JUNOSe 11.0.x IP, IPv6, and IGP Configuration Guide
traceroute
64
Reachability Commands
I Information request message
i Information reply message
L TTL expired message
M Could not fragment, DF bit set
m Parameter problem message
N Network unreachable
P Protocol unreachable
Q Source quench
r Redirect message
T Timestamp request message
t Timestamp reply message
U Destination unreachable
Example
host1(config)#interface serial 5/2:1/1
host1(config-if)#ip address 172.16.1.1 255.255.255.0
host1(config-if)#exit
host1#ping 172.16.1.1 extended interface serial 5/2:1/1
There is no no version.
See ping
Use to discover the routes that router packets follow when traveling to their
destination.
You can specify:
A VRF context
Destination IP or IPv6 address
Source interface for each of the transmitted packets
Source address for each of the transmitted packets
Maximum number of hops of the trace and a timeout value
Size of the IP packets (not the ICMP payload) in the range 0–64000 bytes
sent with the traceroute command. Including a size might help locate any
MTU problems that exist between your router and a particular device.
Extended IP header attributes, including the ToS byte (IP only), whether to
set the DF bit for the transmitted packets (IP only), the traffic class (IPv6
only), and flow label (IPv6 only).
