Removing a Fan

To perform this procedure, you will first need to remove the top cover. The steps below
will direct you to the instructions to remove the top cover at the appropriate location in the
step sequence.
Caution: Before performing the procedures in this chapter, except for when hot-swapping, turn off
the system and disconnect all power plugs.
1. Remove the top cover. For instructions, see
2. Locate the fan area in the system. See the following figure.
3. Insert your thumb and a finger into the rounded and square holes at the top of the
fan.
4. Lift the fan from the system.
®
Intel Server System SR9000MK4U Product Guide
"Removing the Top Cover" on page

Figure 47. Locating the Fans

Figure 48. Removing a Fan

AF001133
AF001135
36.
57
