Summary of Contents for Intel SR1325TP1 - Entry Server Platform
-
Page 1: User Guide
® Intel Entry Server Platform SR1325TP1-E User Guide ® A Guide for Technically Qualified Assemblers of Intel Identified Subassemblies/Products Order Number: C61602-001... - Page 2 Intel’s own chassis are designed and tested to meet the intended thermal requirements of these components when the fully integrated system is used together. It is the responsibility of the system integrator that chooses not to use Intel developed server building blocks to consult vendor datasheets and operating parameters to determine the amount of airflow required for their specific application and environmental conditions.
-
Page 3: About This Manual
This document provides a brief overview of the features of the board/chassis, a list of accessories or other components you may need, troubleshooting information, and instructions on how to add and replace components on the Intel Entry Server Platform SR1325TP1-E. For the latest version of this manual, refer to http://www.support.intel.com/support/motherboards/server/SR1325TP1-E. -
Page 4: Product Accessories
Power cord (If not included with the platform. This product ships with a power cord in North America only.) For information about which accessories, memory, processors, and third-party hardware have been tested and can be used with your board, and for ordering information for Intel products, see http://support.intel.com/support/motherboards/server/SR1325TP1-E/compat.htm. -
Page 5: Additional Information And Software
Processors that have been tested with this product DIMMs that have been tested with this product The power budget for this product Software to manage your Intel Server Platform Diagnostics testing software Firmware and BIOS updates System drivers... -
Page 6: Warnings
Preface Warnings System power on/off: The power button DOES NOT turn off the system AC power. To remove power from system, you must unplug the AC power cord from the wall outlet. Make sure the AC power cord is unplugged before you open the chassis, add, or remove any components. - Page 7 Preface Safety Cautions Read all caution and safety statements in this document before performing any of the instructions. See also Intel Server Boards and Server Chassis Safety Information on the Resource CD and/or at http://www.support.intel.com/support/motherboards/server. Wichtige Sicherheitshinweise Lesen Sie zunächst sämtliche Warn- und Sicherheitshinweise in diesem Dokument, bevor Sie eine der Anweisungen ausführen.
- Page 8 Preface viii...
-
Page 9: Table Of Contents
Contents Contents Preface .........................iii Warnings ......................vi 1 Server Platform Features................15 Server Board Connector and Component Locations ............16 Configuration Jumpers ......................17 Server Board Back Panel Connectors .................. 18 Server Chassis Components ....................19 Server Chassis Front Panel ....................20 Server Chassis Back Panel.................... - Page 10 Devices are not Recognized under Device Manager (Windows* Operating System).. 71 Hard Drive(s) are not Recognized................71 Bootable CD-ROM Is Not Detected................71 LED Information ......................72 BIOS Error Messages ......................73 BIOS POST Beep Codes ..................... 74 ® Intel Entry Server Platform SR1325TP1-E User Guide...
- Page 11 ® Intel Server Issue Report Form............... 83 Warranty......................87 Limited Warranty for Intel ® Chassis Subassembly Products..........87 Extent of Limited Warranty....................87 Warranty Limitations and Exclusions ..................88 Limitations of Liability ....................88 How to Obtain Warranty Service................... 89 Telephone Support.......................
- Page 12 Contents Figures Figure 1. Intel Server Board SE7210TP1-E Diagram ............16 Figure 2. Configuration Jumper Location ................17 Figure 3. Back Panel Connectors ..................18 Figure 4. System Components..................... 19 Figure 5. Chassis Front......................20 Figure 6. Chassis Back ......................21 Figure 7.
- Page 13 Contents Tables Table 1. Server Board Features ..................15 Table 2. Configuration Jumper [J1D1]................17 Table 3. NIC LEDs......................18 Table 4. Control Button Functions .................. 20 Table 5. LED Indicator Status..................20 Table 6. Keyboard Commands..................57 Table 7. BIOS Error Messages..................
- Page 14 Contents ® Intel Entry Server Platform SR1325TP1-E User Guide...
