JUNOSe 11.0.x IP, IPv6, and IGP Configuration Guide
4.
5.
6.

Configuring the Probe Type

To begin configuring RTR, enter RTR Configuration mode and configure the probe
type either an echo probe or a path echo probe.
rtr
type
66
Response Time Reporter
Schedule the probe.
(Optional) Capture statistics and collect error information.
(Optional) Collect history.
Use to configure an RTR probe and to enter RTR Configuration mode.
Example
host1(config)#rtr 1
Use the no version to delete all configuration information for an RTR probe.
See rtr
Use to set an echo or path echo probe:
echo Limited to end-to-end RTR operations; corresponds to SNMP ping
pathEcho Finds a path to the destination and echoes each device in the
path; corresponds to SNMP traceroute
You must specify this value before any other.
If you change the type for an existing RTR entry, all values are reset, including
the administrative status. There is no default value.
More than one RTR entry can become active, provided each entry's target address
is unique.
If you configure multiple RTR entries to use the same target address, you must
issue the receive-interface command to specify the interface on which the RTR
probe expects to receive responses. (For information, see "Setting the Receiving
Interface" on page 70.)
If you use a target address already configured for another RTR entry that is active,
the test will not run if both entries are in the same virtual router. If they are in
distinct virtual routers, however, there is no restriction.
Example
host1(config-rtr)#type echo protocol ipIcmpEcho 10.10.0.9
Use the no version to remove the type configured for the probe.
See type
