Switch port. open systems mode The mode that is used for Hewlett-Packard or open fabrics. See also operating mode; S/390 mode.

  • Page 299

    Glossary ordered set In Fibre Channel protocol, four 10-bit characters (a combination of data and special characters) providing low-level link functions, such as frame demarcation and signaling between two ends of a link. It provides for initialization of the link after power-on and for some basic recovery functions.

  • Page 300

    Glossary persistent binding A form of server-level access control that uses configuration information to bind a server to a specific Fibre Channel storage volume (or logical device), using a unit number. See also access control. personal computer PC. A portable computer that consists of a system unit, display, keyboard, mouse, one or more diskette drives, and internal fixed-disk storage (D).

  • Page 301

    Glossary principal switch In a multiswitch fabric, the switch that allocates domain IDs to itself and to all other switches in the fabric. There is always one principal switch in a fabric. If a switch is not connected to any other switches, it acts as its own principal switch. printed wiring assembly PWA.

  • Page 302

    Glossary protective plug In a fiber-optic environment, a type of duplex connector (or cover) that provides physical protection (D). Contrast with loopback plug. protocol (1) Set of semantic and syntactic rules that determines the behavior of functional units in achieving communication. (2) In systems network architecture, the meanings of and sequencing rules for requests and responses for managing the network, transferring data, and synchronizing network component states.

  • Page 303

    Glossary read-only memory ROM. An information storage chip with permanent memory. Stored information cannot be changed or deleted except under special circumstances (D). Contrast with random access memory. redundancy Performance characteristic of a system or product whose integral components are backed up by identical components to which operations will automatically failover in the event of a component failure.

  • Page 304

    Glossary S/390 mode The mode that is most useful when attaching to IBM S/390 Enterprise Servers. See also open systems mode; operating mode. SA/MVS™ System Automation for Operating System/390. storage area network; system area network. SA OS/390™ System Automation for Operating System/390.

  • Page 305

    Glossary SFP transceivers small form factor pluggable transceivers. shortwave Lasers or light-emitting diodes (LEDs) that emit light with wavelengths around 780 nm or 850 nm. When using multimode fiber (50 nm) shortwave lasers can be used with Fibre Channel links less than 500 m. To achieve longer lengths, single-mode fiber is required. The preferred fiber core size is 50 micron as this fiber has large bandwidth so that the distance is limited by the fiber attenuation.

  • Page 306

    Glossary singlemode optical fiber An optical fiber that allows one wavelength-dependent mode (light path) to propagate. Contrast with multimode optical fiber. small computer system interface SCSI. An interface standard that enables computers to communicate with peripherals connected to them. Commonly used in enterprise computing and in Apple Macintosh systems. Usually pronounced as “scuzzy.”...

  • Page 307

    Glossary static random access memory SRAM. SRAM is microprocessor-cache random access memory. It is built internal to the microprocessor or on external chips. SRAM is fast, but relatively expensive (D). Contrast with dynamic random access memory. storage area network SAN. A high-performance data communications environment that interconnects computing and storage resources so that the resources can be effectively shared and consolidated.

  • Page 308

    Glossary System Automation for Operating System/390 SA OS/390™. IBM licensed software that provides System/390 Parallel Sysplex™ management, automation capabilities, and integrated systems and network management. SA OS/390 manages host, remote processor, and I/O operations. SA OS/390 integrates the functions of Automated Operations Control for Multiple Virtual Storage (MVS™), ESCON™ Manager, and Target System Control Facility (D).

  • Page 309

    Glossary terabyte TB. One thousand (1,000) gigabytes; one terabyte of text on paper would consume 42,500 trees. At 12 characters per inch, 1 TB of data in a straight line would encircle the earth 56 times and stretch some 1.4 million miles equalling nearly three round trips from the earth to the moon.

  • Page 310

    Glossary trap host Simple network management protocol (SNMP) management workstation that is configured to receive traps. trap recipient In simple network management protocol (SNMP), a network management station that receives messages through SNMP for specific events that occur on the arbitrated loop device. trunk cable Cable consisting of multiple fiber pairs that do not directly attach to an active device.

  • Page 311

    Glossary UNIX A popular multi-user, multitasking operating system originally designed to be a small, flexible system used exclusively by programmers. UNIX was one of the first operating systems to be written in a high-level programming language, namely C. This meant that it could be installed on virtually any computer for which a C compiler existed.

  • Page 312

    Glossary virtual storage VS. (1) Storage space that may be regarded as addressable main storage by the user of a computer system in which virtual addresses are mapped to real addresses. The size of virtual storage is limited by the addressing scheme of the computer system and by the amount of auxiliary storage available, not by the number of main storage locations.

  • Page 313

    Glossary wrap plug Synonym for loopback plug. wrap test A test that checks attachment or control unit circuitry, without checking the mechanism itself, by returning the output of the mechanism as input. A wrap test can transmit a specific character pattern through a system and compare the pattern received with the pattern transmitted (D).

  • Page 315

    Index Ethernet hub fault isolation 2–44 audit logs 3–7 event codes CTP card events B–27 bandwidth of ports 1–1 description B–1 blocking a port 3–25 fan module events B–21 power supply events B–18 system events B–3 configuration data thermal events B–45 backing up 3–38 event log 3–7 managing 3–38...

  • Page 316

    Index fiber-optic interswitch link cleaning kit 1–5 description 1–1 components, cleaning 3–27 fault isolation 2–79 protective plug 1–4 IP address wrap plug 1–4 default 2–1 3–2 field replaceable units See FRUs laser transceiver firmware removal 4–2 adding a version 3–33 replacement 4–3 determining version 3–32 LEDs...

  • Page 317

    Index MAP 0600 - Port failure and link incident preventive maintenance, cleaning fiber-optic analysis 2–64 components 3–27 MAP 0700 - Fabric, ISL, and segmented port Product Manager problem determination 2–79 Hardware View 3–15 MAP 0800 - Console PC problem messages A–23 determination 2–91 Performance View 3–17 See MAPs...

  • Page 318

    Index hardware log 3–8 link incident log 3–9 3–11 unblocking a port 3–26 MAPs 2–1 power off procedure 3–29 verify setting offline 3–23 power supply replacement 4–8 setting online 3–23 SFP transceiver replacement 4–4 tools supplied 1–4 views system events Hardware 3–15 event codes tables B–3 Performance 3–17...

  • Page 319

    Figures 1–1 Edge Switch 2/24 (front view) ........1–2 1–2 Multi-mode and Single-mode Loopback Plugs .

  • Page 320

    3–18 Firmware Library dialog box........3–32 3–19 Firmware Library dialog box.

  • Page 321

    Tables 2–1 Factory-Set Defaults ..........2–1 2–2 MAP Summary .

Comments to this Manuals

Symbols: 0
Latest comments:
