Table 3: Routing Table for Router NY

Table 4: Routing Table for Router LA

Setting the Administrative Distance for a Route

The administrative distance is an integer that is associated with each route known
to a router. The distance represents how reliable the source of the route is considered
to be. A lower value is preferred over a higher value. An administrative distance of
255 indicates no confidence in the source; routes with this distance are not installed
in the routing table.
Table 5 on page 27 lists the default distance for each type of source from which a
route can be learned.

Table 5: Default Administrative Distances for Route Sources

Destination Next-Hop
Network Router
10.1.0.0/16 10.1.0.1
10.2.0.0/16 10.5.0.3
10.2.0.0/16 10.5.0.3
10.2.0.0/16 10.5.0.3
10.2.0.0/16 10.5.0.3
10.5.0.0/30 10.5.0.2
Destination Next-Hop
Network Router
10.1.0.0/16 10.5.0.2
10.1.0.0/16 10.5.0.2
10.1.0.0/16 10.5.0.2
10.2.0.0/16 10.2.0.1
10.5.0.0/30 10.5.0.3
Route Source
Connected interface
Static route
Route Administrative
Type Distance
connected 0
OSPF 110
IS-IS 115
EBGP 20
RIP 120
connected 0
Route Administrative
Type Distance
static 1
OSPF 110
RIP 120
connected 0
connected 0
Default Distance
0
1
Chapter 1: Configuring IP
Metric
0
10
10
15
5
0
Metric
0
10
4
0
0
27
IP Routing
