Juniper IGP - CONFIGURATION GUIDE V11.1.X Configuration Manual page 428

JUNOSe 11.0.x IP, IPv6, and IGP Configuration Guide
404
Monitoring IS-IS
Stop Accept Date and time that the router stops accepting packets
created with this password
Stop Generate Date and time that the router stops inserting this
password into packets
Domain Authentication Displays the following fields if domain
authentication is enabled:
PSNP/CSNP PDU authentication enabled Indicates whether
authentication of level 2 PSNP packets and/or level 1 CSNP packets has
been enabled by means of the domain-authentication command
Key-id Numeric identifier for the authentication key
Type Type of authentication: hmac-md5 or password; an asterisk after
the type indicates that the key is active
Start Accept Date and time that the router starts accepting packets
created with this password
Start Generate Date and time that the router starts inserting this
password into packets
Stop Accept Date and time that the router stops accepting packets
created with this password
Stop Generate Date and time that the router stops inserting this
password into packets
Use the es-neighbors keyword to display information for IS-IS end-system
adjacencies or the is-neighbors keyword to display information for IS-IS
intermediate-system adjacencies. Neighbor entries are sorted according to the
area in which they are located. The following fields are displayed when any of
these keywords is used:
System Id Six-byte value of router
Interface Interface on which the router was discovered
State Adjacency state, either Up or Init
Up Believes that the ES or IS is reachable
Init Router is an IS and is waiting for an IS-IS hello message. IS-IS
regards the neighbor as not adjacent.
Type Level 1, level 2, and level 1-2 type adjacencies
L1 Router adjacency for level 1 routing only
L1L2 Router adjacency for level 1 and level 2 routing
L2 Router adjacency for level 2 only