-
Page 15: Server Platform Features
Table 1. Server Board Features Feature Description Support for an Intel ® Pentium ® 4 processor in an mPGA478 package with an Processors 800/533/400 MHz system bus Memory Four 184-pin DDR SDRAM Dual Inline Memory Module (DIMM) sockets Support for up to 4 GB Unbuffered ECC system memory... -
Page 16: Server Board Connector And Component Locations
Support for SMBIOS Power Management Support for ACPI: Suspend to RAM (STR) Wake on USB, PCI, RS-232, PS/2, LAN, and front panel Intel® Server Management 5.8 support via mini Baseboard Management Server Management Controller (mBMC) Server Board Connector and Component Locations TP00628 A. -
Page 17: Configuration Jumpers
Server Platform Features Configuration Jumpers J1D1 TP00630 Figure 2. Configuration Jumper Location Table 2. Configuration Jumper [J1D1] Jumper Name Pins What happens at system reset… CMOS clear If these pins are jumpered, the CMOS settings will be cleared on the next reset. -
Page 18: Server Board Back Panel Connectors
Solid Amber Network connection in place Blinking Amber Transmit/receive activity 10 Mbps connection (if left LED is on or blinking) Right LED Solid Amber 100 Mbps connection Solid Green 1000 Mbps connection ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 19: Server Chassis Components
Server Platform Features Server Chassis Components TP00578 A. Hard Disk Drive 1 (drive purchased separately) F. Front Fan Module B. Hard Disk Drive 2 (drive purchased separately) G. Power Supply C. Floppy / CD-ROM / DVD-ROM Drive Module H. Power Supply Fans (drive(s) purchased separately) D. -
Page 20: Server Chassis Front Panel
In order for a hard disk fault indication to occur, an Intelligent Platform Management Interface (IPMI)–based satellite management controller must send a Set Fault Indication command to the mini Baseboard Management Controller (mBMC). Off when the system is powered off or in a sleep state. ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 21: Server Chassis Back Panel
Server Platform Features Server Chassis Back Panel TP00577 A. AC Power Xonnector F. Video Connector B. USB Ports 1, 2, 3 G. NIC1 Connecgtor (1 Gbit) C. Keyboard Connector H. NIC2 Connector (10/100 Mbit) D. Mouse Connector I. PCI Card Bracket (full height) E. -
Page 22: Hard Disk Drives
For information on how to install these drives, see “Installing or Removing a Hard Drive”. NOTE The Intel Entry Server Platform SR1325TP1-E does not support all SCSI, ATA, or Serial ATA hard drives. For a list of validated hard drive manufacturers and hard drive types, see http://support.intel.com/support/motherboards/server/SR1325TP1-E Drives can consume up to 17 watts of power each. -
Page 23: System Cooling
For a list of qualified components see the links under “Additional Information and Software.” Processor One 2.0 GHz Intel Pentium 4 processor with 512KB cache support is required. For a complete list of supported processors, see the links under “Additional Information and Software.” Memory A minimum of one 128 MB Unbuffered, ECC or non-ECC, DDR266-, DDR333- or DDR400- compliant, 184-pin DIMMs. - Page 24 DIMMs may not function under the determined frequency. For ECC functionality, all installed DIMMs must be ECC. If both ECC and non-ECC DIMMs are used, ECC will be disabled and will not function. ® Intel Entry Server Platform SR1325TP1-E User Guide...
