Clearing The Cmos; Upgrading The Firmware - Intel SR9000MK4U - Server System - 0 MB RAM Product Manual

8. After the format has completed, press the <Esc> key several times, until you see the
following screen.
LSI Logic MPT Setup Utility
Are you sure you want to exit?
Esc = Exit Menu
9. Select Exit the Configuration Utility and Restart and press the <Enter> key to
exit from the utility.

Clearing the CMOS

To clear the CMOS, use the following steps:
1. Turn off the system.
2. Leave the power cord(s) connected.
3. Hold down the reset button until the system LED begins to flash.
4. Power on the system.

Upgrading the Firmware

The FWUPDATE utility updates the SAL/BMC and writes sensor data records to the
®
Intel Server System SR9000MK4U. A FWUPDATE is performed as an EFI shell
command.
140
Cancel Exit
Save changes and restart.
Discard changes and restart.
Exit the Configuration Utility and Restart
F1/Shift+1 = Help
2.00.06.00
®
Intel Server System SR9000MK4U Product Guide
