Chassis Component Identification
This section helps you identify the components of your server system. If you are near the
system, you can also use the Quick Reference Label provided on the inside of the chassis
cover to assist in identifying components.
Internal Components
C
B
A
A.
Rack handles (two)
B.
Front Control Panel
C.
Hot swap backplane
D.
System Fans (CPU fans and Memory fans) J.
E.
Air Duct
F.
PCI Express* add-in card bracket
8
E
D
K
Figure 3. System Components
Figure 2. Cable Routing
F
G
H
J
A
G.
PCI Express* x16 riser
H.
Mother board
I.
650W power supply unit
Optional slimline optical drive
K.
Hot swap HDD carrier
®
Intel
Server System SR1690WB Service Guide
I
AF003211