-
Page 25: Platform Installations And Upgrades
Antistatic wrist strap and conductive foam pad (recommended) System References All references to left, right, front, top, and bottom and are based on the reader facing the front of the chassis as it would be positioned for normal operation. ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 26: Removing And Installing The Chassis Cover
1. Remove the two acess screws from the top cover. 2. Slide the top cover back until it stops. 3. Lift the cover straight up to remove it from the chassis. TP00580 Figure 8. Removing the Cover ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 27: Installing The Chassis Cover
Platform Installations and Upgrades Installing the Chassis Cover 1. Place the cover over the chassis so that the side edges of the cover sit just inside the chassis sidewalls. Slide the cover toward the front of the chassis until it fits in place. 2. -
Page 28: Removing And Installing The Processor Air Duct
2. Disconnect the main power cable. See letter “B” in the figure below. 3. Lift the air duct from the server chassis. See letter “C” in the figure. TP00613 Figure 10. Removing Processor Air Duct ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 29: Installing The Processor Air Duct
Platform Installations and Upgrades Installing the Processor Air Duct 1. Place the processor air duct over the processor socket and DIMMs, using caution to make sure you do not pinch any wires beneath the air duct. The front edge of the air duct should contact the front fan module and the top of the installed air duct should be flush with the top surface of the power supply. -
Page 30: Installing And Removing Memory
8. Position the DIMM above the socket. Align the small notch in the bottom edge of the DIMM with the keys in the socket. See number 2 in Figure 12. 9. Insert the bottom edge of the DIMM into the socket. ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 31: Removing Dimms
Platform Installations and Upgrades 10. When the DIMM is inserted, push down on the top edge of the DIMM until the retaining clips snap into place. Make sure the clips are firmly in place. See number 3 in the figure above. 11. -
Page 32: Installing Or Replacing The Processor
4. Aligning the pins of the processor with the socket, insert the processor into the socket. See letter B in the figure below 5. Close the handle completely. See letter C. TP00519 Figure 14. Installing the Processor in the Processor Socket ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 33: Figure 15. Attaching The Heat Sink To The Processor
Platform Installations and Upgrades NOTE The bottom of the heat sink may have thermal interface material (TIM) already applied. Be careful not to damage the thermal interface material. 5. If there is no thermal interface material on the bottom of the heat sink, use the enclosed syringe and apply the thermal interface material to the top of the processor. -
Page 34: Figure 17. Attaching The Fan Heat Sink Clips To The Processor Socket
Figure 18. Connecting the Processor Fan Cable to the Processor Fan Connector 11. Install the processor air duct. The air duct must be in place for proper system cooling. For instructions on installing the processor air duct, see “Installing the Processor Air Duct.” ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 35: Removing The Processor
® The drive type allowed depends on the installed version of Intel Server Board SE7210TP1-E and the add-in components that you are installing. Drives installed into the Intel Entry Server Platform SR1325TP1-E are not hot-swappable. CAUTION The Intel Entry Server Platform SR1325TP1-E does not support all hard drives. -
Page 36: Figure 20. Attaching A Hard Disk Drive To A Bracket
6. Align the holes in the drive to the holes in the drive bracket and insert four screws from the fastener bag marked “A” to secure the drive to the bracket. The fastener bag was included with your server platform. TP00429 Figure 20. Attaching a Hard Disk Drive to a Bracket ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 37: Removing A Hard Drive
Platform Installations and Upgrades 7. Set the drive assembly on the bottom of the chassis, slightly behind the sheet metal tabs (Letter “A” in Figure 21), and slide the drive assembly forward to engage the tabs with the hard drive carrier. -
Page 38: Installing A Floppy / Cd-Rom And / Or Dvd-Rom Drive (Optional Accessory Kit)
AC power cord from the system or wall outlet. ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 39: Removing Drive Cage From Chassis
Platform Installations and Upgrades Removing Drive Cage from Chassis 1. Before removing the cover to work inside the system, observe the safety guidelines at the beginning of this document. 2. Remove the top cover from the chassis. 3. Remove the power and data cables from the rear of the floppy drive / CD-ROM / DVD-ROM drive backplane. -
Page 40: Removing Backplane Board And Cage Cover
Lift the brown locking mechanism at the front of the Flat Flex Cable (FFC) connector to disengage the FFC from the floppy drive. See letter “A” in Figure 24. Leave the FFC attached to the backplane board. ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 41: Reattaching Flat Flex Cable To Backplane Board
Platform Installations and Upgrades Reattaching Flat Flex Cable to Backplane Board The Flat Flex Cable (FFC) is used only when a floppy drive is installed into the slimline drive cage. Use these steps if your flat flex cable becomes loosened or disengaged from the backplane board. Attach the Flat Flex Cable to the backplane board before attaching the cable to the floppy drive. -
Page 42: Inserting Replacement Floppy Drive
6. Hold the backplane board with the attached FFC above the floppy drive. Hold the backplane board so that the silkscreen label “IDE CONN” is at the top left and the FFC is at the right. See Figure 26, B. ® Intel Entry Server Platform SR1325TP1-E User Guide... - Page 43 Platform Installations and Upgrades NOTE If the FFC is not attached to the backplane board, see “Reattaching Flat Flex Cable to Backplane Board” for instructions on reinstalling it. Install the FFC into the backplane board before attaching it to the floppy drive. 7.
