98
Monitoring IP
router will send and receive version 2 only. The default is configured for
RIP1.
Update interval Current setting of the update timer (in seconds)
Invalid after Current setting of the invalid timer (in seconds)
hold down time Current setting of the hold down timer (in seconds)
flushed interval Current setting of the flush timer (in seconds)
Filter applied to outgoing route update Access list applied to outgoing
RIP route updates
Filter applied to incoming route update Access list applied to incoming
RIP route updates
Global route map Route map that specifies all RIP interfaces on the
router
Distance Value added to RIP routes added to the IP routing table; the
default is 120.
Interface Interface type on which RIP protocol is running
Redistributing Protocol to which RIP is redistributing routes
Routing for Networks Network for which RIP is currently injecting
routes
Example
host1#show ip protocols
Routing Protocol is
Redistributing: ospf
Default local preference is 100
IGP synchronization is enabled
Always compare MED is disabled
Router flap damping is disabled
Administrative Distance: external 20 internal 200 local 200
Neighbor(s):
Address 1.1.1.1
Outgoing update distribute list is 2
Outgoing update prefix list is efg
Incoming update prefix tree is abc
Incoming update filter list is 1
Routing for Networks:
192.168.1.0/24
Routing Protocol is
System Id: 0000.0000.0011.00
Distance: 115
Address Summarization:
None
Routing for Networks:
fastEthernet0/0
Routing Protocol is
Distance is 110
bgp 100"
isis isisOne"
IS-Type: level-1-2
ospf 1" with Router ID 192.168.1.151
