3. Simultaneously push the two levers on the top of the power supply slightly outward
and then raise them to unlock the power supply. See letter "A" in the following
figure.
4. Use the handle on the power supply to lower it into the system. See letter "B" in the
figure.
Caution: Do not lift the power supply by the levers. Lift the power supply only by the handle.
®
Intel
Server System SR9000MK4U Product Guide
Figure 64. Removing a Power Supply Filler
A
Figure 65. Installing a Power Supply
AF001150
A
B
AF001152
A
B
69