-
Page 44: Inserting Replacement Cd-Rom / Dvd-Rom Drive
4. Use the four screws removed from the old drive to attach the replacement drive to each side of the cage (two screws on each side). TP00143D Figure 27. Installing Replacement CD-ROM or DVD-ROM Drive ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 45: Attach Backplane To Cage
Platform Installations and Upgrades Attach Backplane to Cage 1. If a floppy drive is installed, hold the backplane board so the silkscreen label “IDE CONN” is at the top left. If you are looking at the printed side of the FFC instead of the solid gray side of it, roll the bottom of the backplane board up and over until you are looking at the solid gray surface of the FFC. -
Page 46: Re-Insert Drive Cage Into Chassis
6. Install the new PCI add-in card on the riser. 7. Insert the riser card connector in the server board slot while aligning the tabs on the rear retention bracket with the holes in the chassis. ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 47: Figure 31. Replacing A Riser Card
Platform Installations and Upgrades CAUTION Press the riser card straight down into the slot. Press down on the riser card, not on the PCI card. Tipping it in the slot while installing it or pressing on the PCI card may damage the riser card, board slot, or the PCI card. 8. -
Page 48: Replacing The Power Supply
6. Slide the power supply slightly forward to disengage it from the tabs that attach it to the bottom of the chassis. See letter “C” in Figure 32. 7. Lift the power supply out of the chassis. TP00587 Figure 32. Removing the Power Supply ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 49: Figure 33. Installing The Power Supply
Platform Installations and Upgrades 8. Set the replacement power supply onto the chassis floor. 9. Connect the power connector at the rear of the power supply. See letter “C” in Figure 33. 10. Slide the power supply toward the rear of the chassis to engage the tab. See letter “B” in Figure 11. -
Page 50: Replacing The Front Fan Module
6. Remove the three screws that attach the front fan module to the chassis. 7. Lift the fan module from the chassis. See Figure 34. Figure 34. Removing the Front Fan Module ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 51: Figure 35. Routing The Front Fan Cables
Platform Installations and Upgrades 8. Install the replacement fan module into the chassis using the three screws that held the original fan module in place. 9. Reattach the chassis intrusion cable. 10. Reconnect the cable from each fan at the appropriate location on the server board. Fans are routed as shown in the figure below. -
Page 52: Replacing The Front Panel Board
5. Attach the replacement front panel board to the chassis with the two screws removed from the old front panel board. 6. Plug the cable from the server board back into the front panel board. 7. Replace the chassis cover. Figure 36. Replacing the Front Panel Board ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 53: Replacing The Backup Battery
Platform Installations and Upgrades Replacing the Backup Battery The lithium battery on the server board powers the RTC for up to 10 years in the absence of power. When the battery starts to weaken, it loses voltage, and the server settings stored in CMOS RAM in the RTC (for example, the date and time) may be wrong. -
Page 54: Installing Or Replacing The Power Cord
If you will be placing your server in a rack, wait to install the power cord until after the server is in the rack. Plug the power cord into the power supply. ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 55: Installing The Platform Into A Rack
Installation instructions for the standard bracket kit and the optional rail kit are included with each kit. These instructions can also be found at http://support.intel.com/support/motherboards/server/chassis/SR1300/: Intel® Server Chassis SR1200, SR1300, SR2200, and SR2300 Rail Kit Installation Guide Intel® Server Chassis SR1200, SR1300, SR2200, and SR2300 Bracket Kit Installation Guide NOTES Although these documents do not refer specifically to the Intel®... - Page 56 You may want to calculate the BTU/hr measurement more accurately for your configuration. An extra 500 BTU/hr over many systems would translate into a large error calculating air conditioning capacity. ® Intel Entry Server Platform SR1325TP1-E User Guide...
