Juniper IGP - CONFIGURATION GUIDE V11.1.X Configuration Manual page 432

JUNOSe 11.0.x IP, IPv6, and IGP Configuration Guide
show clns neighbors
408
Monitoring IS-IS
interface state
------------- -----
loopback1 up
ATM3/1.1 up
FastEthernet1/1 up
3 interfaces up in 3 interfaces
See show clns interface
Use to display information about ES and IS neighbors.
Use the detail keyword to display area addresses, IP addresses, and the ES or
IS neighbor's graceful restart capability and restarting state.
Field descriptions
System Id Six-byte value of router
SNPA Subnetwork point of attachment, which is the data link address; not
meaningful for a point-to-point circuit
Interface Interface the router was learned from
State State of the ES or IS
Init Router is an IS and is waiting for an IS-IS hello message. IS-IS
regards the neighbor as not adjacent.
Up ES or IS is considered reachable
Holdtime(rem) Remaining number of seconds before this adjacency entry
times out
Type One of the following adjacency types:
ES End-system adjacency either discovered by means of the ES-IS
protocol or statically configured
IS Router adjacency either discovered by means of the ES-IS protocol
or statically configured
L1 Router adjacency for level 1 routing only
L1L2 Router adjacency for level 1 and level 2 routing
L2 Router adjacency for level 2 only
Proto Protocol through which the adjacency was learned. Valid protocol
sources include ES-IS, IS-IS, and Static.
Area Address(es) Area addresses of the ES or IS
Ip Address(es) IP addresses of the ES or IS
Graceful Restart Capable Whether graceful restart is enabled (yes) or
disabled (no) on the ES or IS
level DIS(L-1)
--------- -------------
level-1-2 Point to Point
level-1-2 Point to Point
level-1-2 nemo:2.03
DIS(L-2) Metric
-------------- ------
Point to Point 10/10
Point to Point 10/10
nemo:2.03 10/10
