Cable Connections
Figure 136. Connections Near Power Supply Box and PCI Card Divider
Note: The figure above shows the system with the power supply box removed.
A.
168
A.
SATA cable clip
B.
IDE cable clip
C.
SATA 4-7 connector, on installed
add-in card
SATA 0 - 3 connector on hard drive
backplane
Figure 137. SATA Connections on Hard Drive Backplane
B
A
C
D
E
D.
SATA 0 - 3 on-board connector
E.
IDE connector
A B
AF001435
B.
SATA 4 - 7 connector on hard drive
backplane
®
