Removing a Memory Box

To perform this procedure, you will first need to remove the front bezel. The steps below
will direct you to the instructions on removing the front bezel at the appropriate location
in the step sequence.
Caution: Before performing the procedures in this chapter, except for when hot-swapping, turn off
the system and disconnect all power plugs.
1. Remove the front bezel. For instructions, see
page
2. Push down on the memory box release lever to unlock the memory box. See letter
"A" in the figure below.
3. Fully open the metal cover on the memory box. See letter "B" in the figure.
4. Carefully pull the memory box from the system and place it on a clean, static-free
surface.
5. Determine your next course of action and refer to the appropriate steps:
— If you are following these steps as part of another procedure, return to that
— If a memory box will not be re-installed, slide a memory box filler panel into the
6. Install the front bezel. For instructions, see
®
Intel Server System SR9000MK4U Product Guide
34.

Figure 34. Removing the Memory Box

procedure.
open memory box slot until it clicks into place.
"Removing the Front Bezel" on
B
A
AF001120
"Installing the Front Bezel" on page 35.
45