-
Page 57: Server Utilities
“No” is selected and the Enter key is pressed, or the ESC key is pressed, the user is returned to where they were before F10 was pressed without affecting any existing values. ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 58: Upgrading The Bios
BIOS upgrade. Review also any release notes in the release notes file that accompanies the new version of the BIOS. The release notes may contain critical information regarding jumper settings, specific fixes, or other information to complete the upgrade. ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 59: Upgrading The Bios
Server Utilities Creating a Bootable Diskette Use a DOS system to create the diskette as follows: 1. Insert a diskette in diskette drive A. 2. At the C:\ prompt, for an unformatted diskette, type: format a:/s or, for a diskette that is already formatted, type: sys a: 4. -
Page 60: Changing The Bios Language
You can use the BIOS upgrade utility to change the language the BIOS uses for messages and the Setup program. Use a bootable diskette containing the Intel flash utility and language files. 1. Boot the computer with the bootable diskette in drive A. The BIOS upgrade utility screen appears. -
Page 61: Recovering The Bios With The Crisis Recovery Diskette
Server Utilities Recovering the BIOS with the Crisis Recovery Diskette Manually Recovering the BIOS A BIOS recovery can be manually initiated. This option would be used only when the BIOS is corrupt, but the ROM checksum error does not occur during POST. To manually initiate a BIOS recovery, use the following steps: 1. -
Page 62: Clearing The Cmos
5. When the system begins beeping, power it down and disconnect the AC power. 6. Return the CMOS Clear jumper to the original location, covering pins 1 and 2. 7. Close the server chassis, reconnect the AC power and power up the system. ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 63: Troubleshooting
SCSI drivers. Intel provides a package called the “Platform Confidence Test” that may help with your diagnostics. See “Additional Information and... -
Page 64: Hardware Diagnostic Testing
5. If the power LED does light, attempt to boot from a floppy diskette or from a CD-ROM disk. 6. Turn on the system. If the power LED does not light, see “Power Light Does Not Light.” ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 65: Verifying Proper Operation Of Key System Lights
Troubleshooting Verifying Proper Operation of Key System Lights As POST determines the system configuration, it tests for the presence of each mass storage device installed in the system. As each device is checked, its activity light should turn on briefly. Check for the following: Does the diskette drive activity light turn on briefly? If not, see “Diskette Drive Activity Light... -
Page 66: Power Light Does Not Light
Remove the memory DIMMs and re-seat them. Make sure the processor(s) comply with the system requirements. Make sure the processor(s) have been populated according to the system requirements. Remove the processor(s) and re-seat them. ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 67: Characters Are Distorted Or Incorrect
Troubleshooting If you are using an add-in video controller board, do the following: 1. Verify that the video works using the onboard video controller. 2. Verify that the video controller board is fully seated in the server board connector. 3. Reboot the system for changes to take effect. 4. -
Page 68: Diskette Drive Activity Light Does Not Light
Make sure the correct networking software is installed. If you are directly connecting two servers (without a hub), you will need a crossover cable. Check the network controller LEDs next to the NIC connectors. ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 69: Problems With Network
Troubleshooting Problems with Network The server hangs when the drivers are loaded. Certain drivers may require interrupts that are not shared with other PCI drivers. For these drivers, it may be necessary to alter settings so that interrupts are not shared. See the documentation that came with your PCI card(s) for information on changing interrupts.. -
Page 70: Problems With Newly Installed Application Software
® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 71: Devices Are Not Recognized Under Device Manager (Windows* Operating System)
Troubleshooting Devices are not Recognized under Device Manager (Windows* Operating System) The Windows* operating systems do not include all of the drivers for the Intel® chipsets, onboard NICs, and other components. See “Additional Information and Software” for a link to the current drivers and chipset files. -
Page 72: Led Information
Troubleshooting LED Information ® The Intel Server Board SE7210TP1-E includes LEDs that can aid in troubleshooting your system. A table of these LEDs with a description of their use is listed below. LED Name Function Location Color Correction Aid in server... -
Page 73: Bios Error Messages
Troubleshooting BIOS Error Messages When a recoverable error occurs during the POST, the BIOS displays an error message describing the problem (see Table 7). Table 7. BIOS Error Messages Error Message Explanation GA20 Error An error occurred with Gate A20 when switching to protected mode during the memory test. -
Page 74: Bios Post Beep Codes
8042 GateA20 cannot be toggled (memory failure or not present) Exception interrupt error Display memory R/W error (Reserved; not used) CMOS Shutdown register test error Invalid BIOS (such as, POST module not found) ® Intel Entry Server Platform SR1325TP1-E User Guide... -
Page 75: Bios Recovery Beep Codes
In the case of a Bootblock update, where video is not available for text messages to be displayed, speaker beeps are necessary to inform the user of errors. For beep codes associated with a ® Bootblock update refer to the Intel Server Board SE7210TP1-E Technical Product Specification. - Page 76 Troubleshooting ® Intel Entry Server Platform SR1325TP1-E User Guide...
-
Page 77: Regulatory And Compliance Information
(EMC) regulations when installed a compatible Intel host system. For information on compatible host system(s) refer to Intel’s Server Builder Web site or contact your local Intel representative. FCC (Class A Verification) – Radiated & Conducted Emissions (USA) ICES-003 (Class A) –... -
Page 78: Product Regulatory Compliance Markings
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For questions related to the EMC performance of this product, contact: Intel Corporation 5200 N.E. Elam Young Parkway Hillsboro, OR 97124 1-800-628-8686 ®... -
Page 79: Industry Canada (Ices-003)
Regulatory and Compliance Information This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 80: Taiwan Declaration Of Conformity
MIC logo to illustrate compliance. The English translation for the above is as follows: 1. Type of Equipment (Model Name): SE7210TP1-E 2. Certification No.: Contact Intel Representative 3. Name of Certification Recipient: Intel 4. Date of Manufacturer: Marked on Product 5. -
Page 81: Getting Help
Telephone All calls are billed US $25.00 per incident, levied in local currency at the applicable credit card exchange rate plus applicable taxes. (Intel reserves the right to change the pricing for telephone support at any time without notice). Before calling, fill out an “Intel®... - Page 82 Getting Help ® Intel Entry Server Platform SR1325TP1-E User Guide...
-
Page 83: Intel Server Issue Report Form
Internet. Date Submitted: Company Name: Contact Name: Email Address: Intel Server Product: Priority (Critical, Hot, High, Low): Brief Problem Description. Provide a brief description below. See the last page for space to include a detailed problem description. - Page 84 Add-in Video On-Board NIC1 (1.0 Gb) On-Board NIC2 (10/100 Mb) Hard Drive Information: # of drives installed: Make/Model/Firmware Revision SCSI # of drives installed: Make/Model/Firmware Revision SATA # of drives installed: Make/Model/Firmware Revision ® Intel Entry Server Platform SR1325TP1-E User Guide...
-
Page 85: Complete Problem Description
In the space below, provide a complete description of the steps used to reproduce the problem or a complete description of where the problem can be found. Please also include any details on troubleshooting already done. ® Intel Entry Server Platform SR1325TP1-E User Guide... - Page 86 Server Issue Report Form ® Intel Entry Server Platform SR1325TP1-E User Guide...
-
Page 87: Warranty
Product or to refund the then-current value of the Product. In no event will Intel be liable for any other costs associated with the replacement or repair of Product, including labor, installation or other costs incurred by buyer and in particular, any costs relating to the removal or replacement of any product soldered or otherwise permanently affixed to any printed circuit board. -
Page 88: Warranty Limitations And Exclusions
Limitations of Liability Intel’s responsibility under this, or any other warranty, implied or expressed, is limited to repair, replacement, or refund, as set forth above. These remedies are the sole and exclusive remedies for any breach of warranty. -
Page 89: How To Obtain Warranty Service
Warranty How to Obtain Warranty Service To obtain warranty service for this Product, you may contact Intel or your authorized distributor. North America and Latin America To obtain warranty repair for the product, please go to the following Web site to obtain instructions: http://support.intel.com/support/motherboards/draform.htm... -
Page 90: Returning A Defective Product
Warranty Returning a Defective Product Before returning any product, call your authorized dealer/distribution authority. ® Intel Entry Server Platform SR1325TP1-E User Guide...
